Summary of Contents for Ecom Smart-Ex 01
- Page 1 Smart-Ex 01 | Ex-Handy 09 ® Safety Instructions...
-
Page 2: Table Of Contents
13. EU Declaration of Conformity and Certificate ........... 12 Note: The current safety instructions, operating instructions, EU Declaration of Con- formity and the Certificate of Conformity can be downloaded from the relevant product page at www.ecom-ex.com, or alternatively they can be requested di- rectly from the manufacturer. -
Page 3: Application
1. Application 1.1 ATEX & IECEx The Smart-Ex 01 and Ex-Handy 09 are intrinsically safe water-, dust- and im- pact resistant Smartphones for industrial application in areas with an increa- sed risk of explosion in zone 1, zone 2, zone 21 and zone 22 in accordance with directives 1999/92/EC, 2014/34/EU (ATEX) and the IECEx System. -
Page 4: Safety Regulations
4. Safety regulations Use of the intrinsically safe Smartphone Smart-Ex 01 or Ex-Handy 09 assumes that the operator observes the conventional safety regulations and has read the certificate of conformity in order to eliminate malfunction of the device. The following items are to be observed: Operating conditions: •... -
Page 5: Ex-Data
Voltage Um of the Safety Box “SB S01”; Um=29V Accessoires: • Only accessories approved by ecom instruments GmbH may be used or intrinsically safe accessories applying to the relevant entity parameter for the audio jack as stated in document 500055EX05A. -
Page 6: Nec & Cec
Protection class: IP68 (for 30 minutes, 2 meters under water) SAR: max. 0.350 W/kg (10g) Smart-Ex 01 max. 0.327 W/kg (10g) Ex-Handy 09 Inserting the SIM Card: 1. Remove the screws of the headset port cover and the SIM card cover with the provided Multitool “MT S01”... - Page 7 Notice: Insert SIM card tray as shown to avoid damage to the card. This information is also shown on the protection film affixed to the display of the Smartphones. For optimal use of the touch screen you should remove the protection film before using the Smartphone for the first time.
-
Page 8: Charging The Smartphone
Ex-protection as well as the war- ranty is void. In case the lithium-ion battery in Smart-Ex 01 or Ex-Handy 09 has to be re- placed only by ecom instruments GmbH or by personnel or service centers authorized by ecom instruments GmbH, and must be recycled or disposed of separately from household waste. -
Page 9: Repair
100 °C. 9. Repair Repairs are to be conducted by ecom instruments GmbH or by personnel or service centers authorized by ecom instruments GmbH, because the safety of the device needs to be tested after repairs are implemented. -
Page 10: Warranty And Liability
Directive 2002/96/EC. Please follow local regulations for the disposal of electronic products. The costs associated with returning devices to ecom instruments GmbH are to be borne by the sender. In accordance with Article 1, Section 18 and Article 2 of the Act revising the law of Waste-Related Product Responsibility for Batteries and Accumulators (Gesetz zur Neuregelung der abfallrechtlichen Produktverantwortung für... -
Page 11: Eu Declaration Of Conformity And Certificate
13. EU Declaration of Conformity and Certificate The EU declaration and the certificate of conformity is enclosed with the sales packaging as a separate document. Please also observe the information provided underneath the table of contents. - Page 12 GmbH prior written consent. The contents of this document are presented as they currently exist. ecom instruments GmbH does not provide any express or tacit guarantee for the correctness or completeness of the contents of this docu- ment, including, but not restricted to, the tacit guarantee of market suitability or fitness for a specific purpose unless applicable laws or court decisions make liability mandatory.
