Chapter A — Specifications

Physical and Environmental Specifications

82
This sections lists the physical and environmental specifications for
the CT50 -Ex.
Physical Dimensions
Length:
Width:
Depth:
Weight (with battery):
umble and Drop Specifications
Tumble specification:
Drop specification:
Power and Electrical Specifications
Ex-Battery Pack:
Electrical rating:
Temperature and Humidity Specifications
Operating temperature:
Storage temperature:
Relative humidity
(operating):
Environmental rating:
160 mm
82.5 mm
19 mm
342 g (including battery)
1000 1 m tumbles
5 ft multiple drops to unyielding steel plate, -10
to +50 °C temperature range and 4 ft drop at
20 ° C
Rechargeable Lithium-ion 3.6 V, 4040 mAh
battery
5 V, 2 A
- 20 °C to +50 °C (-4 °F to 122 °F)
-30 °C to 70 °C (-22 °F to 158 °F)
0% to 95% non-condensing
IP67, Category 1
