#0914 INTIMIDATOR SE3 DD RACING KIT
#0914 INTIMIDATOR SE3 DD RACING KIT
#0914 INTIMIDATOR SE3 DD RACING KIT
#0914 INTIMIDATOR SE3 DD RACING KIT
#0914 INTIMIDATOR SE3 DD RACING KIT
Manufactured By:
Manufactured By:
Manufactured By:
Manufactured By:
Manufactured By:
760-B Crosspoint Drive
760-B Crosspoint Drive
760-B Crosspoint Drive
760-B Crosspoint Drive
760-B Crosspoint Drive
Denver, NC 28037
Denver, NC 28037
Denver, NC 28037
Denver, NC 28037
Denver, NC 28037
www.customworksrc.com
www.customworksrc.com
www.customworksrc.com
www.customworksrc.com
www.customworksrc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intimidator SE3 DD 0914 and is the answer not in the manual?

Questions and answers

Related Manuals for Custom Works Intimidator SE3 DD 0914

Summary of Contents for Custom Works Intimidator SE3 DD 0914

  • Page 1 #0914 INTIMIDATOR SE3 DD RACING KIT #0914 INTIMIDATOR SE3 DD RACING KIT #0914 INTIMIDATOR SE3 DD RACING KIT #0914 INTIMIDATOR SE3 DD RACING KIT #0914 INTIMIDATOR SE3 DD RACING KIT Manufactured By: Manufactured By: Manufactured By: Manufactured By: Manufactured By: 760-B Crosspoint Drive 760-B Crosspoint Drive 760-B Crosspoint Drive...

  • Page 2: Suggested Tools

    The instructions will build the kit using the most verastale set-up Custom Works has found in testing on different types of tracks, however there are various other suspension configurations available to you that you may find more suitable for your local track.

  • Page 3: Front Suspension

    Front Suspension Front Suspension Front Suspension Front Suspension Front Suspension 1293 Qty 1 1287 Qty1 3229 Qty2 3229 Qty2 3229 Qty2 5263 Qty 6 5217 Qty 2 5207 Qty 2 3229 Qty 4 -Parts for INT SE Chassis INT Front Clip Short Body Post Post Collar Set Screw...

  • Page 4: Rear Suspension

    - Assemble the bell crank as shown in the 5253 STEP #2 STEP #3 5235 5281 diagram to the left. Use the thin shims on - Insert the 7224 Axle 5252 5235 3647 the 3646 Steering Post so there is ZERO into the 3213 Steering 7224 slop with the movement of the bellcrank.
  • Page 5 CVD & Drive Assembly CVD & Drive Assembly CVD & Drive Assembly CVD & Drive Assembly CVD & Drive Assembly -Parts for Step#1 3241 Qty 2 1226 Qty 4 4245 Qty 2 1255 Qty 10 5292 Qty 4 Bearing Carrier Ball Bearing Rear Outer Susp Pin Spacer...

  • Page 6: Diff Assembly

    Diff Assembly Diff Assembly Diff Assembly Diff Assembly Diff Assembly -Parts for Step#1 4125 Qty 1 8035 Qty 2 4360 Qty 2 4361 Qty 1 4359 Qty 6 4129 Qty 1 4133 Qty 2 Right Outdrive Diff Ring Thrust Washer Diff Bolt Cover Thrust Balls Diff Bolt...
  • Page 7 Transmission Transmission Transmission Transmission Transmission -Parts for Trans 4121 Qty 1 4122 Qty 1 4123 Qty 1 4124 Qty 1 4131 Qty 2 5262 Qty 5 4382 Qty 2 1290 Qty 1 5252 Qty 5 5253 Qty 2 Left Bulkhead Bearing Carrier L Right Bulkhead Bearing Carrier R...

  • Page 8: Shock Assembly

    Shock Assembly Shock Assembly Shock Assembly Shock Assembly Shock Assembly Bag J Bag J Bag J Bag J Bag J -Parts for Step#1 1425 Med / 1426 Short Qty 2ea 1429 Med / 1430 Short Qty2ea 1250 Qty 8 1435 Qty 6 1434 Qty4...

  • Page 9: Battery Mount

    Battery Mount Battery Mount Battery Mount Battery Mount Battery Mount 1291 Qty 1 8110 Qty 2 3229 Qty2 3229 Qty2 5217 Qty 2 5263 Qty 5 -Parts for Body Post Post Collar Set Screw 4-40 Lock Nut SE Side Mount 4-40 x 3/8 FH Screw Battery Mount...

  • Page 10: Maintenance

    You have now completed the assembly process of your new Custom Works INTIMIDATOR SE3 DD! In the next section of this manual you will find some basic setup hints and advice. It is important to remember that all tracks and racing surfaces are different.
  • Page 11 SET-UP GUIDELINES: SET-UP GUIDELINES: SET-UP GUIDELINES: SET-UP GUIDELINES: SET-UP GUIDELINES: When looking for the “perfect set-up” it is important to remember 2 things... 1) Keeping things simple is best. 2) As you are making your set-up change, the track is changing too! Ask a local racer what the track usually does from begining to end, especially day to night.
  • Page 12 Rear Toe Stagger: Rear Toe Stagger: Rear Toe Stagger: Rear Toe Stagger: Rear Toe Stagger: Difference in the amount of Rear Toe-In among the rear tires. Typically used only on high bite tracks with MORE toe-in on the Left Rear tire than the Right so the rear of the car helps turn the car LEFT under acceleration.
  • Page 13 DRIVER:_______________________________ Clay Hard Packed Loose Dirt DATE:_________________________________ Carpet Asphalt Concrete EVENT________________________________ Flat Banked True Oval Tri-Oval CLASS:________________________________ Traction: High Medium TRACK:_________________LENGTH:_______ FRONT SUSPENSION FRONT SUSPENSION FRONT SUSPENSION SHOCKS SHOCKS SHOCKS SHOCKS SHOCKS FRONT SUSPENSION FRONT SUSPENSION RIGHT LEFT COLLAR TOE IN/OUT LEAD TRAIL CAMBER:____________...
