Installation
In plastic bag: 4 Power cables
Camera
Speaker
Extra Remote
control
Codec
(Underneath
storage)
D13751.01 Page 1
Network
Wireless LAN
PC
Storage area for PC
or other equipment
Accessories box:
DC Power supply
4 ISDN cables
Ethernet cable
PC cable DVI/VGA
Headset
Shoulder strap
User Manual CD-Rom
Note: Remove accessories box and other
equipment from storage area when in use.
AC Power
TacticalMXP
LCD Screen
Microphone
User interface
panel
Headset
Advertisement
Related Manuals for TANDBERG Tactical MXP
Summary of Contents for TANDBERG Tactical MXP
- Page 1 Installation TacticalMXP Accessories box: DC Power supply 4 ISDN cables Ethernet cable PC cable DVI/VGA Headset Shoulder strap User Manual CD-Rom In plastic bag: 4 Power cables Note: Remove accessories box and other equipment from storage area when in use. Camera Speaker LCD Screen...
-
Page 2: The Remote Control
The Remote Control 1. Mic off: Mute and unmute the microphone. 2. Arrow keys: Navigate in menus or move camera. 3. Volume: Adjust the volume up and down. 4. Layout: Change picture layout on the screen. 5. Cancel: Go one step back or close menu. 6.
