DHP 3135196 Assembly Manual

Black twin / twin bunk bed-kt

Hide thumbs Also See for 3135196:

Assembly manual (16 pages)

page of 15

/ 15
Bookmarks

Available languages

Quick Links

Download this manual

150 Lbs

Weight Limits:

68 Kgs

WARNING

• WARNING FOR YOUNG CHILDREN - This product contains small components, please ensure that they are kept away from small children.Children under the age of 6,

small infants and babies must not sleep on this bed for safety reasons. To prevent injury and damage to this unit, PROHIBIT jumping on it.

• Recommended # of people needed for assembly 2 (however it is always better to have an extra hand.) Estimated assembly time is 2 hour.

• THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE

150 Lbs

68 Kgs

3135196

29986 31352

BLACK TWIN \ TWIN BUNK BED-KT

DO NOT RETURN PRODUCT TO THE

STORE

STOP

Individual stores do not stock parts.

If a part is missing or damaged, call our

toll-free customer service line. We will

gladly ship your replacement parts FREE

of charge.

Need Parts or Assistance?

or access our website

www.dhpfurniture.com

For prompt, reliable service; please have your assembly

manual ready.

Date of Purchase

___ / ___ / ___

1-800-267-1739

Lot Number

_________

B34313519601

Need help?

Do you have a question about the 3135196 and is the answer not in the manual?

Questions and answers

Summary of Contents for DHP 3135196

Page 1 3135196 29986 31352 BLACK TWIN \ TWIN BUNK BED-KT 150 Lbs Weight Limits: DO NOT RETURN PRODUCT TO THE 68 Kgs STORE STOP Individual stores do not stock parts. If a part is missing or damaged, call our toll-free customer service line. We will gladly ship your replacement parts FREE of charge.
Page 3 PARTS LEG POST 1 T906780 LEG POST 3 QTY: 1 LEG POST 2 T906800 T906790 FRONT GUARD RAIL QTY: 1 REAR GUARD RAIL QTY: 2 T906820 T906810 QTY: 1 QTY: 1 4 HOLES 4 AGUJEROS 1 HOLE 1 AGUJERO UPPER SIDE RAIL T906830 LADDER SIDE RAIL QTY: 1...
Page 4 PARTS POST LINKS T906890 SLATS QTY: 4 T906870 LADDER QTY: 36 T906880 QTY: 1 POST RAILS SLATS SPACERS T391650 T906900 QTY: 2 QTY: 38 END SLATS PLASTIC PLUG T906910 T391660 QTY: 4 QTY: 88 NOTE: PART HAS PROTECTIVE END CAPS PRE-INSTALLED 4 /15 B34313519601...
Page 5 PARTS HEX KEY SCREW BOLT ST 4.2 x 10mm BOLT HEX KEY T290110 1/4"-20 x 3/4" T114670 5/16" x 3/4" QTY: 1 T127240 QTY: 16 T128230 T290120 QTY: 22 QTY: 16 QTY: 1 BOLT 1/4"-20 x 2 7/16" T127230 QTY: 5 WRENCH T129010 QTY: 1...
Page 6 ALWAYS USE THE RECOMMENDED SIZE MATTRESS OR MATTRESS SUPPORT, OR BOTH, TO HELP PREVENT THE LIKELIHOOD OF ENTRAPMENT OR FALLS. TO PREVENT INJURY, DHP RECOMMENDS ONE TWIN SIZE MATTRESS AND ONE FULL SIZE MATTRESS TO BE USED. USE ONLY A TWIN MATTRESS WHICH IS 74"-75" LONG AND 37 1/2"-38 1/2" WIDE ON UPPER BUNK AND A TWIN MATTRESS WHICH IS 74"-75" LONG AND 37 1/2"-38 1/2" WIDE ON LOWER BUNK.
Page 7 Attach the POST LINKS (M) to the POST RAILS (O) with the SCREWS (4). Attach the POST RAILS (O) to the LEG POSTS (A and B) with the SCREWS (4) as shown. Attach the END GUARD RAILS (I) to the LEG POSTS (A and B) with the BOLTS (2) as shown.
Page 8 Attach the SIDE RAILS (G, H & J) to the LEG POSTS (A, B & C) with the BOLTS (3) as shown below. Hardware Required 8 /15 B34313519601...
Page 9 Attach the GUARD RAILS (E & F) to the LEG POSTS (A & B) with the BOLTS (2) as shown in detail (1). Attach the GUARD RAILS (E & F) to the SIDE RAILS (G & H) with the BOLTS (1) as shown in detail (2). DETAIL (1) Hardware Required DETAIL (2)
Page 10 Carefully attach the SLATS (Q & K) to the UPPER SIDE RAILS (G & H), by using two SLATS (Q) at the extremist ends of the UPPER SIDE RAILS (G & H), and using 18 SLATS (K) in-between. Lock the SLATS (Q & K) into place with 44 PLASTIC PLUGS (R), as shown in detail (1).
Page 11 For the upper bed, attach 19 SLAT SPACERS (R) between SLATS (Q & K) as shown in DETAIL (1). Repeat the same procedure for the lower bed. Attach the LADDER (L) to the LADDER SIDE RAIL (H) with the BOLTS (1) and NUTS (7) as shown in DETAIL (2). DETAIL 1 Hardware Required DETAIL 2...
Page 12 3135196 Limites Del Peso: 150Lbs\68Kgs NO REGRESE ESTE PRODUCTO A LA TIENDA ALTO ALTO Las tiendas no tienen partes. Si faltan partes o las partes están dañadas llame gratis al servicio al cliente. Con gusto mandamos las partes. Sin cargo alguno.
Page 13 PROBABILIDAD DE QUEDAR ATRAPADO O DE CAÍDAS. * PARA PREVENIR LESIÓN, DHP RECOMIENDA QUE SE UTILICE UN COLCHÓN DE TAMAÑO INDIVIDUAL Y UN COLCHÓN DE TAMAÑO MATRIMONIAL. * UTILICE SOLAMENTE UN COLCHÓN INDIVIDUAL QUE SEA 74"-75"DE LARGO Y 37 ½"-38 1/2" DE ANCHO EN LA CAMA SUPERIOR Y UN COLCHÓN INDIVIDUALQUE SEA 74"-75"...
Page 14 PÁGINA 07 Una los ACOPLAMIENTOS del POSTE (M) a los CARRILES del POSTE (O) con los TORNILLOS (4). Ate los CARRILES del POSTE (O) a los POSTES de la PIERNA (A Y B) con los TORNILLOS (4) como se muestra. Una los CARRILES de PROTECTOR del EXTREMO (I) a los POSTES de la PIERNA (A Y B) con los PERNOS (2) como se muestra.
