- Page 1 VLA COMPACT v a r i a b l e l i n e a r r a y VLA-C SERIES | USER’S GUIDE...
- Page 2 JBL VLA-C SERIES | USER’S GUIDE Note: While this guide refers to the VLA-C models without including a color designation, the color suffix is part of the full model number of the product. When ordering a product, the color must be specified via a suffix.
-
Page 3: Table Of Contents
JBL VLA-C SERIES | USER’S GUIDE TABLE OF CONTENTS 1 - Declaration of Conformity .............................. 2 - Safety ....................................... 2. 1 - Safety Instructions ..............................5 2.2 - General Hardware Information ........................5 2.3 - Attachment To Structures ..........................6 2.4 - Important Safety Warning .......................... -
Page 4: Declaration Of Conformity
JBL VLA-C SERIES | USER’S GUIDE 1 - DECLARATION OF CONFORMITY BRAND: JBL Professional FAMILY NAME: VLA Compact Loudspeakers and Accessories MODEL NAMES: • VLA-C265-BK • VLA-C2100-GR • VLA-C265-GR • VLA-C125S-BK • VLA-C2100-BK • VLA-C125S-GR We, HARMAN International, declare under our sole responsibility that the product, to which this declaration relates, is in... -
Page 5: Safety
JBL VLA-C SERIES | USER’S GUIDE 2 - SAFETY 2. 1 - SAFETY INSTRUCTIONS Read these instructions Keep these instructions Heed all warnings Follow all instructions Do not expose the product to sea spray or caustic environmental factors. VLA-C loudspeakers are not outfitted for use on the deck of cruise ships... -
Page 6: Attachment To Structures
None of the information presented herein is intended as a representation or warranty on the part of JBL. Anyone making use of this information assumes all liability arising from such use. All information presented herein is based upon materials and practices common to North America and may not directly apply to other countries because of dif fering material dimensions, specifications and/or local regulations. -
Page 7: Inspection And Maintenance
For all other hardware and fittings, refer to the hardware manufacturer’s inspection and maintenance guidelines for process . JBL is not responsible for the application of its products for any purpose or the misuse of this information for any purpose. Fur thermore, JBL is not responsible for the abuse of its products caused by avoiding compliance with inspection and maintenance procedures or any other abuse. -
Page 8: Mechanical Information
JBL VLA-C SERIES | USER’S GUIDE 3 - MECHANICAL INFORMATION VLA Compact suspension system and accessories are also in compliance with the ANSI E1.8 - 2012 Section 5.3.4 standard for a minimum safety factor of 5:1. Minimum safety factor requirements are often set by local regulations and the VLA-C Calculator should be used to verify the safety factor for each array configuration. -
Page 9: System Components
JBL VLA-C SERIES | USER’S GUIDE 4 - SYSTEM COMPONENTS VLA-C265 VLA-C2100 VLA-C125S VLA-C265 VLA-C2100 VLA-C125S Bracket Plate Bracket Plate Bracket Plate See later sections for additional information. CAUTION: Always use components and accessories specified and approved by JBL Professional. -
Page 10: Software
5 - SOFTWARE EASE GLL FILES EASE GLL files are available for VLA-C Series loudspeakers at the JBL Professional website www. jblpro.com on the VLA Compact Series webpage and on each of the individual model webpages. Example of small stadium with two flanking scoreboard arrays of 8 x VLA-C265 each (ave. 500 Hz – 4 kHz). - Page 11 JBL VLA-C SERIES | USER’S GUIDE VLA-C CALCULATOR The free VLA-C Calculator is simulation sof tware for designing and predicting JBL VLA-C Series systems. Acoustical Mapping The Acoustical Mapping tab allows for 2D sectional-view modeling of VLA-C arrays on up to four seating planes.
- Page 12 JBL VLA-C SERIES | USER’S GUIDE Array Configuration The Array Configuration tab describes the array and provides information about weight factors and center of gravity (CG), along with mechanical validation of the array. The array weight design factor is selectable between 5:1, 7:1, and 10:1. Frame options are selectable. If the array configuration falls outside the load limits of either the speaker cabinets, the speaker interconnect system, or the suspension system, this will be indicated via an error indication.
-
Page 13: Array Size Cabinet Suspension Limit Guidelines
JBL VLA-C SERIES | USER’S GUIDE 6 - ARRAY SIZE CABINET SUSPENSION LIMIT GUIDELINES Refer to the free VLA-C Calculator software for the array size cabinet suspension limits for your particular configuration. 7 - BRACKET PLATES (ie, Angle Brackets) Each loudspeaker model ships with a corresponding pair of bracket plates which can be seen here:... -
Page 14: Which Bracket Plate To Use
JBL VLA-C SERIES | USER’S GUIDE 7 . 1 WHICH BRACKET PLATE TO USE • When attaching a VLA-C265 to a VLA-C265, use the included VLA-C265 bracket. The possible splay angles are: 1.5°, 2.4°, 3.8°, 6.0°, and 9.5°. • When attaching a VLA-C2100 to a VLA-C2100, use the included VLA-C2100 bracket. The possible splay angles are: 2.4°, 3.8°, 6.0°, 9.5°, and 15.0°. -
Page 15: Assembly Drawing
JBL VLA-C SERIES | USER’S GUIDE 7 .2 ASSEMBLY DRAWING VLA-C2100 M10x35mm Stainless Steel Bolts 1.5mm pitch 6 mm hex drive (See torque spec, above.) M10 stainless steel lock washers VLA-C2100 VLA-C2100 Bracket Plate... -
Page 16: Example Of 6-Cabinet Array
JBL VLA-C SERIES | USER’S GUIDE 7 .3 EXAMPLE OF 6-CABINET ARRAY VLA-C125S 0° INTER-CABINET SPLAY ANGLE • VLA-C125S UPPER SPEAKER to VLA-C125S LOWER SPEAKER uses VLA-C125S bracket plate. • Orient “FRONT” arrow toward fronts of speaker cabinets. • On top half of bracket plate, use the 2 holes marked for when connecting C125S (ie, VLA-C125S) UPPER SPEAKER and C125S (ie, VLA-C125S) LOWER SPEAKER and for 0°ANGLE. -
Page 17: Side-Panel External Trim Cover Panels
JBL VLA-C SERIES | USER’S GUIDE 7 .4 SIDE-PANEL EXTERNAL TRIM COVER PANELS 8-32 x 1/2” trusshead, Phillips-drive, stainless steel bolts (See torque spec, above.) -
Page 18: Amplification
JBL VLA-C SERIES | USER’S GUIDE 8 - AMPLIFICATION The VLA-C full-range models may be driven passively or actively, and the full-range models can be driven individually or in pairs. Below is the listing of the current amplifier models that contain the proper FIR presets for the VLA-C loudspeaker models. - Page 19 JBL VLA-C SERIES | USER’S GUIDE PASSIVE VERSUS ACTIVE SETTING ON LOUDSPEAKERS Note that the VLA-C models ship in passive mode. For diagrams showing how to wire the speaker systems in either full-range passive mode or bi-amp mode, see the WIRING section of this guide.
-
Page 20: Dsp Presets
JBL VLA-C SERIES | USER’S GUIDE 9 - DSP PRESETS FIR filters and limiters for the VLA-C products have been developed specifically for the Crown DCI-N and DCI-DA amplifiers. The list of available presets are shown below and can be found on the VLA-C home page at www.jblpro.com. - Page 21 JBL VLA-C SERIES | USER’S GUIDE 7. Select the ‘VLA-C’ speaker tuning File and click ‘Open’. (Note: if you did not follow step 2, you may have to navigate to the location where the file is downloaded) 8. Double click on the ‘SPKR’ Processing Object on the Amplifier panel.
-
Page 22: Wiring
JBL VLA-C SERIES | USER’S GUIDE 10 - WIRING WIRING FOR VLA-C265 & VLA-C2100 FULL-RANGE LOUDSPEAKERS Internal Connections -- The cabinet’s internal wiring connections are shown below. The left-hand barrier strip terminals are for the input to -- and output from -- the built-in high-slope passive crossover network. - Page 23 JBL VLA-C SERIES | USER’S GUIDE Wiring for Use of the Internal Crossover Network -- The cabinet’s internal wiring connections are shown below. Low-Pass To LF Drivers Crossover Filter High-Pass To HF Drivers Crossover Filter Left-Hand Right-Hand Barrier Strip Barrier Strip...
- Page 24 JBL VLA-C SERIES | USER’S GUIDE Wiring for Bi-amplification -- Connect the low-pass output from the amplifier to the right-hand barrier strip terminals labelled LF+ and LF-. Connect the high-pass output from the amplifier to the right-hand barrier strip terminals labelled HF+ and HF-. These connections are shown in the diagram below in orange, although the wire color you use may be different.
-
Page 25: Wiring For Vla-C125S Subwoofer
JBL VLA-C SERIES | USER’S GUIDE WIRING FOR VLA-C125S SUBWOOFER Connect the subwoofer output from the amplifier to the right-hand barrier strip terminals labelled LF 4Ω+ and LF 4Ω -. To the two 15” LF Drivers Front Thru LF 4Ω... -
Page 26: Wiring Three Vla-C-125S Cabinets In A Cardioid Subwoofer Configuration
– with two cabinets forward-facing and one cabinet rear- facing. The kit prevents having wiring exposed on the outsides of the cabinets and prevents having the wiring extend to the front side of the array (for connecting the rear-facing cabinet). See JBL ’s VLA-C125S-ACC Cardioid Kit Guide. -
Page 27: Specifications
JBL continually engages in research related to product improvement. Some materials, production methods and design refinements are introduced into existing products without notice as a routine expression of that philosophy. For this reason, any current JBL product may differ in some respect from its... - Page 28 JBL continually engages in research related to product improvement. Some materials, production methods and design refinements are introduced into existing products without notice as a routine expression of that philosophy. For this reason, any current JBL product may differ in some respect from its...
- Page 29 JBL continually engages in research related to product improvement. Some materials, production methods and design refinements are introduced into existing products without notice as a routine expression of that philosophy. For this reason, any current JBL product may differ in some respect from its...
-
Page 30: Impedance Curves
JBL VLA-C SERIES | USER’S GUIDE 12. 1 IMPEDANCE CURVES VLA-C265 Passive Impedance 1000 10000 20000 Frequency (Hz) VLA-C265 Biamp Impedance VLA-265 LF VLA-265 HF 1000 10000 20000 Frequency (Hz) VLA-C2100 Passive Impedance 1000 10000 20000 Frequency (Hz) VLA-C2100 Biamp Impedance... -
Page 31: Contact Information
Jupiter 2A Block, 4th Floor Marathahalli Ring Road Bangalore 560103, India +918049365905 www.harman.com Professional Contacts, Outside the USA: Contact the JBL Professional Distributor in your area. A complete list of JBL Professional international distributors is provided at our U.S.A. website: www.jblpro.com... - Page 32 JBL Professional | 8500 Balboa Blvd. | Northridge, CA 91329 | USA...
