LAUNCH
1.2 Features
Integrated with demounting, mounting and inflating functions;
Equipped with 2-range bead breaking pedals with larger space;
2-range movable jaw, flexible, better suitable for demounting and mounting of flat tire with different specifications;
Adopted demounting head with no crowbar, pneumatic controlled pulling tire internal rim. Reasonable design, reliable
performance, sturdy and durable;
Adopted simple assisting arm, faster and more convenient for demounting and mounting tire, good reproducibility,
better protect the tire rim and to improve the quality of tire demounting and mounting.
1.3 Technical specifications
Weight of machine: 248kg
Working pressure: 0.8-1.0Mpa
Motor power: 1.1kw (1.5Hp)
Technical specifications for electric appliances:
Turntable revolution: 7r/min
Max. tire diameter: 1100mm(43")
Max. tire width: 355mm(14")
Locking rim range:external:12"-26"(305-660mm)
Working temperature: 0-50℃
Noise: <70dB
Force on splitter:
1.5 Applicable range
Max. tire diameter:1100 mm (43")
Max. tire width:355mm
0.75kw(1Hp)
220v
1hp
50HZ-60HZ
110V
1hp
60HZ
380V
3hp
50HZ
2500kg(5500lb)
(14")
TWC-711TMB Tire Changer User's Manual
internal:14"-28"(355-711mm)
2
