- Page 1 USER AND INSTALLATION MANUAL ENGLISH SWIRLFAN II. ® PART01661 CONFETTI FX rev 01-01...
-
Page 2: Disclaimer
Should you detect any errors or inaccuracies in the manual, we would be grateful if you would inform us. This helps us to further improve our documentation. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 3: Table Of Contents
Mount on a truss (Re)Fill with confetti Connect power and setup DMX Setup multiple machines in a sequence with DMX Swirl with DMX Clean up Maintenance Troubleshooting Correct disposal EC Declaration of Conformity MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 4: Foreword
This document contains the original instructions in English. In case you require other languages please contact MAGIC FX. REVISION TABLE Document nr Revision Date Description Authored by Checked by PART01661 01-00 10-10-2019 Initial release PART01661 01-01 01-11-2019 MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 5: Meet The Magicfx ® Swirlfan Ii
SWIRLFAN II. ® Via two seperate lids in the top confetti is loaded into the machine. loading the MAGICFX SWIRLFAN II can be done either on the ground or while it is hanging in the truss. The MAGICFX SWIRLFAN II is delivered with 2 Quick Trigger Clamps. Use these to hang ®... -
Page 6: Technical Data
Humidity (Relative) 20% to 90% (non condensing) Controlling Control options Control protocols DMX512-A (ANSI E1.11) RDM (ANSI E1.20 Control connectors Neutrik 5-pole male/female XLR Usage Consumable(s) Confetti Technical data PRODUCT IDENTIFICATION Type plate MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 7: Dmx Control
DMX CONTROL The MAGICFX SWIRLFAN II is controlled with 1 safety adress and 1 operational ® address. DMX Address Address range Safety address 1 – 255 Start address (Effect density) 1 – 255 DMX addresses The safety address cannot be the same as the operational address. Operating of... - Page 8 Factory Defaults (YES/NO) Pause Timer (0–600 (s)) Error History Output Distance (0-255) Serial Number (DDDDD) Unique ID (HHHHHHHHHHHH) Main Menu Software Version Software CRC Information Bootloader CRC Build Date Uptime (DDDD:HH:MM:SS) Effect Time (DDDD:HH:MM:SS) MAGICFX® SWIRLFAN II — User and Installation Manual...
- Page 9 Release date of functional software. Up-Time Time counter which indicates how long the appliance has been (DDDD:HH:MM:SS) powered in total. Effect-Time Time counter which indicates how long the effect has been activated (DDDD:HH:MM:SS) in total. MAGICFX® SWIRLFAN II — User and Installation Manual...
-
Page 10: Rdm Capability
SOFTWARE_VERSION_LABEL DEVICE_MODEL_DESCRIPTION MANUFACTURER_LABEL SLOT_DESCRIPTION SENSOR_DEFINTION SENSOR_VALUE DMX_START_ADDRESS IDENTIFY_DEVICE DEVICE_LABEL FACTORY_DEFAULTS RESET_DEVICE RDM parameters RDM parameters are subject of change due to software updates. Contact MAGIC FX for the latest information and updates. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 11: Accessories
Confetti types and related load The output density of the confetti depends on multiple factors, NOTICE such as the set DMX value, the kind of confetti used and the height of the machine. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 12: Swirl Safely
SWIRL SAFELY! The MAGICFX SWIRLFAN II has been designed and constructed in such a manner ® that it can be used safely. This applies to the use, the circumstances and the regulations as described in this documentation. Reading this documentation and... -
Page 13: Safety Symbols
Section 2.6. Make sure the fan is not rotating and the power cable(s) are WARNING disconnected. Removing confetti residues when the fan is rotating can lead to serious injury. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 14: Let's Swirl
Make sure to use the safety steel to secure the machine to the truss. The safety steel can be attached to the safety eye on top of the machine. Inspect if the MAGICFX® SWIRLFAN II is mounted firmly and secured correctly. Inspect the machine and remove any foreign objects and material that will block or obscure the opening around and/or the air inlets of the machine during operation. -
Page 15: Re)Fill With Confetti
Make sure the fan is not rotating and the power cable(s) are WARNING disconnected. Removing confetti residues when the fan is rotating can lead to serious injury. Close the lid of the MAGICFX SWIRLFAN II. ® MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 16: Connect Power And Setup Dmx
Chapter 1. 7. Optionally see Section 3.7 for adding more machines to the same sequence. Always plug in a DMX Terminator into the DMX output. Using a CAUTION DMX Terminator improves signal reliability. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 17: Setup Multiple Machines In A Sequence With Dmx
7. Repeat step 1 – 5 for each subsequent machine. Always plug in a DMX Terminator into the DMX output of the final CAUTION unit in the control sequence. Using a DMX Terminator improves signal reliability. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 18: Swirl With Dmx
3. If desired, vary the effect density during operation. 4. Enjoy the view! 5. Deactivate the density address to stop blasting confetti. 6. Deactivate the safety address. The FX LED indicator on each machine dims. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 19: Clean Up
Make sure the fan is not rotating and the power cable(s) are WARNING disconnected. Removing confetti residues when the fan is rotating can lead to serious injury. 5. Unmount the machine if necessary. MAGICFX® SWIRLFAN II — User and Installation Manual... -
Page 20: Maintenance
To achieve the maximum service life of the MAGICFX SWIRLFAN II you must regularly ® clean the MAGICFX SWIRLFAN II and test if it is functioning correctly. ® Contact MAGIC FX if the MAGICFX SWIRLFAN II is not functioning correctly. -
Page 21: Ec Declaration Of Conformity
Translation of the original declaration of conformity Name manufacturer : MAGIC FX BV Address : Schouwrooij 27, 5281 RE BOXTEL Country : The Netherlands : B. Veroude Date : 10-10-2019 Signature MAGICFX® SWIRLFAN II — User and Installation Manual... - Page 24 WWW.MAGICFX.EU...
