VERIFY THE CONTENTS INSIDE PACKAGE BOX
The package should contain the items plus NVR-401. If any item is missing or damaged, please contact the seller immediately
Quick Installation Guide
STEP 1 : Physical Installation
Install the Hard Disk Drive
1. Remove the screws on the bottom.
3. Connect the SATA bus cable and power cable to the HDD.
Quick Guide
CD-ROM
Power Cord
Power Adapter
RJ-45 Cable
2. Pull out the case inside.
NVR-401
8 x HDD Screw
Advertisement
Table of Contents
Related Manuals for Planet NVR-401
Summary of Contents for Planet NVR-401
-
Page 1: Quick Guide
NVR-401 VERIFY THE CONTENTS INSIDE PACKAGE BOX The package should contain the items plus NVR-401. If any item is missing or damaged, please contact the seller immediately Quick Installation Guide CD-ROM Power Cord Power Adapter RJ-45 Cable 8 x HDD Screw... - Page 2 Further configurations and information can be found in the user’s manual CD. Please check the user’s manual for more information. Quick Guide PLANET Technology Corporation 11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C. Tel: 886-2-2219-9518 Fax: 886-2-2219-9528 Email: support@planet.com.tw www.planet.com.tw 2011-AB5280-000 their respective owners. Copyright © 2010 PLANET Technology Corp. All rights reserved.
