onnection Box for HD Camera (Outdoor) 9487-A
C
EN
Assembly manual
Item no. 7000 01 06 / Included in delivery, see back page.
1
Mark and drill the mounting
holes using the drilling tem-
plate. Then guide the cable
through the mounting plate
and screw the mounting plate
to the wall.
3
Connect the cable to the camera cable
and secure with the retaining straps in
the cover.
VBD 658-6 (09.16)
2
Guide the camera cable through the
gasket in the cover and screw the cam-
era to the cover.
4
Screw the cover to the
mounting plate.
Advertisement
Related Manuals for RADEMACHER 9487-A
Summary of Contents for RADEMACHER 9487-A
- Page 1 Box for HD Camera (Outdoor) 9487-A Assembly manual Item no. 7000 01 06 / Included in delivery, see back page. Mark and drill the mounting Guide the camera cable through the holes using the drilling tem- gasket in the cover and screw the cam- plate.
- Page 2 Mounting accessories for wall mounting (4 rawlplugs, 4 screws) b) Two mounting screws for securing the camera c) Connection box cover d) Drilling template e) Connection box mounting plate RADEMACHER Geräte-Elektronik GmbH Buschkamp 7 46414 Rhede (Germany) info@rademacher.de www.rademacher.de...
