SW1021A
SW1023A
SW1025A
SW1022A
SW1024A
SW1026A
CUSTOMER
Order toll-free in the U.S.: 877-877-BBOX (outside U.S. call 724-746-5500)
SUPPORT
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
INFORMATION
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
Model Numbers
Complete System with (1) CAT6 path
Complete System with (1) ST Fiber path
Complete System with (1) SC Fiber path
CAT6 upgrade kit – 1 additional path
ST Fiber upgrade kit – 1 additional path
SC Fiber upgrade kit – 1 additional path
2U AUTO-BYPASS
SWITCH
January 2008
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box SW1023A
Summary of Contents for Black Box SW1023A
- Page 1 Order toll-free in the U.S.: 877-877-BBOX (outside U.S. call 724-746-5500) SUPPORT FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 INFORMATION Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
-
Page 2: Specifications
FEDERAL COMMUNICATIONS COMMISSION INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment. - Page 3 2. Introduction The 2U Auto Bypass Switch is a multiple port A/B switch that is designed to automatically switch between a normal network path and a “bypass” or “failover” path for 10/100/1000/10G Ethernet network environments, or multimode fiber based Ethernet environments. It consists of a 2U high, 19 inch rackmount card cage, a power supply card plus external 100-240 VAC power supply module (with an option for a second external power supply module for redundant power), and from 1 to 5 groups of Auto Bypass Switch module cards.
- Page 4 3. Configuration 3.1 A/B Switch Card Configuration Figure 3.1.1 – Typical A/B Switch Card Front & Rear Panels Each A/B Switch Card has an 8-position DIP switch, used to set the card’s address. Switch position 1 is the least significant bit, and position 8 is the most significant bit. Set each switch position ON (as marked) for a '0', and OFF for a '1'.
- Page 5 Table 3.2.1 – Controller Card Rear PC Board Jumper Settings Jumper RJ45 Shield Connected to Frame Ground * Pin 1 to Pin 2 Open Pin 2 to Pin 3 Power Supply Ground 100 Ohm Connection to Frame Ground * Pin 1 to Pin 2 Direct Connection to Frame Ground Pin 2 to Pin 3 * Factory Default Positions...
- Page 6 Table 3.3.1 – Controller Card Front PC Board Jumper W1 and W2 Settings Jumper Gang-In Pin 3 Connected to TXD * Pin 1 to Pin 2 Connected to V+ through 1K Pin 2 to Pin 3 Gang-In Pin 4 Connected to RXD * Pin 1 to Pin 2 Connected to V- through 1K Pin 2 to Pin 3...
- Page 7 • IP address and MAC address of the external Ethernet node that the 2U Auto Bypass Switch is to monitor in order to determine when to switch between the normal and the bypass paths. A value of 0.0.0.0 for the monitor IP address disables the auto bypass and auto recovery switching functions.
-
Page 8: Installation
4. Installation Find a location suitable for installing the 2U Auto Bypass Switch, with access to AC power outlets and the connections you intend to switch through the unit. If you intend to use serial control, connect to the RJ11 Gang In RS232 console port using the supplied DB9 to RJ11 adapter and RJ11 to RJ11 crossover cable. - Page 9 A typical failover application where a redundant or backup connection is required would have the host device connected to one of the “C” ports, with the normal network connection to the respective “B” port, and the failover network connection to the respective “A” port. The 2U Auto Bypass Switch provides two separate A/B switching elements, so two separate host devices can be connected to their own “normal”...
- Page 10 In a typical IPS environment, the NETWORK port on the 2U Auto Bypass Switch would be connected to an unused port on the edge router/switch mentioned in the example configuration in section 4.3 above. To provide auto bypass switching, the 2U Auto Bypass Switch should be configured to use the firewall’s IP and MAC addresses for the monitor IP address and monitor MAC address parameters.
-
Page 11: Operation
5. Operation Whenever the 2U Auto Bypass Switch is powered OFF, or if power fails, the non-latching relays in the 2U Auto Bypass Switch will be in the “A” position, connecting the devices/networks attached to the “A” ports to the “C” ports of both sets of A/B switching elements within the 2U Auto Bypass Switch. -
Page 12: Ethernet Switching
GET[SET] WEBENABLE [ON/OFF] GET[SET] WEBPASSWORD [string] GET[SET] WEBTIMEOUT [N] (seconds) GET[SET] WEBPORT [N] GET[SET] TELNETENABLE [ON/OFF] GET[SET] TELNETPASSWORD [string] GET[SET] TELNETTIMEOUT [N] (seconds) GET[SET] TELNETPORT [N] GET[SET] MONITORIP [X.X.X.X] (0.0.0.0 to disable) GET[SET] MONITORMAC [X X X X X X] (X = HEX CHARS) GET[SET] MONITORINTERVAL [N] (1/10 seconds, 0 to disable) GET[SET] MONITORFAILCOUNT [N] (0 to disable) GET[SET] MONITOROKCOUNT [N] (0 = no auto recover) -
Page 13: Network Setup
6. Network Setup To perform the initial setup of the 2U Auto Bypass Switch you can use a serial terminal capable of 9600 baud, no parity, 8 data bits, and 1 stop bit. Connect this terminal to the RS232 console connector on the 2U Auto Bypass Switch using the supplied DB9 to RJ11 adapter and RJ11 to RJ11 crossover cable. -
Page 14: Console Commands
7. Console Commands The following commands are available from the console prompt of the unit. All commands are case insensitive, although several variable parameters are case sensitive (read/write community names and web password). Many of the command words such as GET, SET, SYSTEM, and PORT can all be abbreviated by the first letter of the command. - Page 15 GET RACK N This command is not supported in the 2U Auto Bypass Switch. If this command is issued to the 2U Auto Bypass Switch it will respond with the following: Rack Status: XXXXXXXXXXXXXXXX GET PORT N Displays the status of A/B switching element N (1-2). The response will be “A” or “B”. Port Status: B SET PORT N A[B] Sets the addressed A/B switching element N (1-2) to position A or B.
- Page 16 SET WEBPASSWORD string GET WEBPASSWORD Set or display the current web password. Note that this is a case sensitive field. Any change will not become permanent until a SAVE operation is performed. SET WEBTIMEOUT seconds GET WEBTIMEOUT Set or display the current web timeout in seconds. After a period of inactivity of this many seconds, the network module will request a login.
- Page 17 whether or not the normal and/or bypass path is operational. This value is entered as a series of six HEX characters with spaces between each HEX character. If monitoring connectivity to a device on the same subnet as the 2U Auto Bypass Switch’s internal Ethernet node, set the monitormac address parameters to the MAC address of the device being monitored.
- Page 18 GET MANAGER N Display SNMP manager N (1-16) IP address. GET MANAGER Display all SNMP manager IP addresses. SAVE Save settings for next startup. All settings are stored in non-volatile memory and restored upon power on. Changes to parameters will not become permanent unless a SAVE operation is performed. (Save followed by reset command) RESET Causes a network system reboot and reloads all parameters from stored settings.
-
Page 19: Web Interface
8. Web Interface The network module provides access to console commands through a web browser interface. When enabled (see SET WEBENABLE command) accessing the default page on the modules IP address (index.html) will present the following page (or similar). Note: If using a pop up blocker on your web browser, be sure to allow pop ups from the IP address of the Auto Bypass Switch, otherwise you could experience trouble receiving a response through the interface. - Page 20 Web Interface Version 1.0 Copyright (c) 2007 All rights reserved. Command console: Output from last command... System Status: X IP Address: 192.168.1.31 Subnet Mask: 255.255.255.0 Gateway IP Address: 192.168.1.1 Web Enable: Enabled Web Password: mctech Web Timeout: 300 Web Port: 80 Telnet Enable: Enabled Telnet Password: dataman Telnet Timeout: 80...
-
Page 21: Snmp Mib Path Summary
9. SNMP MIB Path Summary The following MIB Path Summary shows the variables available on a 2U A/B switching system. [internet] – 1.3.6.1 [private] – 1.3.6.1.4 [enterprises] – 1.3.6.1.4.1 [mctech] – 1.3.6.1.4.1.9477 [mctech] – 1.3.6.1.4.1.9477 private enterprise number [mcAgent] – 1.3.6.1.4.1.9477.1 SNMP Agent [abSwitchSystem] –... - Page 22 A/B Switch System SNMP Variable Definitions: [abSystemGangPort] – 1.3.6.1.4.1.9477.1.4.1 A/B Switch System gang port. This variable is used to control all A/B Switch Cards in the system. A system may consist of up to 255 racks, each rack containing up to 16 A/B Switch Cards.
- Page 23 the card. Each 2U A/B Switch cards in the system MUST have a unique address, in the range of 0x01 to 0xFF hex. Address 0x00 is invalid, and must not be used. This is a read only variable. [abSwitchPort] – 1.3.6.1.4.1.9477.1.4.3.1.2.SwitchIndex A/B Switch Card port.
- Page 24 © Copyright 2007 Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746 24 of 24...
