- Page 1 Device description netPI Extension Modules NPIX Hilscher Gesellschaft für Systemautomation mbH www.hilscher.com DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public...
-
Page 2: Table Of Contents
NIOT-E-NPIX-RS232: Extension module for RS-232............ 22 NIOT-E-NPIX-IO: Extension module for digital inputs and outputs ........ 25 NIOT-E-NPIX-EVA: Evaluation module ................ 30 Contacts.......................... 35 netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 3: Introduction
NIOT-E-NPIX-EVA (evaluation board) · Part no.: 1322.050 1.1.2 List of revisions Revision Date Revision 01-23-2017 Document created Table 1: List of revisions netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 4: Conventions In This Document
Operation instructions 1. <operational step> Ø <instruction> Ø <instruction> 2. <operational step> Ø <instruction> Ø <instruction> Results <intermediate result> <final result> netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 5: Legal Notes
The manual delivered with the product shall apply. Under no circumstances shall Hilscher Gesellschaft für Systemautomation mbH be liable for direct, indirect, ancillary or subsequent damage, or for any loss of income, which may arise after use of the information contained herein. - Page 6 Introduction 6/35 Liability disclaimer The hardware and/or software was created and tested by Hilscher Gesellschaft für Systemautomation mbH with utmost care and is made available as is. No warranty can be assumed for the performance or flawlessness of the hardware and/or software under all application conditions and scenarios and the work results achieved by the user when using the hardware and/or software.
- Page 7 Additional guarantees Although the hardware and software was developed and tested in-depth with greatest care, Hilscher Gesellschaft für Systemautomation mbH shall not assume any guarantee for the suitability thereof for any purpose that was not confirmed in writing. No guarantee can be granted whereby the...
- Page 8 The customer hereby expressly acknowledges that this document contains trade secrets, information protected by copyright and other patent and ownership privileges as well as any related rights of Hilscher Gesellschaft für Systemautomation mbH. The customer agrees to treat as confidential all of the information made available to customer by Hilscher Gesellschaft für...
-
Page 9: Installation
If your netPI has already been installed in a switch cabinet, remove the device from the top hat rail and disconnect all cables from the device. netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 10: Figure 1: Remove Cover Of Extension Slot
Figure 3: Inserting module Ø Push the module into the slot until it reaches its final position. netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 11: Figure 4: Tighten Screws Of The Extension Module
Ø Stick the label (included in the delivery of the module) onto the casing of the netPI. Figure 5: Attach label sideways ð You have installed the NPIX Extension Module. netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 12: Installing Npix With Open Netpi Casing
If your netPI has already been installed in a switch cabinet, remove the device from the top hat rail and disconnect all cables from the device. netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 13: Figure 6: Remove Cover Of Extension Slot
Ø Remove the screws of the cover of the extension slot at the bottom of the netPI. Figure 6: Remove cover of extension slot Figure 7: Extension slot with cover removed netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 14: Figure 8: Screws On The Top Side
Take care not to damage the antenna. Figure 10: Remove casing Ê You now have free sight of the expansion socket on the netPI PCB. netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 15: Figure 11: Inserting Module
Figure 13: Connector pins jammed netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 16: Figure 14: Tighten Screws At The Module
Ø Put the protection cap on the antenna, as shown in the picture below: Figure 15: Protection cap on antenna Ø Slide the upper casing back onto the netPI device. Figure 16: Refit casing netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 17: Figure 17: Tighten Screws
Ø Stick the label (included in the delivery of the module) onto the casing of the netPI. Figure 18: Attach label sideways ð You have installed the NPIX Extension Module. netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 18: Pinning Of The Extension Socket
BCM 21 (BCM_SPI1_SCLK) MMIO16 BCM 2 (BCM_SDA1) BCM 26 (GPIO) (IRQ from NPIX) Table 2: Pinning of the extension socket in netPI netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 19: Niot-E-Npix-Rs485: Extension Module For Rs-485
The label is included in the delivery as a separate sticker, and is to be attached to the casing of the netPI next to the mounted module. Figure 20: NIOT-E-NPIX-RS485 Label netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 20: Table 4: Rs-485 Interface
Not connected n.c. Not connected Reference potential n.c. Not connected BCM26(GPIO) Table 5: Pinning of the host interface of NIOT-E-NPIX-RS485 netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 21: Figure 21: Niot-E-Npix-Rs485 Block Diagram
ISO+5V n.c. 3,3V DC n.c. n.c. 5V DC n.c. ISOGND n.c. NXE1S0305MC L=600Ohm@100MHz ISOGND C=10µF/10V C=10µF/10V Figure 21: NIOT-E-NPIX-RS485 block diagram netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 22: Niot-E-Npix-Rs232: Extension Module For Rs-232
The label is included in the delivery as a separate sticker, and is to be attached to the casing of the netPI next to the mounted module. Figure 23: NIOT-E-NPIX-RS232 label netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 23: Table 7: Rs-232 Interface
Not connected n.c. Not connected Reference potential n.c. Not connected BCM26(GPIO) Table 8: Pinning of the host interface of NIOT-E-NPIX-RS232 netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 24: Figure 24: Niot-E-Npix-Rs232 Block Diagram
3,3V DC n.c. R=62Ohm n.c. 5V DC +3V3_ISO n.c. BZX84C3V3 n.c. NXE1S0305MC n.c. ISOGND ISOGND C=10µF/10V C=10µF/10V Figure 24: NIOT-E-NPIX-RS232 block diagram netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 25: Niot-E-Npix-Io: Extension Module For Digital Inputs And Outputs
Female plug with PUSH-IN spring connection (12 pin) LEDs PWR: external voltage supply connected (LED green) ERR: Error (LED red) Table 9: Technical data NIOT-E-NPIX-IO netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 26: Figure 26: Niot-E-Npix-Io Label
Digital input 4 OUT3 Digital output 4 +24VM +24V external voltage supply +24VM +24V external voltage supply Table 10: Digital IOs netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 27: Table 11: Pinning Of The Host Interface Of Niot-E-Npix-Io
Not connected n.c. Not connected Reference potential n.c. Not connected BCM26(GPIO) Table 11: Pinning of the host interface of NIOT-E-NPIX-IO netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 28: Figure 27: Niot-E-Npix-Io Block Diagram
STA4 OUT4 OUT3 +3V3 1/4 CLT3-4BT6 OUT1 netPI_IN0 OUT2 netPI_IN1 OUT3 netPI_IN2 OUT4 netPI_IN3 ISO-0VM ISO-0VM Figure 27: NIOT-E-NPIX-IO block diagram netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 29: Figure 28: Input Use Case Example
The following figure shows a simple example of an output use case featuring a light bulb as "consumer": Figure 29: Output use case example netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 30: Niot-E-Npix-Eva: Evaluation Module
1322.050 Interface 52 pin header (providing a 1:1 connection to the extension interface of the netPI) Table 12: Technical data NIOT-E-NPIX-EVA netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 31: Table 13: Pinning Niot-E-Npix-Eva
(from communication CPU) MMIO09 MMIO26 GPIO14_TXD0 GPIO19_SPI1_MISO MMIO10 MMIO27 GPIO15_RXD0 GPIO20_SPI1_MOSI MMIO11 MMIO36 GPIO17_TX_EN GPIO21_SPI1_SCLK MMIO16 GPIO2_SDA1 GPIO26 Table 13: Pinning NIOT-E-NPIX-EVA netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... -
Page 32: Figure 31: Niot-E-Npix-Eva Block Diagram
GPIO15_RXD0 GPIO17_TX_EN GPIO2_SDA1 GPIO3_SCL1 GPIO4_GPIO_GCLK GPIO7_SPIO_CE1_N GPIO18_SPI1_CE0_N GPIO22_GPIO_GEN3 GPIO23_GPIO_GEN4 GPIO25_GPIO_GEN5 GPIO27_GPIO_GEN2 GPIO16_SPI1_CE2_N GPIO19_SPI1_MISO GPIO20_SPI1_MOSI GPIO21_SPI1_SCLK GPIO26 Figure 31: NIOT-E-NPIX-EVA block diagram netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public... - Page 33 Input use case example..................29 Figure 29: Output use case example..................29 Figure 30: NIOT-E-NPIX-EVA ....................30 Figure 31: NIOT-E-NPIX-EVA block diagram ................ 32 netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public...
- Page 34 Table 11: Pinning of the host interface of NIOT-E-NPIX-IO ........... Table 12: Technical data NIOT-E-NPIX-EVA ................. Table 13: Pinning NIOT-E-NPIX-EVA..................netPI Extension Modules | NPIX © Hilscher 2018 DOC171201HW01EN | Revision 1 | English | 2018-01 | Released | Public...
-
Page 35: Contacts
Fax: +49 (0) 6190 9907-50 E-mail: info@hilscher.com Support Phone: +49 (0) 6190 9907-99 E-mail: de.support@hilscher.com SUBSIDIARIES China Japan Hilscher Systemautomation (Shanghai) Co. Ltd. Hilscher Japan KK 200010 Shanghai Tokyo, 160-0022 Phone: +86 (0) 21-6355-5161 Phone: +81 (0) 3-5362-0521 E-mail: info@hilscher.cn E-mail: info@hilscher.jp...
