225 Lbs
Weight Limits:
102 Kgs
600 Lbs
272 Kgs
WARNING
WARNING FOR YOUNG CHILDREN - This product contains small components, please ensure that they are kept away from small children. Children under
•
the age of 5, small infants and babies must not sleep on this bed for safety reasons. To prevent injury and damage to this unit, PROHIBIT jumping on it.
This product is designed for home use and not intended for commercial use.
•
The futon has been designed for seating and as an alternate sleep product for up to two (2) average adults.
•
KEEP FINGERS CLEAR OF THE MECHANISM when opening or closing the futon. Lift the futon seat from the front to open; Pull up the back of the futon
•
from the rear to close
Recommended # of people needed for assembly 2 (however it is always better to have an extra hand.) Estimated assembly time is 2 hours.
•
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE
•
3137096
BLACK TWIN \ FUTON BUNK BED
DO NOT RETURN PRODUCT TO THE
STORE
STOP
Individual stores do not stock parts.
If a part is missing or damaged, call our
toll-free customer service line. We will
gladly ship your replacement parts FREE
of charge.
1-800-267-1739
Need Parts or Assistance?
or access our website
www.dhpfurniture.com
For prompt, reliable service; please have your assembly
manual ready.
Date of Purchase
___ / ___ / ___
Lot Number
_________
B34313709605-10125-M
Advertisement
Table of Contents
Related Manuals for DHP 3137096
Summary of Contents for DHP 3137096
- Page 1 3137096 BLACK TWIN \ FUTON BUNK BED 225 Lbs Weight Limits: DO NOT RETURN PRODUCT TO THE 102 Kgs STORE STOP Individual stores do not stock parts. If a part is missing or damaged, call our toll-free customer service line. We will gladly ship your replacement parts FREE of charge.
- Page 3 PARTS REAR POST 1 FRONT POST 1 T608860 FRONT POST 2 REAR POST 2 T608880 QTY: 1 T608890 T608870 QTY: 1 QTY: 1 QTY: 1 GUARD RAIL RIGHT LOWER SIDE T608900 RAIL SIDE GUARD RAIL QTY: 2 T609080 T608910 QTY: 1 QTY: 2 UPPER SAFETY RAIL LEFT LOWER...
- Page 4 PARTS LOWER BED FRAME-1 LOWER BED FRAME-2 T605520 POST RAILS QTY: 2 T605530 T608930 QTY: 2 QTY: 2 CONNECTOR UPPER SLAT T608940 T609100 QTY: 4 QTY:22 MIDDLE RAIL LOWER SLAT T605610 T605600 QTY: 1 QTY: 40 4 /20 B34313709605...
- Page 5 PARTS T605570 T605560 LEFT MECHANISM RIGHT MECHANISM QTY:1 QTY:1 "R" "L" FLAT BENT BENT FLAT STOPPER SLAT SPACER PLASTIC PLUG T605640 LADDER T391650 T391660 QTY: 2 T608950 QTY: 21 QTY: 124 QTY: 2 FRAME CONNECTOR HOOK T608960 T391180 QTY: 4 QTY: 3 NOTE: PART HAS PROTECTIVE END CAPS PRE-INSTALLED...
- Page 6 PARTS BOLT 1/4" 1/4" x 5/8" T154290 BOLT T127160 QTY: 16 5/16" x 3/4" QTY: 32 BOLT T128210 1/4" x 1 3/16" BOLT QTY: 16 T127150 1/4" x 1 3/8" T127190 QTY: 4 QTY: 8 BOLT 1/4" x 2" BOLT T127340 1/4"...
- Page 7 ALWAYS USE THE RECOMMENDED SIZE MATTRESS OR MATTRESS SUPPORT, OR BOTH, TO HELP PREVENT THE LIKELIHOOD OF ENTRAPMENT OR FALLS. TO PREVENT INJURY, DHP RECOMMENDS ONE TWIN SIZE MATTRESS AND ONE FULL SIZE MATTRESS TO BE USED. USE ONLY A TWIN MATTRESS WHICH IS 74"-75" LONG AND 38 1/2"- 39" WIDE ON UPPER BUNK AND A FULL MATTRESS WHICH IS 74"-75" LONG AND 53 1/2"-54 1/2" WIDE ON LOWER BUNK.
- Page 8 Attach the CONNECTORS (N) to the POST RAIL (M) with the SCREWS (9) as shown. Attach the CONNECTORS (N) to the REAR POST 1 (A) and FRONT POST1 (C) with the SCREWS (9) as shown. Repeat this step using POSTS (B & D) to create two end assemblies. Note: Don't FULLY tighten the screws at this step, they shall be fully tightened at the next step Nota: No apriete COMPLETAMENTE los tornillos en este paso...
- Page 9 Attach the SIDE GUARD RAIL (F) to the POSTS (A & C) with the BOLTS (6) as shown in detail (1). Attach the LOWER SIDE RAIL (I2) to the POSTS (C & A) with BOLTS (1) and WASHERS (8) as shown in detail (2). Attach the MECHANISM (L) to the LOWER SIDE RAIL (I2) with the BOLTS (4) and LOCK NUTS (7) as shown in detail (3).
- Page 10 As shown in details (1 & 2), attach the LOWER SAFETY RAIL (H) and the UPPER SAFETY RAIL (G) to the POSTS (A, B, C & D) with the BOLTS (5). Attach the GUARD RAIL (E) to the POSTS (A, B, C & D) with the BOLTS (6). Attach the GUARD RAIL (E) to UPPER SIDE RAILS (G) with the BOLTS (1) as shown in detail (3).
- Page 11 Attach the UPPER SLATS (K) to the UPPER SAFETY RAILS (G). Lock the SLATS (K) in-place with 44 PLASTIC PLUGS (Y), as shown in detail (1). Attach the SLAT SPACERS (Q) between SLATS (K) as shown in details (2 & 3) DETAIL 1 DETAIL 3 DETAIL 2...
- Page 12 As shown in detail (1), attach the frame connector (S) to the lower bed frame-2 (V) by using bolts (6), and then attach lower bed frame-1 (J) & middle rail (X) to the frame connector (S) by using bolts (6). As shown in detail (2), attach the lower slats (O) to lower bed frames (V &...
- Page 13 As shown in detail (1), attach the lower bed frame-1 (J) and the lower bed frame-2 (V) to the frame connector (S) by using bolts (6). As shown in detail (2), attach the lower slats (O) to lower bed frames (V & J), then lock the slats in-place by using 2 plastic plugs (Y) for each slat.
- Page 14 As shown in detail (1 & 2), attach the LOWER BED FRAMES-1 (J) to the MECHANISMS (L & R) with the BOLTS (3) and NUTS (7). Attach the STOPPERS (T) and the HOOK (U) into place in the locations shown in details (3 & 4). WARNING: Use the frame assembled in step (5) as seatrest, as shown.
- Page 15 YOU'RE DONE! ¡LE HACEN! To use as a bed Para utilizar como cama PULL LIFT LEVANTE TIRÓN To use as a futon Para utilizar como futon LIFT LEVANTE 15 /20 B34313709605...
- Page 16 3137096 Limites Del Peso: CAMA: 225 lbs\102 kgs , Futon : 600 Lbs\272 kgs NO REGRESE ESTE PRODUCTO A LA TIENDA ALTO ALTO Las tiendas no tienen partes. Si faltan partes o las partes están dañadas llame gratis al servicio al cliente. Con gusto mandamos las partes. Sin cargo alguno.
- Page 17 PROBABILIDAD DE QUEDAR ATRAPADO O DE CAÍDAS. * PARA PREVENIR LESIÓN, DHP RECOMIENDA QUE SE UTILICE UN COLCHÓN DE TAMAÑO INDIVIDUAL Y UN COLCHÓN DE TAMAÑO MATRIMONIAL. * UTILICE SOLAMENTE UN COLCHÓN INDIVIDUAL QUE SEA 74"-75"DE LARGO Y 38 ½"-39" DE ANCHO EN LA CAMA SUPERIOR.
- Page 18 PÁGINA 08 Ate los CONECTADORES (N) al CARRIL del POSTE (M) con los TORNILLOS (9) como se muestra. Ate los CONECTADORES (N) al POSTE POSTERIOR 1 (A) y POST1 DELANTERO (C) con los TORNILLOS (9) como se muestra. Repita este paso usando los POSTES (B & D) para crear dos montajes del extremo.
- Page 19 PÁGINA 13 Según las indicaciones del detalle (1), ata la cama más baja frame-1 (J) y la cama más baja frame-2 (V) al conectador del marco (S) usando los pernos (6). Según las indicaciones del detalle (2), ata los listones más bajos (O) a marcos más bajos de la cama (V & J), entonces traba los listones sobre el terreno usando 2 enchufes plásticos (Y) para cada listón.
