Dismantling the housing cover
Note: Before adjusting or repairing the machine, make sure to
dismantle the housing covers according to the adjustment
and repair instructions.
Pull out the mains plug and the socket on the machine.
Remove the needle and the presser foot shoe.
Remove the detachable work support.
Remove the top cover.
Unscrew and remove the two torx screws of the housing insert.
Remove the housing insert.
Slightly raise both lugs 1 and remove the facing panel of the front housing panel by swiveling it
downwards (fig. 1).
Remove connection plug 2 (fig. 2) from the circuit board.
