Maverick & Maverick Max RacePace Rear Smash Bumper Installation Instructions
Congratulations on your purchase of the DragonFire RacePace Rear Smash Bumper for the Maverick &
Maverick Max. Designed not only to look good, this bumper offers supreme protection as well as support
for rear plastics. Like everything we do we won't make something unless it improves what you have.
Accelerate your Maverick to RacePace!

Tools Required

(2) 13mm Wrench
(2) 15mm Wrench
10mm Wrench
7mm Socket
Number 30 Torx
Bit

Step 1: Place vehicle on flat/level surface.

Place gear shifter in park and remove
keys from the ignition.
Step 2: With floor jack, lift rear of the
vehicle up and secure with jack stands.
Step 3: Remove the top two bolts
retaining the rear a-arms. Set hardware
aside it will be re-used. See Figure A
Part # 01-2110 (Black - Non DS Models)
01-2111 (Red - Non DS Models)
01-2127 (Octane Blue - Non DS Models)
01-2131 (Manta Green - Non DS Models)
*This product does not promise rear end protection in the event of a collision
*Improper installation may result in damage to vehicle
*This product is not intended as an anchor point for pulling
*Do not use if there is any sign of damage
Off road activities can be hazardous and could lead to injury, dismemberment, paralysis and death.
No warranty of representation is made as to the products ability to protect the user from any injury
or death. The user assumes that risk. The acceptance and /or use of this merchandise purchased
from DragonFire by the customer hereby shall release DragonFire from any and all liability
pertaining to the use of such merchandise.
