nvent Raychem NGC-UIT-ORD Conversion Instructions

NGC-UIT-ORD to NGC-UIT2-ORD
Conversion Instructions
KIT CONTENTS
Qty Description
2 9 Pin D-Sub to 10 pin terminal block Phoenix Contact
1 12 Vdc Power Supply
2 Serial Communication cables,
10 ft.
3
Alarm Relays – 12 V, 12 A, SPDT
3 Alarm Relay Sockets
1 NGC-UIT2-ORD and mounting
hardware (12 Kep nuts, 6/32 in)
1 DIN35 Rail, 10 inches
1 Template for replacing UIT1
with UIT2
3 Ground Terminal Blocks
4 End Clamps
Optional–To be purchased separately–UIT2 Window Kit P/N
T1011164
DESCRIPTION
These instructions will guide the installer on how to convert from
nVent RAYCHEM NGC-UIT-ORD to nVent RAYCHEM NGC-UIT2-ORD and
are intended only for personnel experienced in panel constructions.
This kit can also replace a NGC-UIT-OUT if installed in a nonhazardous
area. If installed outdoors in nonhazardous area, then a protective cover
is required.
Part
Manufacturer Number
2315162
Lambda DSP60-12
L-Com CSMN9MF-10
TE Connectivity RTB14012F
TE Connectivity RT78724
nVent 10332-013
N/A
nVent
Phoenix Contact 3031238
Phoenix Contact 0800886
TOOLS REQUIRED
Masking tape
•
• 3/8 drill bit
• In-line torque wrench with 8mm (5/16 in) socket
• Jig saw (recommend using carbon steel blade with 24TPI)

SPECIFICATIONS

General
Area of Use Nonhazardous, indoors or outdoors
(IP65, Type 4)
Supply Voltage 9 – 30 Vdc, 3.6 – 1.2 A
Operating Temperature –30°C to 60°C (–22°F to 140°F)
Storage Temperature –30°C to 80°C (–22°F to 176°F)
Dimensions 279 mm W X 229 mm H X 70 mm D
(11 in. W X 9 in. H X 2.75 in. D)
Alarm Outputs
Transistor open collector Three open collector outputs, with a range of
outputs 5 – 30 Vdc with a max. sink current of 500 mA
Use to drive external relays Relays may be assigned for alarm outputs.
LCD Display
Display LCD is a 8.4 in. XGA, color TFT transflective
device with integral LED backlight
Touch Screen 5-wire resistive touch screen interface for
user entry
Network Connection
Local/Remote Port RS-232/RS-485 ports may be used
to communicate with host computers
(nVent RAYCHEM Supervisor Software) or DCS
Local RS-232 A non-isolated, 9 pin D sub male
Remote RS-485 #2 2-wire isolated, 9 pin D sub male
Data Rate 9600 to 57600 baud.
Maximum cable length For RS-485 not to exceed 1200 m (4000 ft).
Cable to be shielded twisted pair.
Field Port RS-485, 2-wire isolated. Used to communicate
with external devices, such as NGC-30-CRM
and RMM2. Maximum cable length not to
exceed 1200 m (4000 ft). Cable to be shielded
twisted pair.
Field RS-485 #1 2-wire isolated, 9 pin D sub male
Data Rate To 9600 baud
LAN 10/100 Base-T Ethernet port with Link and
Activity
Status LEDs USB Ports USB 2.0 Host port Type A recep-
tacle (X2)
• #16 (3/16) drill bit
• Metal file
