Summary of Contents for Instramed Eazy PRO
- Page 1 Quick start guide AUTOMATED EXTERNAL DEFIBRILLATOR WITH MANUAL FUNCTION...
- Page 2 For information about warranty or technical assistance, please contact Instramed’s technical support. Copyright © 2017 Instramed. The Eazy PRO, Instramed and its respective logos are trademarks of Instramed Indústria Médico Hospitalar Ltda. The internal software of this product is Instramed’s intellectual property, being protected under international copyright laws.
- Page 3 20 days, it is advisable to execute a full battery charge. If this procedure is not performed, there is a risk of draining the battery and consequently being unable to use the Eazy PRO in its portable configuration (not connected to the electric current).
-
Page 4: Table Of Contents
Index Presentation Characteristics ......................06 Safety Information About this guide ......................07 Use criteria ....................... 07 Qualified users ......................07 ECG misinterpretation ....................07 Warnings ........................08 Adverse effects ......................08 Precautions ....................... 09 Electromagnetic Compatibility .................. 09 The Equipment Front panel ....................... - Page 5 Using the CPR Maestro .................... 22 PC Connection Requirements ......................23 SoftDEA Installation ....................23 Connecting the Eazy PRO to a PC ................23 Inspection and Maintenance Device care ....................... 24 Cleaning and disinfection ..................24 Preventive Maintenance ................... 24 Corrective Maintenance ....................
-
Page 6: Presentation
Presentation The Eazy PRO is a new generation Semi-Automated External Defibrillator (AED). Using Neural Network technology, the EAZY guides by voice, makes the diagnosis, considers clinical variables and applies treatment safely with the touch of only a single button. Designed for emergency care, it is compact, light, resistant and easy to use. -
Page 7: Safety Information
This guide does not substitute the user manual. Its function is to familiarize the user with the main functions and ways of operating the equipment. For detailed information on the functioning of the Eazy PRO, please consult the user manual on the CD which accompanies the product. -
Page 8: Warnings
NOTICE: each and every repair to the equipment can only be done by Instramed’s authorized technical assistance centers. NOTICE: the use of the Eazy PRO is restricted to one patient at a time. NOTICE: the applied parts are protected against defibrillation discharge; during discharge there may be baseline variation. -
Page 9: Precautions
Electromagnetic Compatibility The Eazy PRO is a device built according to NBR and IEC standards and therefore is completely safe for the patient and the user. However, all safety precautions described below must be followed... -
Page 10: The Equipment
The Equipment Front panel 1. Touch screen: presents operational information and allows for manual interaction with the device. 2. Operational status indicator. 3. Start button. AUTOMATED EXTERNAL DEFIBRILLATOR (AED) MANUAL OVERRIDE FUNCTION Sides 1. Speaker 2. Battery power supply con- nector 3. -
Page 11: Function Of The Front Panel Elements
Function of the front panel elements 1 - Touch screen A) IN AUTOMATIC MODE As default, the device starts operating in AUTOMATIC MODE. In this configuration, the Eazy PRO presents the following items on the screen when connected to the patient: BPM 080 CPR 00:00 Analyzing... - Page 12 If the user decides to switch to manual mode, the equipment will function as a standard defibrillator. In this situation, it will be necessary to select the appropriate charge according to the type of patient without the Eazy PRO’s intervention or orientation. Energy charging, delivering the shock and CPR interval counting will be the user’s entire responsibility.
-
Page 13: Operational Status Indicator
EVEN WHEN THE BATTERY HAS BEEN FULLY CHARGED, THE OPERA- TIONAL STATUS INDICATOR WILL STILL BE SHOWING The display will only change from when the Eazy PRO performs the auto-test routine or if the device is turned on/of by the user. -
Page 14: Start Button
Applying shock therapy (active only when the automatic clinical analysis of the patient indicates the need for it). NOTE: it is not necessary to switch the Eazy PRO off. Fifteen seconds after the removal of pads from the patient or disconnection of pads from the equipment, the device switches itself off, saving battery charge. -
Page 15: Operating In Aed Mode
When in AED mode (Automated External Defibrillator), the Eazy PRO identifies arrhythmias and selects the energy charge automatically. Below you will find a simplified introduction to how the Eazy PRO operates. Be sure to carefully memorize the detailed guide on the next pages before operating the equipment. -
Page 16: Operating In Manual Mode
In this situation, the device does not interfere with the treatment, and the user is responsible for choosing the energy, charging the charge and delivering the shock. After confirming the mode change, the Eazy PRO ceases to emit sound and visual orientation, in addition to the automatic safeguards against shocks. -
Page 17: Adhesive Pads Placement
Quick start guide | Operating in manual mode Adhesive pads placement 1 - adults Remove pads from their wrapping and peel off the film protecting the adhesive. Place pads on the patient according to the picture above, keeping adhesive area in contact with the skin. -
Page 18: Children Under 8 Years Old
Operating in manual mode 2 - children under 8 years old The Eazy PRO can be used on children from the age of one year onwards. However, on patients from one year of age to eight years of age or patients who weigh less than 25kg, some precautions must be taken: Use child pads;... -
Page 19: Simplified Diagram Of Procedure In Adults
Wait for emergency Call emergency team service No pulse Place victim on a dry, flat and steady area - Place pads - Activate the Eazy PRO Restarts the cycle Restarts the cycle The Eazy PRO analyzes patient’s condition Shock NOT Shock recommended... - Page 20 - Panting Not breathing Wait for emergency team Place victim in a dry flat steady area - Place pads - Activate the Eazy PRO Restarts the cycle Restarts the cycle The Eazy PRO analyzes patient’s condition Shock NOT Shock recommended...
-
Page 21: Ecg Monitoring
ECG Monitoring The ECG monitoring is available with the use of the 3 lead ECG cable (optional). The Eazy PRO monitors only the ECG DII derivation. The device may operate in three different ways. • Only adhesive pads connected: the device works as an external automated defibrillator, using the AHA protocol. -
Page 22: Cpr Maestro
The parameter will be automatically turned off on the Eazy PRO screen. Using the CPR Maestro 1 – Connect the CPR Maestro to Eazy PRO, using the input indicated below, located on the side of the equipment. 2 – Place the device on the patient’s chest, according to the image below. -
Page 23: Pc Connection
Portuguese. You only have to select a language the first time you start the software. • After the software reads the Eazy PRO data, the ECG and the events list will appear on the software’s screen. ATTENTION: the equipment blocks any operation on the patient when commu- nication via USB with PC occurs. -
Page 24: Inspection And Maintenance
Remember to check the status of the operational status indicator at least every 30 days. Corrective Maintenance If the equipment needs repair, this can only be done by INSTRAMED or its authorized representative, otherwise this Warranty certificate may no longer be valid. No internal parts are to be fixed by the user. -
Page 25: Warranty Certificate
This also applies in case of alterations made to this contract, the fiscal receipt, or to the equipment’s serial number. Instramed Indústria Médico Hospitalar Ltda. is not responsible for the improper use of this equipment, by people who are not familiar with its function or the techniques recommend for its proper use. - Page 26 AUTOMATED EXTERNAL DEFIBRILLATOR WITH MANUAL FUNCTION www.Instramed.com.br +55 (51) 3073 8200...
