JBL Authentics L8 Owner's Manual

Home audio system
Hide thumbs Also See for Authentics L8:
Table of Contents

Advertisement

Quick Links

Authentics L8
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for JBL Authentics L8

Summary of Contents for JBL Authentics L8

  • Page 1 Authentics L8 Owner’s Manual...

  • Page 2: Table Of Contents

    JBL AUTHENTICS L8 BOTTOM PANEL CONTROLS PLACING THE JBL AUTHENTICS L8 SYSTEM CONNECTIONS POWER CONNECTION WI-FI CONNECTION OPERATION TURNING THE JBL AUTHENTICS L8 ON AND OFF ADJUSTING THE SYSTEM’S VOLUME MUTING THE SYSTEM SWITCHING SOURCES OPERATING THROUGH BLUETOOTH OPERATING THROUGH NFC ®...

  • Page 3: Introduction

    Authentics L8 Introduction Introduction Included Items Thank you for purchasing the JBL Authentics L8 home audio The JBL Authentics L8 audio system includes the following system, with which you are about to begin many years of items in the package: listening enjoyment.

  • Page 4: Controls And Connections

    Refer the following illustrations to remove the grille of your Controls and Connections Authentics L8 audio system. The JBL Authentics system controls and connections are available on the top and bottom panels of the system. JBL Authentics L8 Top Panel Controls On the top-right corner of the system, you will be able to locate the Power button and Volume tuner.

  • Page 5: Jbl Authentics L8 Bottom Panel Controls

    Optical Power ON/OFF The top panel of the JBL Authentics L8 contains the following controls at the center, covered by a lid. The controls can be accessed by removing the lid: Two USB Ports Aux in...

  • Page 6: Placing The Jbl Authentics L8 System

    Placing the JBL Authentics L8 JBL Music App System To connect your JBL Authentics L8 to the Wi-Fi network: The audio system is not a portable device and needs to be Download the JBL Music app and open it. installed in a specific place in your room to provide you with the best possible music experience.
  • Page 7 Authentics L8 system for less than two seconds. iOS Wi-Fi Sharing with Cable If you have not connected your iOS device with Bluetooth, use the following method to connect your JBL Authentics L8 to the Wi-Fi network: Connect your iPhone, iPad or iPod touch to the system’s top USB port, labeled iPad, using the...
  • Page 8 > 2s The iPhone, iPad or iPod touch will then share Wi-Fi settings with the JBL Authentics L8 and it will be connected to your Wi-Fi network. This takes at least 40 seconds. Once the JBL Authentics L8 is connected to the network, the system will play a tone indicating the connection is successful.

  • Page 9: Operation

    Operation Operation Turning the JBL Authentics L8 ON and OFF To turn the JBL Authentics L8 ON, press the Power button on the top panel of the system. The system can play only one active source at a time. Press the Source button whenever you want to change the source.

  • Page 10: Operating Through Nfc

    LED illuminates constantly, it is paired the NFC area on the top panel of the JBL Authentics L8. If with the device and you can stream audio via there is a pop-up on your phone asking if you want to pair with Bluetooth from the device to the system.

  • Page 11: Operating Through Dlna

    You can use DLNA compliant software to stream audio to your JBL Authentics L8 from a PC or Android device that is connected to the same network. To operate through DLNA, from the media player software, select audio to play back on the JBL_L8_WF_XXXXXX, where XXXXXX is the last six characters of the system’s MAC address.

  • Page 12: Jbl Music App

    Check www.jbl.com periodically to see if any updates are available. If a new firmware version is released, first download it from the JBL website and save the file to an easy-to-remember location on your computer. The system is non-functional during the upgrade process.

  • Page 13: Led Indication Table

    Authentics L8 LED Indication Table If a new version is available, download it from the JBL website Factory Setting Reset and proceed with the following upgrade method: To restore all settings to the factory defaults, press and hold the Place the upgrade file downloaded from the website, power button for at least 10 seconds.

  • Page 14: Troubleshooting

    Authentics L8 Troubleshooting Troubleshooting If your JBL Authentics L8 system is not performing the way you think it should, check if the problem is covered in this section before calling your dealer or contacting a JBL representative. Problem Solutions My JBL Authentics L8 does not turn ON Make certain the AC power cord is plugged into a live outlet.

  • Page 15: Specifications

    Authentics L8 Specifications Specifications Type Powered two-way stereo speaker with wireless audio playback and control High-frequency transducers 1 inch tweeter Low-frequency transducers 4 inch woofer Frequency response 45 Hz – 35 kHz Maximum SPL 104 dB @ 1m Signal-to-Noise Ratio (analog inputs) >92 dB...
  • Page 16 © 2013 HARMAN International Industries, Incorporated. All rights reserved. JBL is a trademark of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. JBL Authentics L8 and the “Hear the truth” logo is a trademark of HARMAN International Industries, Incorporated.
