- Page 3 Pairing Activate Bluetooth on your mobile phone, and search for available devices. Select “RMD050DAB-BT Caliber”, password “1234”. If successful “Connected” is displayed, if not “Pairing Fail!” will be displayed for 3 seconds. The unit will go back to the previous mode.
- Page 4 RMD050DAB-BT Instruction Manual Silkprint RMD050DAB-BT in silver (Pantone 877C) RMD050DAB-BT Instruction Manual RMD 050DAB- BT Placed s 4X 7 5W DAB+/RDS/USB/SD/AUX/BLUETOOTH • FM Electronic tuning system • Automatic storage of 18 broadcasting stations • FM Electronic tuning system • Support MP3/WMA format •...
- Page 5 Basic operation: Backward music selection/backward broadcasting station search button ( Long press this button for the backward broadcasting station search by step system under the reception state; short press this button for the backward broadcasting station search in a semi- automatic way, and Button 1-6 can be long pressed to preset the storage of broadcasting station after stopping.
- Page 6 incoming message; long press this button to dial the last phone number under the bluetooth state. Display screen Display the reception frequency and current display information. USB Socket Insert the USB flash disk, and the music in corresponding format can be displayed automatically. panel control receiving window It is used to receive the command sent from the panel control.
- Page 7 long press this button for 2s to store the radio station played currently as "1" radio station. Short press this button for pause under MP3 playing state, and short press this button again for playing. 18. Mute button (MUTE) Short press this button for mute and shore press this button again for mute cancellation. 19.
- Page 8 Bluetooth operation: Matching of phone and host Firstly, approach the phone to host and enable the bluetooth of the phone, then, find the bluetooth name of the host "RDM050DAB-BT" (password: 1234) with the phone for connection. When 2s "doduo" prompt tone is sent from the phone, it indicates that the successful connection between the host and phone bluetooth.
- Page 9 Basic RDS operation AF Function When starting the host for the first time, its system will default to be in the RDS (AF) tracking and station selection state automatically; In case the broadcasting station of FM band requires to be listened, RDS (AF) function must be closed at first, otherwise, FM band will not receive the broadcasting station.
-
Page 10: Wiring Diagram
Wiring diagram DAB antenna input (Female SMA connector) Antenna input RCA output (White: Left / Red: Right) (DIN) ISO connector: A1. Rear right speaker(+) / Purple A2. Rear right speaker(-) / Purple-Black B4. Battery 12V (+) / Yellow A3. Front right speaker(+) / Grey B5. - Page 11 sides to make the key to grapple the host, then, pull out gently, after which, the host may be removed from the support; Then, remove the power line and horn line, and unplug the antenna Schematic diagram of installation and dismantling: plug.
-
Page 13: Antenna Installation
ANTENNA INSTALLATION Place the antenna on the windshield near the 'A post' Remove the cover of the A-post Stick the transparant part of the antenna on the windshield and put the black part on the metal frame. Attach to the metal of the car frame.
