Hitec Eclipse 7
Screw off original transmitting antenna. There is connecting cabel in Duplex TU package.
Cut off connector on one side. Solder carefully each electric conductor to the „instructor-
student" connector as shown on a picture.
Screw off the antenna
Solder conductors to the
connectors
red – power supply
black – ground
yellow – PPMimpulses
