Chassis; Front And Rear Covers - ADC ADCP-90-216 User Manual

ADCP-90-216
Issue 2, January 1998
FEATURE
Dimensions
Height
Width
Depth
Mounting
Splice Details
Splice Drawers
Splice Trays
Catalog Number:
FST-F3DF-FT
FST-F3DF-HS
FST-F3DF-MT
FST-F3DF-RT
FST-F3DF-3M
FST-F3DF-NT
FST-F3DF-RC
FST-F3DF-HS18
FST-F3DF-HSAC
Splice Capacity
Cable Clamp Kits
IFC/OSP Cable Clamp FL2-ACC007
* Except where otherwise noted.
A. Chassis
4.02 The splice module chassis is constructed of heavy gauge aluminum and has a baked
powder paint finish. The module is compatible with the 7-inch FDS connector module. Cable
access holes at the left and right side of both modules provide IFC or OSP cable fiber access.
Fiber access holes in the top and bottom of both modules permit protected routing of pigtails to a
connector module mounted either above or below the splice module.
B. Front and Rear Covers
4.03 A transparent front cover, hinged at the bottom, protects the fibers and pigtails from
normal activity near the module. The circuit designation labels provided are to be attached to the
front of each splice drawer. Circuit identification can be written on labels and attached to the
designation cards. The front cover can be removed for convenience and protection during
installation or other activity. The metal rear cover is hinged at the bottom and is removable. The
removable cover provides access to the interior of the chassis for fiber activity.
Page 6
1998, ADC Telecommunications, Inc.
Table 1. Splice Module Specifications
SPECIFICATION
7 in. (17.78 cm)
17 in. (43.18 cm)
11 in. (27.94 cm)
19-inch or 23-inch rack
6
12 (One or two splice trays per drawer)
Splice Chip Type:
Bare Fusion
Heat Shrink Fusion
Mechanical (Elastomeric)
Rotary
FibrLok
Qpak
Raychem
Heat Shrink Fusion (18 splices)
AOFR Clip
144 splices (12 splices per splice tray)*
Outside diameter 0.5-0.8 in. (13-20 mm)
