  • Page 1 Rigging Guide Mainsheet Ratchet Base V1 PLEASE FOLLOW ASSEMBLY GUIDE IN THE CORRECT ORDER...
  • Page 2 Adding the new mainsheet base This retro kit allows you to remove the mainsheet ratchet and add a swivel base easily, which can still be removed to stack boats together. From September 2016 the base adapter plate will be standard on all new boats and the ratchet and ratchet base will come in the customer kit.
  • Page 3 1. How to convert your Aero to accept the new mainsheet ratchet base Remove the two screws then remove the mainsheet block, eyelet and plastic base. Remove the shackle, spring and eyelet from the block. Add some sealant down the two existing holes left by the screws removed in step 1.1.
  • Page 4 Using the mounting bracket as a guide, drill the third hole using a 3mm drill bit. Add sealant and screw down. The screws must be tight If you wish to use the new ratchet base, see step 1.5 - 1.7 for how to add it. If you wish to use a swivel base, move on to section 2.4 Add the eyelet onto the ratchet base.
  • Page 5 Take the new ratchet base, align the three pins with the holes in the adapter plate, then push it down then forwards to lock into place. You should hear a click as the catch engages. 2. How to add a swivel base If you have just completed step 1.1-1.4 and you wish to add a swivel base, move straight on to step 2.4 Using the tool provided release the catch...
  • Page 6 Remove the ratchet block and fittings from the base. Compress the existing spring (as removed in step 2.3 or 1.1) using cable ties then attach the ratchet block onto the eyelet of the new swivel base. Make sure the plastic spring washer goes back on the right way up.
