- Page 1 (Rev. 2.0_10-2010) DISASSEMBLY & ASSEMBLY INSTRUCTIONS SINGLE STAGE CENTRIFUGAL PUMPS TCHM & TCTM...
- Page 2 All dr awings ar e f or r eference pur pose and not are certified f or c onstruction, how ever s hould additional information be required, contact POMPETRAVAINI or its closest representative. INDEX Steps to be followed prior to pump disassembly Disassembly and assembly 2.1 -...
- Page 3 Proceed with visual and dim ensional ins pections of the components to be r eplaced ( use only or iginal par ts f rom Pompetravaini), check the parts for wear and tear (for critical dimensions see tab.1 and 2 on chapter 6).
- Page 4 Specify also the VDMA num ber of the r equired par t, as s een on the pum p s ectional dr awing and par ts lis t f or pr oper identification of spare parts. We recommend the use of original spares: in c ase this is not r espected, POMPETRAVAINI declines any responsability for eventual damages caused by not original spare parts.
- Page 5 4 - SECTION DRAWINGS 903.3 400.1 433.2 502.1 940.2 903.1 902.2 902.1 932.1 901.1 Fig. 1 - Pump series TCHM gr. 1 and 2 design /1-C = Single mechanical seal and motor frame 80 and 90 903.3 400.1 433.2 940.2 903.1 902.2 902.1...
- Page 6 5 - NOMENCLATURE OF PUMP PARTS VDMA VDMA DESCRIPTION DESCRIPTION N° N° Suction casing Seal locating ring Spacer ring 502.1 Wear ring Casing cover Mechanical seal bush 183 Suppor t foot 562 Pin 210 Shaf 901... Screw 230 Im peller 902...
- Page 7 Tab. 1 BEARINGS TYPE RADIAL SEAL RINGS TYPE for SHAFT * MECHANICAL PUMP Motor frame Motor frame SEAL MODEL Ø (mm) 25-125 25-160 25-200 32-125 32-160 32-200 6208.2RS 6011.2RS AS40527 AS55708 --- 3 (40x80x18) (55x90x18) (40x52x7) (55x70x8) 40-125 ...
- Page 8 ....kW / ....HP COMMENTS NA5.SM.TCHM.GB00 / PRINTED IN ITALY Smontaggio TCHM-TCTM Inglese POMPETRAVAINI’S continuing research results in product improvement, therefore any specifications may be subject to change without notice. S.p.A. 20022 CASTANO PRIMO (Milano) ITALY Via per Turbigo, 44 – Zona Industriale Tel.
