HITEC CP5220 Manual

GENERAL FEATURES
Water level measurement, control and process for tanks and water towers.
TECHNICAL PRINCIPLE
The level measurement is performed through the differential pressure meas-
urement between liquid surface and the submersible sensor. The pressure is
converted into electric signal by piezo-electric gauge to provide a 4/20mA out-
put signal on 2 wires.
MECHANICAL SPECIFICATIONS
Housing :
Cable :
Sensor :
Diameter :
Height :
Weight :
Fitting :
ELECTRICAL SPECIFICATIONS
Output signal :
Power supply :
EMC Conformity :
Consumption :
TECHNICAL DATA
Water column range :
Equivalent pressure :
Hysteresis :
Non-linearity :
Temperature operating range :
CP5220 / Data sheet / release.A2 - Page 1 of 2
CP5220
Level Transmitter for Tank
Serial n€
Nominal range
Cable length
Stainless steel 316L, PVC tip
2 wires + internal tube in shielded PVC (food approval)
cable
piezo-resistive gauge with silicone coating.
31 mm
150 mm (without cable)
435 g (without cable)
of shielded cable (475 g) or more upon request
by the suspension cable supplied with a hanging system
KITCAB.
4/20mA output signal on 2 loop wires, 4mA for 0m and
20mA for the full-scale
Voltage supply between 6 to 38 volts DC input. (Don't for-
get to integrate the voltage drop-out in the current loop)
Check the voltage specification of the protector unit
EN 50 081-2, EN 50 082-2
the signal value (mA)
Full-scale (F.S.) between 0,5 m to 30m. (Full-scale 20mA
adjusted to the required value by Hitec)
0,05 to 3 bars. P(bars) = H(meters) / 10.197
0,10 % F.S. (constant temperature).
0,15 % F.S. (constant temperature).
from 2€C to 50€ Celsius
Submersible
:
:
: 10 meters +
Supplied normally with 10 meters
