DHP Maven Platform Bed 4124019 Instruction Booklet

DHP Maven Platform Bed 4124019 Instruction Booklet

Twin with storage

Advertisement

TM
Weight Limit: 225 Lb / 102 Kg
N.C. - 4/3/2017
© 2014 Dorel Home Products All Rights Reserved
Maven Platform Bed With Storage
Thank you for purchasing from DHP!
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/support-home
or call Toll-Free 1-800-267-1739
Date of Purchase
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
4124019
Black Faux Leather
Lot Number
B34412401900 - 10125-M
Twin
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Maven Platform Bed 4124019 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DHP Maven Platform Bed 4124019

  • Page 1 Twin Black Faux Leather Weight Limit: 225 Lb / 102 Kg Thank you for purchasing from DHP! DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge.
  • Page 2 Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and ● Call our toll free number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of ●...
  • Page 3 B34412401900...
  • Page 4 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Headboard Footboard Side Panel Side Panel Side Rail T946240 T946250 T946260 T946270 T946280...
  • Page 5 Parts Replacement Parts, Visit www.dhpfurniture.com/eng/support-home All in 1 big box! There are inner box(es) that include components required to complete this assembly. Drawer Back Panel Before you throw the package, please use the Front Panel Drawer Bottom Panel Drawer Side Panel T946400 T946380 T946390...
  • Page 6 Hardware Pack Hardware Pack #: T4124019-00 1/4" X 3/4" 1/4" X 3/4" X 13 1/4" X 1 3/16" 1/4" X 1 9/16" 1/4" X 1 9/16" X 21 6# X 1/2" 1/4" 4# X 1 3/16" X 20 Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions.
  • Page 7 Step 1 Attach Z X 2 and F X 2 to C and D with Note: Holes on part F should be facing upward X 10 B34412401900...
  • Page 8 Step 2 1st choice for Drawer location Note: You have two choices for the drawer location as illustrated. If you intend to place the drawer in the 1st location, then: Attach V to U and C with If you intend to place the drawer in the 2nd location, then: Attach V to U and D with 2nd choice for Drawer location B34412401900...
  • Page 9 Step 3 1st choice for Drawer location 1st choice for drawer location: Attach E to D with 2nd choice for drawer location: Attach E to C with 2nd choice for Drawer location B34412401900...
  • Page 10 Step 4 Attach I to B with B34412401900...
  • Page 11 Step 5 5.1 Attach Z X 2 to A with 5.2 Attach E and V to B with 2nd choice for Drawer location 1st choice for Drawer location B34412401900...
  • Page 12 Step 6 Insert Gx2 into M with B34412401900...
  • Page 13 Step 7 Attach Gx2 to A and B with Note: We will continue to show the assembly with the drawer placed in 1st location. If you intent to assemble the drawer in the 2nd location please follow the same steps. B34412401900...
  • Page 14 Step 8 Attach H to C and D with Note: small tubes on part H should be orientated as illustrated, facing toward B. B34412401900...
  • Page 15 Step 9 Attach R to E, G and V with Note: arched side on R must be facing upward. B34412401900...
  • Page 16 Step 10 10.1 Insert O into X; 10.2 Press X into E, V and F, repeat the same procedure for the opposite side. 10.3 Insert ends of both slats O into Y, then press Y into G as illustrated. Repeat the same procedures going backwards for every row of slats.
  • Page 17 Step 11 Attach Nx2 to S and L with Note: before assembling, line up the screws and holes on N with pilot holes on S and L. Note: For a better looking and for ease of assembly, orientate ALL PANELS with the staples and pilot holes facing toward the outside and on upper side.
  • Page 18 Step 12 Attach K to S , L and N with Note: For a better looking, orientate the staples toward the outside. Note: before assembling, line up the screws and holes on K with pilot holes on N, S and L. X 12 B34412401900...
  • Page 19 Step 13 Attach Qx4 to K with Note: before assembling, line up screws and holes on Q with pilot holes on K. B34412401900...
  • Page 20 Step 14 Turn over sub-assembly from previous step and: 14.1 Attach to J where indicated; 14.2 Attach sub-assembly N, L and S to J with 14.2 14.1 B34412401900...
  • Page 21 Step 15 Align the drawer and then push it in. Lock drawer by slightly lifting drawer and inserting the Pin into the Slot. 1st choice for Drawer location Slot 2nd choice for Drawer location B34412401900...
  • Page 22 ● Move your new furniture carefully, with two people lifting and carrying the unit to its new location. ● Your DHP furniture can be disassembled and reassembled to move. ● Some parts have been pre-assembled for this item. They are illustrated on this page and available for replacement.
  • Page 23 Garantía Gracias por su compra DHP! DHP garantiza que este producto está libre de defectos de material y de fabricación, comprometiéndose a corregirlos en caso de ser hallados. Esta garantía es valida por Registra tu producto y participa para ganar! un año a partir de la fecha de compra original.
  • Page 24 Partes Lea antes de comenzar a ensamblar ● Llame a nuestro número gratuito si necesita asistencia. Piezas de reemplazo, visite www.dhpfurniture.com/spa/support-home ● Trabaje en un área espaciosa y cerca de donde su producto será utilizado, preferiblemente sobre una alfombra o utilice el cartón del empaque para proteger su piso y su producto.
  • Page 25 Paso 5 llevando el aparato a su nueva ubicación. 5.1 Una Z X 2 con A usando ● Sus muebles DHP se pueden desmontar y volver a ensamblar en caso de 5.2 Una E y V con B usando mudanza.
  • Page 26 Garantie Merci d'avoir acheté un produit de DHP ! DHP garantit que ce produit est exempt de tout vice de matériaux et de fabrication et Enregistrez votre produit et s'engage à remédier à un tel défaut. Cette garantie couvre un an à compter de la date d'achat originale.
  • Page 27 Pièces Avant de commencer l'assemblage ● Si vous avez besoin d'aide, appelez notre service à la clientèle sans frais. Pièces de rechange, visitez www.dhpfurniture/fre/support-home ● Travailler dans un endroit spacieux et près du lieu où l'unité sera utilisée, préférablement sur un tapis, ou sur un morceau de l'emballage pour protéger le Tout dans 1 grosse boîte! plancher et le produit.
  • Page 28 5.1 Attacher Z X 2 à A avec ● Votre mobilier DHP peut être démonté et reassemblé pour faciliter les 5.2 Attacher E et V à B avec déménagements.
