Custom Dynamics CD-RG-AW2-B Installation Instructions

Part Numbers:
CD-RG-AW2-B
CD-RG-V-AW2-BB
Package Contents:
- LED Vent Trim Assemblies (pair)
- 4" Cable Ties (10)
- Speed Nuts (2)
- Instructions (1)
Fitment:
2015-2023 Harley-Davidson® Road Glide
(FLTRX), Road Glide Special (FLTRXS), 2022-2023 Road
Glide ST (FLTRXST) & CVO
(FLTRKSE), 2020-2024 Road Glide Limited (FLTRK), 2018-
2022 CVO Road Glide (FLTRXSE), 2016-2019 Road
Glide Ultra (FLTRU), 2020-2022 CVO
(FLTRUSE) and 2023-2024 Road Glide 3 (FLTRT).
ATTENTION
Please read all Information below before Installation
Warning: Disconnect negative battery cable from battery; refer to owner's
manual. Failure to do so may result in electrical shock, injury, or fire. Secure
negative battery cable away from positive side of battery and all other positive
voltage sources on vehicle.
Safety First: Make sure the motorcycle is parked on a level surface and the
motorcycles mechanical components are cool to the touch.
Notice: This product is designed and intended for use as auxiliary lighting on
motorcycles only. This product is NOT intended to replace any original equip-
ment lighting installed on the motorcycle and should not be used for that pur-
pose. This product must be wired in such a fashion that it does not interfere
with any original equipment lighting.
Notice: Do NOT use thread locker such as Loc-Tite
It will weaken the plastic at the screw holes causing cracks and will void the
warranty.
Note: You will have to remove the front fairing dash and windshield in order to
complete this installation. Please refer to your manufacturer's service manual
if unsure of this procedure.
Cleaning: Take special care in cleaning the finish. Use only Alcohol or Iso-
Heet and a fine microfiber cloth to remove dirt or debris. Never use abrasive
polishes or cleaners as these can scratch the finish.
Note: Over-tightening the mounting hardware will cause the paint to chip
which is not covered under the warranty.
Questions? Email: info@CustomDynamics.com or Call us at: 1 (800) 382-1388 M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
We thank you for purchasing the Custom Dynamics® Road
Glide LED Vent Trim. Our products utilize the latest technology
and highest quality components to ensure you the most reliable
service. We offer one of the best warranty programs in the in-
dustry and we back our products with excellent customer sup-
port, if you have questions before or during installation of this
product please call Custom Dynamics® at 1(800) 382-1388.
CD-RG-V-AW2-C
Road Glide Limited
Road Glide Ultra
with this product.
Custom Dynamics® Road Glide LED Vent Trim
Installation Instructions
Installation:
1. Remove the 4 windshield fasteners and trim. Lift the windshield up to
remove. Store the windshield in a safe place to prevent damage.
2. Remove the top vent. The top vent is secured to the fairing by clips.
Position yourself in the front of the motorcycle and lift straight up on the
top vent to release. Shown in Figure 1. Store the top vent in a safe
place to prevent damage.
1
3. Locate and unplug the left and right side 4 pin turn signal harness con-
nectors. Shown in Figure 2..
2
2
