Summary of Contents for Instramed Isis
- Page 1 Quick start guide 00:00 Shocks: 0 00:00:20 FOLLOW THE INSTRUCTIONS Place the pads on the patient. 0,25 AUTOMATED EXTERNAL DEFIBRILLATOR...
- Page 2 For information about warranty or technical assistance, please contact Instramed’s technical support. Copyright © 2017 Instramed. The Isis, Instramed and its respective logos are trademarks of Instramed Indústria Médico Hospitalar Ltda. The internal software of this product is Instramed’s intellectual property, being protected under international copyright laws.
- Page 3 Isis in its portable configuration (not connected to the electrical network). More information on this topic is available in the ISIS User Manual present on the CD which accompanies the product.
-
Page 4: Table Of Contents
Front panel ....................... 10 Sides ......................... 10 Function of the front panel elements ................ 11 1 - Screen ......................11 2 - Operational status indicator ................12 3 - Start button ..................... 13 Operation Operation cycle of the Isis ..................14... - Page 5 CPR Maestro Using the CPR Maestro .................... 21 PC Connection Requirements ......................22 SoftDEA Installation ....................22 Connecting the Isis to a PC ..................22 Inspection and Maintenance Device care ....................... 23 Cleaning and disinfection ..................23 Preventive Maintenance ................... 23 Corrective Maintenance ....................
-
Page 6: Presentation
Given the complexity of the clinical variables involved, for many years only doctors and experienced paramedics could use defibrillators to reverse a cardiac arrest. Nowadays, however, with the evolution of artificial intelligence (AI), the Isis, using its Neural Network Technology, is capable of analyzing the state of the patient, considering the clinical variables and applying, automatically, the most suitable shock therapy. -
Page 7: Safety Information
This guide does not substitute the user manual. Its function is to familiarize the user with the main functions and ways of operating the equipment. For detailed information on the functioning of the Isis, please consult the user manual on the CD which accompanies the product. -
Page 8: Warnings
NOTICE: each and every repair to the equipment can only be done by Instramed’s authorized technical assistance centers. NOTICE: the use of the Isis is restricted to one patient at a time. NOTICE: the applied parts are protected against defibrillation discharge; during discharge there may be baseline variation. -
Page 9: Precautions
Electromagnetic Compatibility The Isis is a device built according to NBR and IEC standards and therefore is completely safe for the patient and the user. However, all safety precautions described below must be followed... -
Page 10: The Equipment
The Equipment Front panel 1. Screen indicating the stages of the de-fibrillation. procedure and ECG curve. 2. Microphone. 3. Operational status indicator. 00:00 Shocks: 0 00:00:20 FOLLOW THE INSTRUCTIONS 4. Start button. Place the pads on the patient. 0,25 AUTOMATED EXTERNAL DEFIBRILLATOR Sides 1. -
Page 11: Function Of The Front Panel Elements
Quick start guide | The Equipment Function of the front panel elements 1 - Screen The Isis presents the following items on the screen when connected to the patient: CPR 00:00 Shocks: 0 00:00:20 ANALYSING... Do not touch the patient. -
Page 12: Operational Status Indicator
Mains supply LED on means device is connected to the electric current. Mains supply LED blinking when in normal use means the battery needs charging.In this state, Isis guarantees at least 3 discharges at maximum energy. • Battery LED on means internal battery is being charged. A blinking LED beside this symbol means full charge. -
Page 13: Start Button
Applying shock therapy (active only when the automatic clinical analysis of the patient indicates the need for it). NOTE: it is not necessary to switch the Isis off. Fifteen seconds after the re- moval of pads from the patient or disconnection of pads from the equipment, the device switches itself off, saving battery charge. -
Page 14: Operation
The energy delivered is preset. The user cannot change this protocol. For adult electrodes: 1st shock: 150J, the following: 200J. For child electrodes: 50 J. More information on this topic is available in the ISIS User Manual present on the CD which accompanies the product. -
Page 15: Adhesive Pads Placement
Quick start guide | Operation Adhesive pads placement 1 - adults Remove pads from their wrapping and peel off the film protecting the adhesive. Place pads on the patient according to the picture above, keeping adhesive area in contact with the skin. ATTENTION: The area in contact with the pads must be dry. -
Page 16: Children Under 8 Years Old
2 - children under 8 years old The Isis can be used on children from the age of one year onwards. However, on patients from one year of age to eight years of age or patients who weigh less than 25kg, some precautions must be taken: Use child pads;... -
Page 17: Simplified Diagram Of Procedure In Adults
Wait for emergency Call emergency team service No pulse Place victim on a dry, flat and steady area - Place pads - Activate the Isis Restarts the cycle Restarts the cycle The Isis analyzes patient’s condition Shock NOT Shock recommended... - Page 18 Check patient’s condition - Panting Not breathing Wait for emergency team Place victim in a dry flat steady area - Place pads - Activate the Isis Restarts the cycle Restarts the cycle The Isis analyzes patient’s condition Shock NOT Shock recommended...
-
Page 19: Ecg Monitoring
(always on DII derivation) and alarms when detects a situation of cardiac arrest. In this situation, and in shock indicated situation, the adhesive pads should be connected. Using the ECG: Connect the ECG patient cable to the Isis, using the connector indicated below, located on the side of the device. -
Page 20: Cpr Maestro
Its sensors measure the frequency and depth of chest compressions, providing the user with real-time feedback. These information are displayed on CPR Maestro and Isis screens and through sound recommendations. Note: Because it is an accessory, it can not be used by itself. Only con- nected to Isis. -
Page 21: Using The Cpr Maestro
CPR Maestro Using the CPR Maestro 1 – Connect the CPR Maestro to Isis, using the input indicated below, located on the side of the equipment. 2 – Place the device on the patient’s chest, according to the image below. -
Page 22: Pc Connection
Portuguese. You only have to select a language the first time you start the software. • After the software reads the Isis data, the ECG and the events list will appear on the software’s screen. ATTENTION: the equipment blocks any operation on the patient when commu- nication via USB with PC occurs. -
Page 23: Inspection And Maintenance
(see page 12 - operational status indicator). Corrective Maintenance If the equipment needs repair, this can only be done by INSTRAMED or its authorized representative, otherwise this Warranty certificate may no longer be valid. No internal parts are to be fixed by the user. -
Page 24: Warranty Certificate
This also applies in case of alterations made to this contract, the fiscal receipt, or to the equipment’s serial number. Instramed Indústria Médico Hospitalar Ltda. is not responsible for the improper use of this equipment, by people who are not familiar with its function or the techniques recommend for its proper use. - Page 25 AUTOMATED EXTERNAL DEFIBRILLATOR www.Instramed.com.br +55 (51) 3073 8200...
