BUCKINGHAM MFG M3 Attachment Instructions

Sling magnet

Download this manual

BUCKINGHAM MFG.

The Sling Magnet is designed for use when attaching slings to equipment in the field. It is

specifically useful in attaching a sling to a transformer for lifting and removing the transformer

during line work. This device is used to hold one end of the sling in place, while attaching the

other end of the sling.

Black hook & loop

strap.

The following procedure shows how to utilize the Sling Magnet in the lifting of an electrical

transformer:

Step # 1 – Locate one end of the sling to attach the Sling Magnet above the sling eye.

Step # 2 – Unfold the hook & loop strap of the Sling Magnet and place the Sling Magnet around

the sling. Ensure the yellow tube material is facing out away from the sling (see Fig. 1):

Sling eye.

M3SlingMagnet.doc (Rev. 7/31/17)

P/N 230370

Attachment Instructions

P/N M3 – Sling Magnet

Magnet inside

yellow tube.

Fig. 1

Web end of Sling

Magnet.

Magnet facing

out away from

sling.
