Summary of Contents for ensto Wallbox
- Page 1 Wallbox Installation Instructions Operation Instructions RAK111_ENG 28.2.2019 © Ensto 2019...
-
Page 2: Table Of Contents
5.4. Ground Mounting on Concrete Foundation with Ground Mounting Pole..13 5.5. Wall Mounting on Wall Mounting Pole..............14 5.6. Ground Mounting on Unimi Concrete Foundation..........14 5.7. Fixing Wallbox on Mounting Poles EVTL43.00 and EVTL48.00......16 6. Electrical Connections......................17 6.1. Wiring Instructions....................17 6.2. -
Page 3: Ensto Wallbox
1-2 x Mode 3/ Type 2 socket outlet 2. Safety Instructions • Wallbox must be installed by a qualified person. • Read this instruction manual before installation and usage of the charging station. • The instruction manual must be stored in a safe location and be available for future instal- lation and service. -
Page 4: Delivery Contains
Flange KOT21715 Included in the delivery. Note! Cable glands are not included in the delivery. Please order suitable cable glands separately according to the used supply cable sizes, for example Ensto KTM... cable gland series (polyamide or brass). +0.1 -0.1 knock- outs RAK111_ENG / ©... - Page 5 EVTL40.00 Wall bracket 4x Ø7 2x Ø6 RAK111_ENG / © Ensto 2019...
- Page 6 EVTL43.00 Ground mounting pole RAK111_ENG / © Ensto 2019...
- Page 7 EVTL44.00 Adapter for ground mounting Ø54,5 Ø60,3 4 x M12 RAK111_ENG / © Ensto 2019...
- Page 8 EVTL48.00 Wall mounting pole RAK111_ENG / © Ensto 2019...
-
Page 9: Mounting Instructions
5. Mounting instructions 5.1. Before Installation Remove the Wallbox from its package. Do not scratch the surface of the Wallbox after removal from the package. When selecting installation site, take into account the following: • The minimum space needed for operating and maintenance. -
Page 10: Wall Mounting With Wall Bracket
Open the front cover lock and remove the front cover. Note! RFID, LED module and antenna cables are attached to the front cover. Be careful not to break any components when you remove the front cover. RAK111_ENG / © Ensto 2019... - Page 11 Place the Wallbox on the wall bracket (1). Attach the top of the Wallbox on the wall bracket using the screws included in the delivery (2). Secure the bottom of the Wallbox with the screws included in the delivery (3).
-
Page 12: Ground Mounting On Concrete Casting With Ground Mounting Pole
Fix the ground mounting pole on the anchor bolts with washers and nuts. Pull the electrical cables through the ground mounting pole. Attach the Wallbox on the mounting pole. See in- structions on page 16. RAK111_ENG / © Ensto 2019... -
Page 13: Ground Mounting On Concrete Foundation With Ground Mounting Pole
Fix the ground mounting pole on the adapter with bolts, washers and nuts. Pull the electrical cables through the ground mounting pole. 10. Attach the Wallbox on the mounting pole. See instructions on page 16. RAK111_ENG / © Ensto 2019... -
Page 14: Wall Mounting On Wall Mounting Pole
Pull the electrical cables through the wall mounting pole. Attach the Wallbox on the wall mounting pole. See instructions on page 16. 5.6. Ground Mounting on Unimi Concrete Foundation This installation example describes the installation pro- cedure using a concrete foundation supplied by Unimi - Solutions. - Page 15 Always place a cover plate on the foundation, if the Wallbox is installed in a separate session than the foundation. 10. When you start the installation of the Wallbox, remove the cover plate.
-
Page 16: Fixing Wallbox On Mounting Poles Evtl43.00 And Evtl48.00
5.7. Fixing Wallbox on Mounting Poles EVTL43.00 and EVTL48.00 KOT21715 Installation steps Open the front cover lock and remove the front cover. Note! RFID, LED module and antenna cables are attached to the front cover. Be careful not to break any components when you remove the front cover. -
Page 17: Electrical Connections
Ensure that the RFID, LED module and antenna cables are routed correctly. 10. Close the front cover. DC power supply Controller Supply board / boards connectors Cable route Plastic guide Front DIN rail Electrical cables RAK111_ENG / © Ensto 2019... -
Page 18: Power Supply
EVB100 and EVB200: A Residual current protection device (RCD) and a circuit breaker (MCB) for each charging outlet must be installed in the switchboard. EVB101: A combined RCD / MCB is integrated in the charger. Example 1: Supply connection from TN network for Wallbox with 2 outlets SUPPLY 2 SUPPLY 1... - Page 19 Example 2: Supply connection from IT network for Wallbox with 2 outlets SUPPLY 2 SUPPLY 1 Example 3: Supply connection for Wallbox with 1 outlet, integrated RCD / MCB SUPPLY RAK111_ENG / © Ensto 2019...
-
Page 20: Commissioning
7.1. Connecting to Wallbox If you want to change the default settings, you must connect to Wallbox via web configuration tool to be able to proceed with the commissioning settings. Use Firefox or Windows Explorer web-browser for configuring. -
Page 21: User Instructions
When you stop the charging event, the indicator light turns to waving green and you are able to unplug the charging cable. • After you have unplugged, you are logged out from the charging point and the charging point is free for the next user. RAK111_ENG / © Ensto 2019... -
Page 22: Technical Information - Evb
3-color LED • Green / Ready • Blue / Charging • Red / Error) Use access RFID (ISO/IEC 14443A, ISO/IEC 15693) Free access Mobile apps via 3rd party operators Current measurement Integrated / on-board measurement RAK111_ENG / © Ensto 2019... -
Page 23: Dimension Drawing
High operating temperature, such as direct sunlight, can cause reduced charging current or temporary interruption in the charging procedure Control and Communication Operation mode Standalone / Online Wireless 2G / 3G / 4G Wired Ethernet Protocol OCPP1.5 or OCPP1.6 10. Dimension Drawing RAK111_ENG / © Ensto 2019... -
Page 24: Installation / Commissioning Checklist
11. Installation / Commissioning Checklist Introduction This checklist is a guidance for ensuring both mechanical and electrical installation as well as commissioning of the Wallbox. Checking the Installation Go through the visual, mechanical and electrical installation when the charging station is un-powered. -
Page 25: Maintenance / Preventive Maintenance Instructions
SW update if needed (if in service contract). Restart the station from F0, ensure it will restart properly. EVB101: Test the function of the RCD / MCB twice a year by pressing the “Test” button. RAK111_ENG / © Ensto 2019... -
Page 26: Evb100 Internal Circuit Example
EX OUT 2 IN AC Power IN AC TEST RESET IC11000 EX SOCKET XBU6000 CHAGO PE (M5) WALLBOX Controller XKL6000 XKL6001 XKL6002 BU/RD BU/BN BU/GN BU/YE 6 7 8 9 10 Emergency Opener TYPE2 SUPPLY RAK111_ENG / © Ensto 2019... -
Page 27: Evb101 Internal Circuit Example
GND OUT ANTENNA 12V OUT EX OUT 2 EX OUT 2 IN AC Power IN AC TEST RESET IC11000 EX SOCKET XBU6000 CHAGO PE (M5) WALLBOX Controller XKL6000 XKL6001 XKL6002 BU/RD BU/BN BU/GN BU/YE TYPE2 SUPPLY RAK111_ENG / © Ensto 2019... -
Page 28: Evb200 Internal Circuit Example
GND IN XBU8001 IC11000 RGB1 + WHITE CHAG WALL Cont XBU1000 XBU1100 XKL6000 XST9000 XST1201 RFID XST1100 XST1101 XST1102 XST4002 XST1200 XST1103 XST4003 BU/RD BU/BN BU/GN BU/YE 6 7 8 9 10 Emergency Opener TYPE2 RAK111_ENG / © Ensto 2019... - Page 29 12V OUT EX OUT 2 EX OUT 2 TEST RESET EX SOCKET XBU6000 PE (M5) LBOX troller XKL6001 XKL6002 BU/RD BU/BN BU/GN BU/YE 6 7 8 9 10 Emergency Opener TYPE2 SUPPLY 1 SUPPLY 2 RAK111_ENG / © Ensto 2019...
-
Page 30: Extension Box Evk
MID class energy meter. Note! Cable glands are not included in the delivery. Please order suitable cable glands separately according to the used cable sizes, for example Ensto KTM... cable gland series (polyamide or brass). M12x1,5 Ø12.5 (Knock-out) Ø32.5 2pcs (Knock-outs) -
Page 31: Mounting The Extension Box
16.1. Mounting the Extension Box Mount the extension box as near to the Wallbox as possible to minimize the length of the con- nection cables. Items needed: Extension box EVK... 1 pcs Fastening set including mounting lugs and screws Screws 0°... -
Page 32: Wiring Instructions
Cut the connection cables in suitable lengths. Make sure that the supply connection cable is long enough so that the ground lead reaches the PE terminal on the extension box. Connect the extension box to the Wallbox, see wiring example on page 33. See also Wallbox wiring instructions on page 17. - Page 33 Example: Connection of EVK... extension box and Wallbox with 2 outlets WARNING! Danger of electrical shock or injury. Always disconnect power before carrying out work on the device. XST1100 XST1101 XST1102 XST4002 XST1200 XST1103 XST4003 XST1100 XST1101 XST1102 XST4002 XST1200...
-
Page 34: Technical Information - Evk
Dimensions 300 x 400 x 132 mm Weight approx. 4,1 kg, depends on product configuration Enclosure class IP66 Shock protection rate IK08 Operating temperature -25 °C … +65 °C Mounting On wall with fastening lugs RAK111_ENG / © Ensto 2019... -
Page 35: Troubleshooting
“Device Manager” that RNDIS tablished via web browser. network adapter is available. If not, update the related Windows driver. 18. Warranty Warranty conditions, see the product card on www.ensto.com. RAK111_ENG / © Ensto 2019... - Page 36 Ensto Finland Oy Ensio Miettisen katu 2, P.O. Box 77 FIN-06101 Porvoo, Finland Tel. +358 20 47 621 Customer service +358 200 29 007 ensto@ensto.com...
