- Page 1 PrintServer 17/300 Printer Controller Firmware Version 2.1 Upgrade Order Number: EK–LPS1X–IN. A01 Digital Equipment Corporation Maynard, Massachusetts...
- Page 2 First Printing, June 1994 Digital Equipment Corporation makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.
-
Page 3: Installing The Firmware
Installing the Firmware Version 2.1 of the controller firmware ROM chips must be Software installed in a PrintServer 17/300 printer if you are booting from Requirements NetWare. The minimum version of PrintServer software required to boot from NetWare is Version 5.0. - Page 4 Installing the Firmware To install the ROM chips: Installation Procedure Disconnect the power cord from the wall outlet and then from the rear panel. Disconnect the Ethernet cable from the rear panel. Loosen the two captive screws by the Ethernet connection on the rear panel.
- Page 5 Installing the Firmware Extract the existing ROM chips ( ) by sliding the screwdriver underneath each chip and gently loosening the pins from their sockets. Carefully align the pins on each new chip with the sockets on the board, noting the orientation of the notch ( ¡...
- Page 6 Installing the Firmware To verify correct installation of the chips, power on the printer. Verification The power-up diagnostics run and the following display appears Procedure on the operator panel: XX-XX-XX-XX-XX-XX If the operator panel is blank, either the controller board is not fully seated or the chips are not installed correctly.
