QUICKSTART
KM 150/500 R Bp

Start up

1
A
D
2
A
3
A
WARNING
These are only brief instructions! Please read the operating instructions accompanying the appliance prior to using
or maintaining the appliance.
The non-compliance with the operating and safety instructions may lead to damage of the appliance and to risks
for the operator and other persons.
B
B
B
C
C
C
A Sit on the driver's seat.
B Turn the ignition key to position "I".
Note
The indicator of the battery capacity will show the
actual charge status after approx. 10 seconds.
C Check charge of battery; charge it if neces-
sary.
D Close covers.
A Check the wheels for tied up belts.
B Check roller brush.
C Check side brush.
A Pull seat adjustment lever outwards.
B Move seat, release lever and
lock in place.
Check that the seat is properly locked in posi-
tion by attempting to move it backwards and
forwards.
C Adjust the seat back.
5.964-129.0 01/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM 150/500 R Bp and is the answer not in the manual?

Questions and answers

Related Manuals for Kärcher KM 150/500 R Bp

Summary of Contents for Kärcher KM 150/500 R Bp

  • Page 1 QUICKSTART KM 150/500 R Bp WARNING These are only brief instructions! Please read the operating instructions accompanying the appliance prior to using or maintaining the appliance. The non-compliance with the operating and safety instructions may lead to damage of the appliance and to risks for the operator and other persons.
  • Page 2 QUICKSTART Operation Starting the machine A Sit on the driver's seat. Do NOT press the accelerator pedal. B Lock parking brake. C Bring the direction selector switch into the middle position. D Insert the ignition key into the ignition switch. Turn the ignition key to position "I".
  • Page 3 QUICKSTART Operation Cleaning the dust filter A Press the switch of the dust filter cleaning system. Operation with beacon lamp A Switch on the beacon lamp. Emptying waste container Danger Risk of injury! When emptying the waste contain- er, care should be taken to ensure that no per- sons or animals are within its swivelling range.

  • Page 4: Maintenance And Care

    QUICKSTART Maintenance and care A Check function of all control ele- ments B Inspect appliance for damage. A Check the hydraulic oil level. B Check brake fluid status. Danger Risk of injury! Always insert the safety rod when the waste container is raised.
  • Page 5 QUICKSTART Troubleshooting Whistling sound in the hydraulics A Refill hydraulic fluid Brushes turn only slowly A Check the roller brush and side brushes for wrapped belts. Little or no suction power in the brush area A Check, clean or replace the dust filter Sweeping unit does not pick up waste A Empty waste container...
