Remote Control, cont'd
The window contains channel mute, front panel lock out
(executive modes), and unit reset controls.
The front panel lockout feature prevents unauthorized
adjustments to the MVC's front panel. See Front panel
security lockout (executive mode) in chapter 2.
Setting output volume range limits
The Master output volume control can be configured with
upper and lower range limits to restrict the volume output.
Setting range limits may prevent possible damage to audio
equipment. From the File drop-down menu, select Advanced
Setup, then select Set Limits.
From the Master output volume range indicator, set the upper
and lower range limits by moving the arrowhead indicators.
After setting the limits, the output volume can only be set
within the specified range limits, as shown below.
www.camboard.de
3-10
MVC 121 • Remote Control
CAMBOARD Electronics
Using the help system
Updating the firmware
Tel. 07131 911201
Fax 07131 911203
For information about program features, you can access the
help program in any of the following ways:
•
From the Extron Electronics program group, double-click
the Audio Products Help icon.
•
From within the Audio Products Control program, click
Help on the task bar.
•
From within the Audio Products Control program, press
the F1 key.
Firmware updates will be available on the Extron Web site. To
load a firmware update:
Download the update file from the Extron Web site
1.
(www.extron.com).
2.
Run the Audio Products Control Program.
3.
On the File menu, click Update Firmware. The Firmware
Loader window appears.
Firmware Loader window
4.
Click the Upload Firmware File button.
5.
Locate and select the update file you downloaded from the
Web site and click Open. The Firmware Loader loads the
update.
The firmware update file must have an .s19 extension. If
it does not have that extension it will not work properly.
6.
When the program is finished loading the update, click
Exit.
ce-info@camboard.de
MVC 121 • Remote Control
3-11
