Initial Settings (Degree Of Acceleration Setting) - Pivot THC-M User Manual

Initial Settings
2
procedure
Make sure to carry out these settings.
When installing for
the first time
Initial
Settings
Before making the "Initial Settings"
1. Make settings only after having completed all wiring (connector installation).
2. Make settings with the
【Making the Settings】
Operational Procedure
1
※1
Key ON.
ON
Engine not
running
2
Press down on the SET
switch for 12 seconds or
longer to change the
display to "0" .
※Upon reaching "0" , a clicking
sound can be heard.
Press until
SET
"0" appears
3
When "0" appears release
the SET switch.
SET
Release
4
Pedal is not pressed down.
(Release the accelerator to 0%)
0
%
5
Press the SET switch.
Set to
SET Press
6
Pedal is completely
pressed down.
(Press in on the accelerator to
100%)
100
%
※1 If the car has standard push start system, follow the User' s Manual of the car to turn the Key to ON.
※2 The values shown in the display will vary depending on the type of car.
When installing into a
different car
key in the ON (engine not running)
Main Unit Display Area
( "nor" Display)
※Make sure to only use
NORMAL Mode when
carrying this out.
※If either
or
shown in the display,
p r e s s d o w n o n t h e
M O D E s w i t c h u n t i l
appears.
Blink
Count down from 5 to 0
after the "cAr" blink.
※2
(e.g.)
Voltage Display
(e.g., L1.5)
※2
(e.g.)
Voltage Display
(e.g., L1.5)
0
( "SEt" Display)
%
※2
(e.g.)
Voltage Display
(e.g., H4.5)
(Degree of Acceleration Setting)
● This operation sets the car' s accelerator
characteristics into the controller unit.
● If the "Initial Settings" are not carried out,
the unit will remain in NORMAL Mode even
Initial
if the Mode is switched.
Settings
● If this settings have been improperly made
a CHECK Lamp may go on.
position and the gear in
Operational Procedure
7
With the accelerator at 100%,
press the SET switch.
※When "nor" is displayed, a clicking
sound can be heard.
is
SET
Press
8
Once the display changes to
100 release the accelerator.
9
Setting Completed
If the device is re-installed into a different vehicle,
make sure to carry out these settings again.
After having disconnected the OBD2 connector or the battery
for running tests there is not need to carry out the "Initial
Settings" again.
Check the Settings
Do not press in on pedal
Press down on pedal
※Depending on characteristics of the accelerator or on how the
accelerator is stepped on the display may read "A99" (99%).
If after the "Err" is shown the display returns
to as shown in
If is
that the degree of acceleration settings have
7
displayed at
not been confirmed properly. Re-do the
settings from step
P (Parking) or N (Neutral).
Main Unit Display Area
( "SEt" Display)
"nor" will be displayed
for 1 second
Set to
100
%
( "100" Display)
( "100" Display)
( "nor" Display)
※If the display is incorrect start
2
again from step above.
( "nor" Display)
( "100" Display)
4
( "L1.5" or so on), it means
4
.
5
