Summary of Contents for Ecom i.roc Ci70-Ex

  • Page 1 Intrinsically Safe PDA i.roc Ci70 -Ex ® Manual...
  • Page 2: Table Of Contents

    Content Before You Begin �������������������������������������������������������������������������������������������������������������� 7 Global Services and Support ������������������������������������������������������������������������������������������� 7 Who Should Read This Manual ���������������������������������������������������������������������������������������� 7 1 About the Computer Features ................8 About the i�roc® Ci70 -Ex Mobile Computers ����������������������������������������������������������������� 9 Overview of i�roc® Ci70 -Ex Features ����������������������������������������������������������������������������� 9 About the Status LEDs ���������������������������������������������������������������������������������������������������...
  • Page 3 Title Bar Status Icons ������������������������������������������������������������������������������������������������������� 23 Connect to a Bluetooth Audio Device ������������������������������������������������������������������������������ 42 Align the Screen ��������������������������������������������������������������������������������������������������������������� 26 Create an ISP Connection ������������������������������������������������������������������������������������������������ 43 About Intermec Applications�������������������������������������������������������������������������������������������� 26 Create a VPN Server Connection ������������������������������������������������������������������������������������� 44 Applications Available on the Mobile Computer ������������������������������������������������������������� 26 About Wireless Security ���������������������������������������������������������������������������������������������������...
  • Page 4: Before You Begin

    Standard Communications ���������������������������������������������������������������������������������������������� 66 Warranty Information Optional Communications������������������������������������������������������������������������������������������������ 66 To understand the warranty for your ecom instruments product, visit the ecom instru- Wireless LAN �������������������������������������������������������������������������������������������������������������������� 66 ments website at www�ecom-ex�com and click Support� Disclaimer of warranties: The sample code included in this document is presented for Regulatory Approvals �������������������������������������������������������������������������������������������������������...
  • Page 5: About The Computer Features

    Ci70 -Ex Mobile Computers ® The ergonomically designed ecom instruments i�roc® Ci70 -Ex Mobile Computers are built on the Microsoft Windows Embedded Handheld operating system� They are easy- to-use, and run most software developed for the Windows Embedded platform, includ- ing standalone, client-server and browser-based applications�...
  • Page 6: About The Status Leds

    15 minutes to load your language� ® Make sure you select the correct language before you tap Provision� If you need to have the language provisioning changed, you will need to send your computer to an ecom Location of the i.roc Ci70 -Ex Status LEDs instruments Global Repair Center�...
  • Page 7: About Battery Status

    Batteries that are stored outside the computer for long periods of time slowly dis- hours before changing batteries� charge� ecom instruments recommends storing the battery in a charger to maintain battery performance� Battery is low� You need to charge or replace the battery soon�...
  • Page 8: About The Keypad

    Enter Characters on the Numeric Keypad Store the computer If you are storing the computer for a few days, like over the You need to use the orange modifier key b and the green modifier key c to access all for more than a day�...
  • Page 9: About The Intermec Dashboard Button

    Make sure you completely close the card access door before you use your computer� Manual� About the Intermec Dashboard Button ecom instruments recommends using the following microSD cards: If the Ready-to-Work light blinks, your computer may be experiencing a problem� Press the Intermec Dashboard button (m) to launch the Intermec Dashboard application and view troubleshooting and status information�...
  • Page 10: Transfer Files To And From Your Pc

    To establish a partnership between your computer and a PC, you need to physically con- nect your computer to your PC using these accessories: • ecom Single Dock Art.-No. AS030301 or • Intermec Desktop Dock equipped with Ci70 computer cup...
  • Page 11: About The User Interface And Intermec Applications

    About the User Interface The user interface for the Windows Embedded Handheld 6�5 operating system is dif- ferent from previous versions of Windows Mobile� The interface is touch-friendly and easy to navigate� Use the following sections to understand how to interact with Windows Embedded Handheld 6�5�...
  • Page 12: Interact With The Screen

    Title Bar Status Icons A horizontal scroll bar appears when you tap an icon in the Title bar� This horizontal scroll bar makes it easy to access the applications associated with the Tile bar icons� The hori- Tappable icons in the Title bar immediately show you the status of your network, your zontal scroll bar also contains a magnifier which improves the touch experience by mak- phone, the volume, the battery, and the time�...
  • Page 13 Connecting to a GPRS network� There is no SIM card present in the computer� A GPRS connection is active� The volume is on� An HSDPA network is available� The volume is off� Connecting to an HSDPA network� The battery has a full charge� An HSDPA connection is active�...
  • Page 14: Align The Screen

    2 Follow the prompts on the screen to complete the alignment process� About Intermec Applications ecom instruments provides many useful applications to help you configure, trouble- shoot, and connect your computer to other devices and networks� You can also down- load additional applications from the Intermec website to help you use all of the fea- tures of your computer�...
  • Page 15: Activate The Umts Module

    The following table • UMTS lists the carriers that ecom instruments currently supports� If your carrier is not listed in the table, please contact ecom instruments product support to see if it is now sup- ported� Note:...
  • Page 16 If the update is successful, the Carrier Selection screen appears and displays the up- dated carrier information� If the update is unsuccessful, a message box appears� Tap Ok to return to the Carrier Selection screen� If you are switching to a CDMA network, or switching from a CDMA network to a UMTS network, you must add the WWAN con- nection in Intermec Settings�...
  • Page 17: About The Integrated Gps On Your Computer

    Improve GPS Performance on the Computer Use the iGPS application to improve the performance of the GPS on your i�roc® Ci70 -Ex ecom instruments recommends that you use the GPS Intermediate Driver (GPSID) in- computer� The integrated GPS module has three operating modes: stead of directly accessing the GPS hardware�...
  • Page 18: Configure The Computer

    How to Configure the Computer You can configure many parameters on the computer such as the bar code symbologies it decodes or the network settings� The values you set for these parameters determine how the computer operates� There are several ways to configure the computer: •...
  • Page 19 you see ��� next to a menu option, there is only one more screen available� Profile Settings Application • Power Most parameters are saved as soon as you tap OK� Some settings such as the Serial • Scanning Port Switch require you to reboot the computer for the changes to take effect� Screen •...
  • Page 20: Navigate In Intermec Settings

    Navigate in Intermec Settings Device Monitor Menu You can easily navigate through the screens in Intermec Settings to find the parameter you need to configure. Device Monitor Options Parameters You Can Configure To move down a level in Intermec Settings: Device Health Controls •...
  • Page 21: Use Intermec Settings Remotely With Smartsystems Foundation

    Note: Configure Bluetooth Communications When you restore default settings in Intermec Settings, only the settings for visible Your mobile computer is Bluetooth™-enabled, which lets you connect to other Blue- items are restored to defaults� The settings for hidden menu items are not affected� tooth devices, such as scanners, printers, or audio devices�...
  • Page 22: Connect To A Bluetooth Printer

    3 Select Quick Connect, Search, or Man- 1 Tap Start > Settings > System > Bluetooth ual� Follow the onscreen instruction to Audio� add a wireless scanner� 2 Tap Search to find your Bluetooth headset or hands-free device� 3 Select your device from the list and config- ure any settings�...
  • Page 23: About Wireless Security

    Make sure the communications and radio parameters on your 70 Series are configured. This section explains how to configure wireless security on your mobile computer. ecom Make sure Funk is selected as your security choice� instruments recommends that you implement WPA2 security using PSK (Personal) or Start Intermec Settings�...
  • Page 24 Configure Static WEP Security With Funk Security Choose Communications > 802�11 Radio > Funk Security� Use the following procedure to configure static WEP security with Funk. ecom instru- Select the profile you want to configure. ments recommends that you use WPA2-PSK instead of WEP if possible�...
  • Page 25 Configure 802.1x Security with Microsoft From the Security Choice list, select Microsoft Security� An alert box Use the following procedure to configure 802.1x security with Microsoft security. ecom appears telling you that you must save your settings and reboot the instruments recommends that you use WPA2-802�1x instead of 802�1x-WEP if possible�...
  • Page 26: Load A Certificate

    2 Go to Start > Settings > System > Intermec Settings� Use this chapter to learn how to remotely update, configure and monitor your ecom instruments mobile computers. You will also find information on installing and devel- 3 Tap Communications > 802�11 Radio >...
  • Page 27: Manage The Computer In Your Network

    For very simple applications, the executable file may be the only file you need to de- ploy. More typically, you will have a set of files to install. ecom instruments recommends using .cab files to install your applications. The com- puter uses standard Windows Mobile .cab files and will install third-party .cab files.
  • Page 28: Install Applications Using Microsoft Activesync

    The console is part of SmartSystems Foundation and Your mobile computer may restart several times during this process� When the is available from the ecom instruments website� Before you can update your mobile update is complete, the Autoflash Complete message appears.
  • Page 29: Troubleshoot And Maintain The Computer

    802�1x security, the imager, or general problems with operating the mobile computer� If you send the computer in for service, it is your responsibility to save the computer data and configuration. ecom instruments is responsible only for ensuring that the hardware matches the original configuration when repairing or replacing the computer�...
  • Page 30: Troubleshoot 802.1X Security

    Follow the next procedure to verify available access points and networks, check signal strength, and view other diagnostics� If you need to contact ecom instruments Product The computer appears to be con- There may be a problem with the connection between the...
  • Page 31: Troubleshoot Reading Bar Codes

    Press the right arrow button to view any recommended settings� buttons or pull the trigger again without scanning a bar To accept the recommended settings, tap Apply� code label� If the light is still on, contact your local ecom Tap OK to exit� instruments representative�...
  • Page 32: Find Your Configuration Number

    Wait while the mobile computer boots� When the cold boot is complete, The accelerometer does You may need to calibrate the accelerometer using the Sensor Cali- the Home screen appears� not appear to be accurate� bration application� Tap Start > Settings > System > Sensor Calibra- tion�...
  • Page 33: A Specifications And Default Settings

    Physical and Environmental Specifications i.roc Ci70 -Ex Physical Dimensions ® Dimensions standard configuration 225 x 85 x 58 mm (8�8 x 3�3 x 2�3 inches) with optional head modules 249 x 85 x 58 mm (9�8 x 3�3 x 2�3 inches) Weight standard configuration 980 g (2�16 lb) with battery...
  • Page 34: Touch Screen Specifications

    Use device settings to configure settings on the mobile computer. Communications Settings Device Settings Communications Setting Default Value Device Setting Default Value ecom instruments CXXX (where Date Device Name XXX indicates the model of mobile Time computer) 802�11 Radio Settings Good Read Settings 802�11 Radio Setting...
  • Page 35: Core Messaging Service Settings

    Backlight Settings Profiles Settings Application Backlight Setting Default Value Profiles Settings Default Value Display Backlight Adjustment Normal Camera Keypad Backlight On Based on Light Level Disable Camera Scan Show Option in Profile Settings Light Level Enable Camera Scan Show Option in Profile Settings Power Screen Settings Always On...
  • Page 36: Head Modules Settings

    Set Rule File Location \SmartSystems\HealthRules.txt System Device Health Refresh (seconds) Network Device Health Refresh (seconds) Device Health Screen Captures Device Health Screen Captures Setting Default Value Directory \SmartSystems\ScreenCapture Screen Captures Allowed Device Wipe Device Wipe Setting Default Value Keypads and Keystrokes Enable Wipe Disabled Head Modules Settings...
  • Page 37: Standard Characters

    Standard Characters c 1 3 c 1 3 3 Use the following tables to learn how to enter standard and other available characters and functions with the keypad� If there is no sequence of keystrokes for a particular c 1 3 3 3 character or function, it is only available through the soft input panel (SIP), which you c 1 4 can access by tapping the keyboard icon on the touch screen�...
  • Page 38 i.roc Ci70 -Ex Characters and Funktions ® To Enter Numeric Keypad QWERTY Numeric Keypad @ (at symbol) & (ampersand) * (asterisk) : (colon) , (comma) $ (dollar) ! (exclamation) - (hyphen) % (percent) � (period) + (plus) # (pound) ? (question mark) ‘...
  • Page 39 Garantie der Markttauglichkeit und der Eignung für einen bestimmten Zweck, es sei denn, anwendbare Gesetze oder Rechtsprechungen schreiben zwingend eine Haftung vor. Die ecom instruments GmbH behält sich das Recht vor, jederzeit ohne vorherige Ankündigung Änderungen an diesem Dokument vorzunehmen oder das Dokument zurückzuziehen.
