00054893
(DIR90BT)
Digital Radio
Digital-Radio
Operating Instructions / Bedienungsanleitung / Mode d'emploi / Instrucciones de uso /
Руководство по эксплуатации / Istruzioni per l'uso / Gebruiksaanwijzing / Οδηγίες χρήσης / Instrukcja obsługi /
Használati útmutató / Návod k použití / Návod na použitie / Manual de instruções / Kullanma kılavuzu /
Manual de utilizare / Bruksanvisning / Käyttöohje / Работна инструкция / Betjeningsvejledning / Manuelt stasjonssøk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hama DIR90BT
Summary of Contents for Hama DIR90BT
- Page 1 00054893 (DIR90BT) Digital Radio Digital-Radio Operating Instructions / Bedienungsanleitung / Mode d‘emploi / Instrucciones de uso / Руководство по эксплуатации / Istruzioni per l‘uso / Gebruiksaanwijzing / Οδηγίες χρήσης / Instrukcja obsługi / Használati útmutató / Návod k použití / Návod na použitie / Manual de instruções / Kullanma kılavuzu /...
- Page 2 Technical data DAB+ Bluetooth Podcasts Internet Spotify Digital Radio ü ü ü ü ü ü ü Bluetooth WiFi 2.4GHz (b/g/n) / 5GHz (a/n), Bluetooth Standard (4.2) Display 2.4" (6.0 cm) Liquid Crystal Display (LCD) Encryption WEP, WPA, WPA2, WPS Current input 12 V 1.0 A DAB/DAB+...
-
Page 3: Spotify Connect
Spotify Connect Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how... - Page 4 AUX IN LINE OUT...
-
Page 6: Operating Instructions
D Operating Instructions Controls and displays A: Front Presets 1-4 [POWER] button [MEMORY] button [MENU/SETTINGS] button [MUTE] button [INFO] button [BACK] button [MODE] button [NAVIGATE/ENTER/ VOLUME] button Display B: Reverse Mains power supply DC IN AUX IN Headphone socket Telescopic aerial LINE OUT socket Update port... - Page 7 C: Remote control ▲ Up / ▼ Down / ◄ Back one menu level Navigation On/off switch ≙ [back] / buttons Press ≙ [volume -/+] / [ ► Forward / Confirm ≙ Press [enter/navigate]/[OK] Mute Confirm ≙ Press [enter/ Direct access to Internet [OK] [IR] navigate]...
-
Page 8: Table Of Contents
Content Explanation of warning symbols and notes . . . 6 10.4 Favourites (local) ..... . . 15 10.4.1 Assigning the Presets shortcut buttons ..15 2. - Page 9 17.4 Language......23 17.5 Factory reset......23 17.6 Software update.
-
Page 10: Menu Structure
Menu structure Main menu* Internet Radio Station list Local Germany Last listened Search Stations Location Popular stations New Stations Main menu* System settings** Podcasts Podcast List Main menu* System settings** Spotify Connect Main menu* System settings** Station list Scan Prune invalid Station order Main menu* System settings**... -
Page 11: Explanation Of Warning Symbols And Notes
Thank you for choosing a Hama product. Take your time 3. Safety instructions and read the following instructions and information • The product is intended for private, non-commercial use only. completely. Please keep these instructions in a safe place • Do not use the product in the immediate vicinity of for future reference. -
Page 12: Informations And Notes Before Getting Started
(unless these are being Use only original accessories (or accessories approved kept ready for an emergency). by Hama) to avoid damage to the product. • Do not short-circuit batteries. • Do not charge batteries. 5. Getting started •... -
Page 13: Radio - Connecting And Starting Up
• Select each successive letter and digit by turning country-specific adapter may be necessary. You can find an [NAVIGATE/ENTER/VOLUME] and confirm each appropriate selection of Hama products at www.hama.com. selection by pressing [NAVIGATE/ENTER/VOLUME]. • To make corrections, select [BKSP / <-] and confirm. -
Page 14: Initial Setup
5.4 Initial setup Date / Time / 12/24-hour format When it is first connected to the power supply, a list of available • Auto update languages for the menu is displayed. Proceed as follows to • Update from DAB/ FM set your desired language: If automatic time and date adjustment is activated, the device receives time and date information from... -
Page 15: Main Menu / Modes
6. Main menu / modes 7.1.1 Search by country or region This devices supports radio reception via the Internet, To search for a station by continent, country and region, DAB/DAB+ and FM. proceed as follows: • Press [ ] (4) to access the Settings menu. The main menu contains the various operating modes •... -
Page 16: Popular Stations
7.1.4 Popular stations 7.2 Favourites (local) You can find a selection of the most popular stations You can save up to 20 of your favourite stations for quick as follows: and direct access. • Press [ ] (4) to access the Settings menu. •... -
Page 17: Favourites
7.3 Favourites • During registration, the radio’s ID is associated with your e-mail address and saved in the web interface. (airable - http://www.wifiradio-frontier.com) • If multiple radios are registered to you and you wish to In addition to the local favourite memory slots, you can delete one of those registrations or just compare them, also create your own lists of favourites. -
Page 18: My Added Stations
7.3.4 My Added Stations 8.1.2 Search by format (subjects or categories) If a station you desire is not yet available, you can add it manually to the portal, or suggest a station be added to To search for a podcast by continent, country and region, the database (Recommend station). -
Page 19: Assigning The List Of Presets (1-20)
8.2.3 Assigning the list of presets (1-20) After successful initial connection: From the main menu or after pressing [ ]/[MODE] repeatedly, • Set the station that you would like to save as a station preset. activate Spotify (Spotify Connect) mode on the radio: •... -
Page 20: Station List
10.2 Station list 10.4 Favourites (local) You can call up the station list in DAB mode at any time. You can save up to 20 of your favourite stations for quick To do this, proceed as follows: and direct access. •... -
Page 21: Drc (Dynamic Range Control)
10.5 DRC (Dynamic Range Control) 11. FM Some DAB network radio stations support a volume control From the main menu or after pressing [ ] repeatedly, feature that actively takes effect during playback. If the activate operating mode FM (FM Radio) on the radio. volume suddenly increases, DRC automatically lowers it. -
Page 22: Manual Station Search
11.3 Manual station search 11.4.4 Calling up a station from the Presets list (1-20) With manual station settings, you can define the required to call up the Presets list. • Press frequency yourself and also receive stations that had • Use [NAVIGATE/ENTER/VOLUME] (9) to navigate signals too weak to pick up on the automatic station to the preferred station and confirm your selection by search and which therefore were not included. -
Page 23: Bluetooth
YES button and confirm the termination of the Bluetooth • If necessary, start searching for Bluetooth devices on ® connection by pressing [ENTER/NAVIGATE]. your device. • Select DIR90BT and wait until radio is listed as connected in the Bluetooth settings of your device. ®... -
Page 24: Other Connection Options
14. Other connection options 15. Sleep 14.1 Connection via LINE OUT The radio has a timer function, which switches the radio to standby mode after a pre-defined length of time, You can connect your loudspeaker, for example, to the radio's regardless of its operating mode. -
Page 25: Activating / Deactivating The Alarm
Programme: • To set the equaliser, proceed as follows: If you selected Internet radio/ DAB/ FM, choose which station you wish to be woken with. You can choose any of the 20 preset slots or the Last listened. Volume: You can set the volume at which the alarm sound should be played. -
Page 26: Wireless Network Connection (Wlan)
• Turn [NAVIGATE/ENTER/VOLUME] to switch amongst PIN setup the networks discovered. At the bottom of the list are • Select your desired network. (Indicated by the prefix options to restart the search ("[Rescan]") or configure "[WPS...]") the connection yourself ("[Manual config]"). •... -
Page 27: Manual Configuration Of Network Connection - Wireless (Wlan)
17.2.3 Manual configuration of network connection – 17.2.5 Network profile wireless (WLAN) The radio automatically saves all successful network • To manually configure a network connection, proceed connections (profiles). This means that re-establishing these as follows: connections (for example, after the radio was disconnected •... -
Page 28: Time/ Date Settings
17.3 Time/ Date settings 17.4 Language To access the time settings, proceed as follows: The first time it is used, the radio's default language is German. • Press [ ] (4) to go to the system settings. To change radio's menu language, proceed as follows: •... -
Page 29: Software Update
17.6 Software updates. Note 17.9 Lighting • Available updates and instructions on how to install them can be found at: www.hama.com -> 00054893 The backlight can be configured for each operating mode (Operation Mode, Standby Mode) separately. 17.7 Info... -
Page 30: Auto Standby
The first time you switch on an UNDOK-enabled product Note from Hama, or when you have set it to the factory settings, • For reasons of environmental protection and to save it creates a micro access point – a separate Wi-Fi network valuable raw materials, the radio automatically switches that you can connect to with your tablet or smartphone. -
Page 31: Procedure For Android Users
Hama product (for example, Setup Hama DIR3120LED) should be listed here. Tap the corresponding Wi-Fi network. Hama GmbH & Co KG assumes no liability and provides no • Now choose a name for the radio (for example, Office warranty for damage resulting from improper installation/... -
Page 32: Declaration Of Conformity
22. Declaration of Conformity Hama GmbH & Co KG hereby declares that the radio equipment type [00054893] is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.hama.com- > 00054893- > Downloads. - Page 33 Bluetooth SIG, Inc. and ® any use of such marks by Hama GmbH & Co KG is under license. Other trademarks and trade names are those of their respective owners. All listed brands are trademarks of the corresponding companies. Errors and omissions excepted,...
