Appendix 1 - Sentex SPECTRUM Series Programming Instructions Manual

PROGRAMMING STEPS FOR THE 101/301 BOARD
Description
Step number
Error Messages:
E1: does not exist
E2: duplicate found
E3: system is full
E5: format error
00 Terminate Programming
01 Set Password
02 Verify Password
03 Set Dialing Type
03 Verify Dialing Options
04 Set Rings Before Answer
04 Verify Rings Before Answer
05 Set Visitor Talk Time
05 Verify Visitor Talk Time
06 Set PBX Digit
06 Verify PBX Digit
06 Erase PBX Digit
07 Program Relay Activation Time
07 Verify Relay Activation Time
08 Set Directory Code Length
08 Verify Directory Code Length
09 Program Directory Code and
Phone Number
09 Verify Directory Code and
Phone Number
10 Erase Directory Code and
Phone Number
11 Erase All Directory Codes and
Phone Numbers
12 Set # of wrong entry codes
12 Verify # of wrong entry codes
13 Program Entry Code
13 Program Entry Code + Relay
Action Code (RAC)
14 Erase Entry Code
15 Erase All Entry Codes
52 System Reset
69 Set Feedback
7r (see Relay Action Relay Management Functions
Codes, next page)
Page 14 of 15

APPENDIX 1

Example
00+#
01+nnnnnn+#
02+nnnnnn+#
03+n+#
03+#
04+n+#
04+#
05+n+#
05+#
06+n+#
06+#
06+101010+#
07+r1+r2+#
07+#
08+n+#
08+#
09+d[ddd]+t[ttt
tttttttt]+#
09+d[ddd]+#
10+d[ddd]+#
11+101010+#
12+n+#
12+#
13+eeee+#
13+eeee+r+#
14+eeee+#
15+101010+#
69+#
7+r+#
Doc 6001573
Description
1=nnnnnn matches current
setting, 0 = no match
Sets dialing type to tones
(1), pulses (0)
(1/0 for tone/pulse)
Sets rings before answer to
0 <=n <=9
If 0, don't answer
015 <=n <255
Set PBX digit
Display PBX digit
Erase PBX digit
Sets relay 1 to r1 (2 digits)
and relay 2 to r2 (2 digits)
Sets code length to 1 <= 4
digits 1<=n <=4
Sets code d[ddd] (1-4 digits)
to t[ttttttttttt] up to 12 digits
Erases dir code d[ddd] (1-4
digits)
Erases all dir codes
Sets incorrect entry codes
allowed to 0 <=n <=9
If n=0, strikes and out is
disabled
Sets entry code eeee with
relay action code 1
Sets entry code with
specified relay action code
'r'
Erases entry code eeee (4
digits)
Erases all entry codes
Performs the specified relay
action 'r'
Remote
Prgrm?
Yes
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
Yes
No
Yes
No
Yes
No
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
No
Yes
Rev A
