53-1003885-01
5 October 2015























Brocade 6542 Blade
Server SAN I/O Module for
Inspur Shangri-la Chassis

Hardware Reference Manual




Supporting Fabric OS 7.4.0_ins







Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6542 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brocade Communications Systems 6542

Summary of Contents for Brocade Communications Systems 6542

  • Page 1                           Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis   Hardware Reference Manual         Supporting Fabric OS 7.4.0_ins        ...
  • Page 2   The authors and Brocade Communications Systems, Inc. assume no liability or responsibility to any person or entity with respect to the accuracy of this document or any loss, cost, liability, or damages arising from the information contained herein or the computer programs that accompany it.

  • Page 3: Table Of Contents

    Inserting optical transceivers and cables ......... 27 Configuring the Switch Module ..................... 29 Switch module configuration ................ 29 Items required for configuration ..............29 Default roles....................30   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 4 Brocade 6542 Blade Server SAN I/O Module Technical Specifications ........ 53 Caution and Danger Notices ....................59 Cautions ..................... 59 Danger notices ................... 59   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 5: Preface

    In Fibre Channel products, a fixed value provided as input to a command option is printed in plain text, for example, --show WWN.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 6: Notes, Cautions, And Warnings

    A Danger statement indicates conditions or situations that can be potentially lethal or extremely hazardous to you. Safety labels are also attached directly to products to warn of these conditions or situations.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 7: Brocade Resources

    • OEM/Solution Providers are trained and certified by Brocade to support Brocade products. • Brocade provides backline support for issues that cannot be resolved by the OEM/Solution Provider.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 8: Document Feedback

    Provide the publication title, part number, and as much detail as possible, including the topic heading and page number if applicable, as well as your suggestions for improvement.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 9: About This Document

    16-Gbps FC ELWL 25 Km       NOTE For the latest list of supported device models, transceivers, and cables, contact Inspur or your solution provider.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 10 Supported hardware and software       Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 11: Switch Module Overview

    Hardware features     The Brocade 6542 Gen-5 16-Gbps FC switch module/blade server SAN I/O module provides the following hardware features:   • Up to 16 16-Gbps external Fibre Channel ports to connect with external FC storage or an FC switch.

  • Page 12: Fabric Os Native Mode And Access Gateway Mode

    The single switch ASIC design eliminates blocking, guaranteeing full transmit and receive bandwidth to all Fibre Channel ports at all times.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 13: Ports On Demand

        If your Brocade 6542 16-Gbps FC Switch Module has a Brocade ISL Trunking license, external ports can form trunking groups of Inter-Switch Links (ISLs) between adjacent switches. ISL trunking allows up to eight ports between a pair of switches to be combined to form a single, logical ISL with an aggregate speed of up to 128 Gbps for optimal bandwidth utilization and load balancing.

  • Page 14: Supported Licenses

    4, 8, and 16 Gbps links are available.       NOTE A bundle license is also supported which includes ISL, FV, and EXF.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 15: Port-Side View

      The following figure shows the port-side view of the switch module.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 16 SFP+ external ports 45-47 and 0 10 Fan 2 FC port 45 status LED 11 Fan 2 status LED FC port 45 fault LED 12 Fan 2 fault LED   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 17: Nonport-Side View

    Nonport-side view     The nonport side of the Brocade 6542 Gen-5 16-Gbps FC switch module is not externally visible and it is internally plugged into the Inspur Shangri-la Blade Server chassis backplane.   The nonport side of the switch module is seated in the chassis. The switch module seats correctly when the insertion arm is closed.

  • Page 18: Sfp+ Optical Transceivers

          SFP+ optical transceivers     The Brocade 6542 16-Gbps FC Switch Module is designed to work with SFP+ optical transceivers. The switch module ships with two 16-Gbps Brocade-branded SFP+ transceivers by default.       NOTE You can also install 8-Gbps SFP transceivers in the switch module. All SFP transceivers must be Brocade-branded.
  • Page 19 (LWL) connections. Replace SFP transceivers with a new pluggable unit rather than replacing the switch module. Refer to the manufacturer’s instructions when installing SFP transceivers.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 20 SFP+ optical transceivers       Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 21: Installing The Switch Module

    Shipping carton contents     The following items are included in the shipping carton:   • One Brocade 6542 16-Gbps FC Switch Module/Blade Server SAN I/O module with two SWL 16- Gbps SFP+ transceivers pre-installed • China RoHS statement    ...

  • Page 22: Installation And Safety Considerations

    Installing multiple switch modules   The Inspur Shangri-la Blade Server chassis supports up to four Brocade 6542 16-Gbps FC Switch Modules. The first switch module that you install must be assigned a unique Ethernet IP address during configuration. After the default Ethernet IP address on the first switch module has been changed, you can install additional switch modules in the Inspur Shangri-la Blade Server chassis.

  • Page 23: Electrical Considerations

      • The blade server is powered up. • The I/O module bay into which the Brocade 6542 16-Gbps FC Switch Module will be inserted is empty and ready to receive the switch module. • All power requirements specific to the Inspur Shangri-la Blade Server chassis are met.
  • Page 24 3. Switch module slot 3 4. Switch module slot 4 2. Orient the switch module port side facing you so that the fans are at the bottom.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 25 It is recommended that you review the installation precautions and guidelines when handling SFP+ optical transceivers and cables before you insert the transceivers and attach the cables.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 26: Installation And Safety Considerations When Handling Transceivers And Cables

      To avoid damage to the fiber-optic cables, be aware of the following guidelines:   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 27: Inserting Optical Transceivers And Cables

    For instructions specific to a cable type, refer to the cable manufacturer’s documentation. The cables used in trunking groups must meet specific requirements. For a list of these requirements, refer to the Fabric OS Administrator’s Guide.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 28 Inserting optical transceivers and cables       Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 29: Configuring The Switch Module

    GUI, it is recommended that you use that application instead.   You can configure the Brocade 6542 16-Gbps FC Switch Module to operate on a network and fabric. You can also change the switch module’s operating modes (Fabric OS Native mode and Access Gateway mode).

  • Page 30: Default Roles

    1. Log in to the Inspur chassis management GUI application.   2. Expand the System Monitoring menu in the left pane and select Switch Module.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 31 Configuring the Switch Module             FIGURE 5 Inspur - Switch Module Overview page   3. Click the Switch Manage tab.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 32 6. Select the Network Mode option as Static or DHCP. 7. If you selected the Static option, enter the IP addresses in the following fields:   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 33: Using The Cli Menu From The Serial Console Port

    When the terminal application stops reporting information, press Enter to display the login prompt. c) Enter the username and password: Username: admin Password: admin 4. Enter the ipAddrSet command to set the IP address.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 34: Connecting The Switch Module To The Ethernet Network

    NOTE The cables used in trunking groups must meet specific requirements. For a list of these requirements, refer to the Fabric OS Administrator’s Guide.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 35: Changing From Fabric Os Native Mode To Access Gateway Mode

      Login: admin   Password: admin 3. Select the switch module from the fabric tree. The selected switch module appears in the Switch View.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 36: Enabling Access Gateway Mode Using The Cli

    For complete instructions on disabling Access Gateway mode using the CLI and joining the switch to the fabric, refer to the “Disabling Access Gateway Mode” section in the Access Gateway Administrator’s Guide.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 37: Disabling Access Gateway Mode Using The Cli

    1. Open a Telnet session to the serial console. 2. Enter the configUpload command. You are presented with a series of prompts. 3. Follow the prompts to upload the configuration.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 38   For specific instructions about how to back up the configuration, refer to the Fabric OS Administrator’s Guide.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 39: Managing The Switch Module

    Locating serial number information ................52       Managing the device     All features on the Brocade 6542 16-Gbps FC Switch Module can be configured using the CLI and Brocade Web Tools.       Interoperability    ...

  • Page 40: Port Negotiation

    33 through 47 are external ports that can be in F_Port, N_Port, or E_Port mode. The following table describes the factory-default F_Port to N_Port mapping for the Access Gateway mode.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 41: Interpreting Post Results

    If one or more LEDs do not display a healthy state, verify that the LEDs are not set to beacon. Use the switchShow command or Web Tools to verify the LED state. For information about how to turn   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 42: Diagnostic Tests

    Slow flashing amber (2- Disabled (result of diagnostics or portDisable command) second intervals)     Fast flashing amber (1/2- Error (fault with port) second intervals)   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 43: Interpreting Led Activity

    I/O module bay, the LEDs become active.   FC port 45 status LED Fan 1 status LED FC port 45 fault LED Fan 1 fault LED   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 44: Removing And Replacing The Switch Module

    Blade Server chassis open for an extended period of time. The slot must be filled with either a replacement switch module or a filler blade to maintain proper airflow.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 45 5. Press the release latch to free the release lever, and gently pull the release lever out from the switch module. The following figures show the open and unlocked view of the release lever and release latch.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 46           FIGURE 8 Opening the release lever and latch     1. Release lever and latch in the open position   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 47 7. Insert the replacement switch module in the I/O module bay of the blade server chassis. You must complete this step within 60 seconds. 8. Insert the SFP+ optical transceivers. 9. Reconnect the cables.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 48: Removing And Replacing The Fan Modules

    The fan module is ejected from its locked position in the switch module. 3. Pull the fan handle away from the switch module and slide the fan module out of the switch module.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 49 5. Slide the fan module into the switch module until the fan module is firmly seated. 6. Verify that the fan module LEDs are functioning correctly.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 50: Removing And Replacing An Optical Transceiver

    The license key is case-sensitive and must be entered exactly as shown. If the license key includes spaces, you must enclose the entire string in double quotation marks. 3. Take the appropriate action as indicated by the command output.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 51: Upgrading Or Downgrading Software

    9. After the switch module reboots, enter the version command to verify the firmware upgrade.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 52: Determining Installed Software Licenses

    • Locate the serial number on the label attached to the top of the switch module. This label is not visible when the switch module is installed in the chassis.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 53: Brocade 6542 Blade Server San I/O Module Technical Specifications

        Brocade 6542 Blade Server SAN I/O Module Technical Specifications       This section highlights the features and specifications for the Brocade 6542 Gen-5 16-Gbps FC switch module.     Switch module default settings     Setting Description  ...
  • Page 54 FCIP (IP over Fibre Complies with FC-IP 2.3 of FCA profile Channel)     Management     System component Description   RS232 console port RJ-45   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 55 Fan 1 power and status LEDs above Fan LEDs 1. Fan 2 power and status LEDs below Fan     Weight and physical dimensions   Fully loaded Brocade 6542 Gen-5 16-Gbps FC switch module: Two fans and no SFP+ transceivers installed.     Model Height Width...
  • Page 56     10 km (6.2 miles)             62.5 21 m (69 ft)       10 km (6.2 miles)   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 57 Not supported     Serial port specifications (protocol)     Parameter Value   Baud 9600 Data bits Parity None Stop bits Flow control None   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 58 Brocade 6542 Blade Server SAN I/O Module Technical Specifications       Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...

  • Page 59: Caution And Danger Notices

    Ein Gefahrenhinweis warnt vor Bedingungen oder Situationen die tödlich sein können oder Sie extrem gefährden können. Sicherheitsetiketten sind direkt auf den jeweiligen Produkten angebracht um vor diesen Bedingungen und Situationen zu warnen.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
  • Page 60 I de 21 CFR. Los productos ópticos que no cumplan con estos estándares pueden emitir luz dañina para los ojos.   Brocade 6542 Blade Server SAN I/O Module for Inspur Shangri-la Chassis Hardware Reference Manual 53-1003885-01...
