Pfaff expression 2014 Service Manual page 10

Slide lever feed regulator for forwards and reverse stitch lengths
Dual fabric feed
Externally disengageable feed dog
Drive from motor to handwheel by flat toothed belt
Calotte metal bearings
Oil for calotte metal bearings: BP Energol HLP 46 or HLP 80 No._28-036550-09
Oil for sewing hook: No. 91-129452-91
Clear workspace: 175, 110, 204 mm
Machine height: 290 mm
Baseplate dimensions: 402 x 175 mm / machine length 408 mm
Free-arm dimensions: 80, 49, 200 mm
Housing and baseplate material: die-cast aluminium
Machine weight without carrying case: 8.3 kg
Needle system 130/705 H
Additional needle system classifications:
Twin needle
Wing needle
Twin hem stitching needle
Long needle eye
Stretch needle
Denim needle
Possible needle points:
Small ball point
Medium ball point
Large ball point
Pointed cloth point
Leather point right hand
Specifications of drive motor for the PFAFF expression 2034 - 2044
____________________________________________________________________
Nr. 92-330111-91
____________________________________________________________________
8
/ machine width 187 mm
Suffix = Zwi
Suffix = Wing
Suffix = Zwi-Ho
Suffix = N
Suffix = PS
Suffix = J
Suffix = SES
Suffix = SUK
Suffix = SKF
Suffix = J
Suffix = LR
24 V =41 W 9300 U/min
