Remote Control, cont'd
= Input or output to be adjusted (1 – 4)
X2
1 = mic 1
2 = mic 2
3 = main line level
4 = master output
= On/off status
X3
0 = off (mute)
1 = on (unmute)
2 = mute by contact closure
= Input audio gain/attenuation value
X4
( -79 through +12)
= Audio gain (per input)
X5
(0 – 12)
= Audio attenuation (per input)
X6
(1 through 79)
= Controller firmware version (listed to two decimal places,
X7
i.e., x.xx)
= Front panel security lockout (executive modes)
X8
0 = off
1 = mode 1 (lock all front panel controls except master
volume)
2 = mode 2 (lock all front panel controls)
= Rear panel DIP switch settings (0 through 15)
X9
See the following tables.
ON
LINE ON - up
OFF - down
MIC
1 2 3 4
1 2 1 2
X9 = 0 1 2
Level
DIP switch 1
Off Off Off
Mic 1
Level
DIP switch 2
Off Off Off
Mic 2
48V
DIP switch 3 Off Off On
Mic 1
48V
DIP switch 4 Off On Off
Mic 2
0 1 2
X9 =
Level
DIP switch 1
Mic Mic Mic
Mic 1
Level
DIP switch 2 Mic Mic Mic
Mic 2
48V
DIP switch 3 Off Off On
Mic 1
48V
DIP switch 4
Off On Off
Mic 2
www.camboard.de
MVC 121 • Remote Control
3-4
DIP Switch Positions
3 4 5 6 7 8 9 10 11 12 13 14 15
Off Off Off Off Off On On On On On On On On
On On On On Off Off Off Off On On On On
Off
On Off Off On On Off Off On On Off Off On On
On Off On Off On Off On Off On Off On Off On
DIP Switch Functions
3 4 5 6 7 8 9 10 11 12 13 14 15
Mic Mic Mic Mic Mic Line Line Line LineLineLine Line Line
Line Line LineLine Mic Mic Mic Mic LineLine LineLine
Mic
On On Off Off Off Off Off Off Off Off
On Off Off
On Off Off Off Off Off On Off On Off Off Off Off
