Dual Performer
Ladder Treestand
© 2012 Summit Treestands, LLC
715 Summit Dr. Decatur, AL 35601
(256) 353-0634
info@summitstands.com
www.summitstands.com
WARNING
!
You must fully read, understand and follow these warnings
and instructions (written and video)! Failure to follow these
instructions may cause serious injury or death!!
•
WHEN HUNTING FROM A TREESTAND FALLS CAUSING INJURY OR DEATH CAN OCCUR ANY TIME AFTER LEAVING THE GROUND! FOR
THOSE REASONS ALWAYS USE A FALL ARREST SYSTEM (FAS) COMPRISING A FULL BODY HARNESS AT ALL TIMES AFTER LEAVING THE
GROUND. YOU MUST STAY CONNECTED AT ALL TIMES AFTER LEAVING THE GROUND WHILE USING ANY ELEVATED HUNTING PLATFORM.
SINGLE SAFETY BELTS AND CHEST HARNESSES ARE NO LONGER ALLOWED AND SHOULD NEVER BE USED. IF YOU ARE NOT USING A FULL
BODY HARNESS THAT IS PROTECTING YOU FROM A FALL, DO NOT LEAVE THE GROUND!
•
READ AND UNDERSTAND ALL OF THE MANUFACTURER'S WARNINGS AND INSTRUCTIONS AND USE ALL SAFETY DEVICES PROVIDED.
CONTACT SUMMIT TREESTANDS FOR ANY QUESTIONS. FAILURE TO DO SO COULD RESULT IN INJURY OR DEATH!
•
A SIGNAL DEVICE SUCH A MOBILE PHONE, RADIO, WHISTLE, SIGNAL FLARE OR PERSONAL LOCATOR DEVICE (PLD) MUST BE ON YOUR
PERSON AND READILY AVAILABLE AT ALL TIMES! ALWAYS INFORM SOMEONE OF YOUR HUNTING LOCATION, WHERE THE TREESTAND
WILL BE LOCATED AND THE EXPECTED DURATION OF THE HUNT!
•
DO NOT USE ANY TREESTAND UNLESS YOU ARE IN GOOD PHYSICAL SHAPE AND HAVE NO PHYSICAL LIMITATIONS OR MEDICAL
CONDITIONS WHICH MAY PREVENT YOU FROM SAFELY USING THIS PRODUCT. ALWAYS CONSULT A PHYSICIAN IF YOU HAVE ANY
QUESTIONS ABOUT YOUR PHYSICAL ABILITY TO USE THIS PRODUCT.
•
NEVER USE A TREESTAND WHILE TAKING DRUGS, ALCOHOL OR CERTAIN PRESCRIPTION DRUGS! ALWAYS CONSULT A PHYSICIAN IF YOU
HAVE ANY QUESTION ABOUT TAKING SPECIFIC MEDICATIONS AND USING THIS PRODUCT!
•
NEVER USE A TREESTAND DURING INCLEMENT WEATHER SUCH AS RAIN, LIGHTNING, WINDSTORMS OR ICY CONDITIONS! END YOUR
HUNT AND RETURN TO THE GROUND IF ANY OF THESE INCLEMENT CONDITIONS ARISE.
•
NEVER USE A TREESTAND WHEN FEELING ILL, NAUSEOUS, DROWSY OR DIZZY!
•
BE WELL RESTED AND NEVER HURRY. HURRYING CAUSES ACCIDENTS!
•
CHECK EVERY LADDER SECTION CONNECTION EVERY TIME YOU USE THE STAND. IF ANY LADDER SECTIONS ARE SEPARATING - DO NOT
USE THE STAND!
•
NEVER USE A TREESTAND ON A DEAD, LEANING, DISEASED, LOOSE BARKED TREE, ON A UTILITY POLE OR ON TREES THAT HAVE ANY
OBSTRUCTIONS THAT MAY LIMIT TREESTAND USE! NEVER RELY ON A TREE BRANCH FOR SUPPORT!
•
CHECK THE GROUND UNDER THE LADDER STAND TO MAKE SURE IT IS FIRM AND LEVEL. SLOPING GROUND OR AN UNEVEN SURFACE
(ONE LADDER SECTION ON A ROCK FOR EXAMPLE) CAN CAUSE YOUR STAND TO TILT OR SHIFT AS YOU CLIMB.
•
ALWAYS MAINTAIN THREE POINTS OF CONTACT WHEN YOU CLIMB THE LADDER SECTION OF THIS STAND!
•
NEVER JUMP OR BOUNCE ON A TREESTAND TO SECURE IT TO THE TREE!
•
PULL UP A BOW, BACKPACK, FIREARM OR OTHER EQUIPMENT ONLY AFTER BEING SECURE IN THE TREESTAND. FIREARMS MUST BE
PULLED UP UNLOADED, CHAMBER OPEN AND MUZZLE DOWN!
•
NEVER MODIFY YOUR STAND IN ANY WAY BY MAKING REPAIRS, REPLACING PARTS, OR ALTERING ADDING OR ATTACHING ANYTHING
TO IT EXCEPT IF EXPLICITLY AUTHORIZED IN WRITING BY THE MANUFACTURER!
•
PRACTICE INSTALLING, ADJUSTING AND USING YOUR TREESTAND AT GROUND LEVEL PRIOR TO USING IT AT ELEVATED POSITIONS!
•
INSTRUCTIONS (WRITTEN AND VIDEO) SHOULD BE KEPT IN A SAFE PLACE AND REVIEWED AT LEAST ANNUALLY. IT IS THE RESPONSIBILITY
OF THE TREESTAND OWNER TO FURNISH THE COMPLETE INSTRUCTIONS TO ANY PERSON WHO BORROWS OR PURCHASES THE
TREESTAND! THIS SUMMIT TREESTAND IS DESIGNED TO BE USED AS A COMPLETE SYSTEM - NEVER LOAN OR SELL ONLY A PORTION OF
THIS TREESTAND SYSTEM.
•
BEFORE EACH USE OF YOUR SUMMIT TREESTAND, ALWAYS INSPECT THE TREESTAND AND HARNESS FOR ANY DAMAGE, CRACKS, TEARS,
CABLE WEAR OR ABRASION THAT MAY HAVE OCCURRED IN TRANSPORTING / STORING YOUR TREESTAND. DO NOT USE IF ANY DAMAGE
IS FOUND! CONTACT CUSTOMER SERVICE FOR THE APPROPRIATE REPAIR / REPLACEMENT PROCEDURE!
•
DO NOT LEAVE YOUR TREESTAND OUTDOORS WHEN IT IS NOT BEING USED! ANY STAND TUBING THAT IS ALLOWED TO FILL WITH
RAINWATER AND FREEZE WILL RUPTURE OR BURST - DO NOT USE YOUR TREESTAND IF THIS OCCURS!
You MUST also view the enclosed DVD BEFORE using your new treestand!!
WEIGHT LIMIT
SINGLE USER
350 LBS. X 1 TOTAL*
DO NOT EXCEED THIS LIMIT!
(* Includes all gear)
Stand minimum and maximum tree size: 8-20" diameter
PN 82064
DOUBLE OCCUPANCY (TWO USERS)
250 LBS. MAX. INDIVIDUAL*
500 LBS MAX. COMBINED TOTAL*
Dual Performer 82064, 1/2012
Advertisement
Related Manuals for Summit Dual Performer
Summary of Contents for Summit Dual Performer
- Page 1 OF THE TREESTAND OWNER TO FURNISH THE COMPLETE INSTRUCTIONS TO ANY PERSON WHO BORROWS OR PURCHASES THE TREESTAND! THIS SUMMIT TREESTAND IS DESIGNED TO BE USED AS A COMPLETE SYSTEM - NEVER LOAN OR SELL ONLY A PORTION OF THIS TREESTAND SYSTEM.
-
Page 2: Table Of Contents
FOR RATCHET NOTICE 82064.760 SHORT LADDER STABILIZER STRAP WITH CAM BUCKLE Summit recommends the use of the SOP Climbing 82064.765 LONG LADDER STABILIZER STRAP System Accessory with all ladder and hang-on WITH LOOP END treestands. For more information please visit our 82064.870... -
Page 3: Right Upright Arm
ASSEMBLY PLATFORM / SEAT BASE LEFT 1. Position the Top Ladder Section, Left Upright UPRIGHT Arm and Right Upright Arm as shown in figure 1. The Top Ladder Section has two couplers welded (PN 82064.250) on and does not have a U bracket. TOP LADDER SECTION 2. Slide the Uprights down onto the Ladder (PN 82064.910) -
Page 4: Yoke
PLATFORM / SEAT BASE (continued) 7. Secure the Upright to the Platform and Seat using three 2 1/2” bolts and lock nuts. Leave these bolts hand tight for now. (See figure 6) 8. Position the remaining Armrest Upright on the opposite side as shown in figure 7. Attach the upright arm using three 2 1/2”... -
Page 5: Gunrest Bar
SUPPORT BARS / SEAT BACK (continued) 5. Position the Seat Back next. The teeth area on the Seat Back bar should face the tree when finished as shown in figure 11. 6. Line up the Seat Back with the holes in the Yoke and Seat Base. Secure using two 3 1/2”... - Page 6 1 3/4” BOLT, LOCK NUT - WRENCH TIGHTEN BUSHINGS GUNREST (PN 82064.740) FOAM SEAT 1. Position the Foam Seat Base inside the frame as FOAM SEAT shown in figure 19. BACK 2. Wrap the hook and loop straps on the bottom and (PN 82064.855) back of the seat around the frame to secure.
-
Page 7: Middle Ladder Section
LADDER COLUMN 1. Position the Bottom Ladder Section and Middle Ladder Section as shown in WELDED figure 20. The welded U bracket faces U BRACKET BOTTOM the tree when fully assembled. LADDER The Bottom Ladder Section has no SECTION welded couplers. (PN 82064.930) 2. Slide the Ladder Sections together, line up the bolt holes and use one 1 3/4”... -
Page 8: Stabilizer Male Section
STABILIZER BAR 1. Position the Female Section of the Stabilizer bar as shown in figure 24. The Stabilizer bar will attach to the welded U Bracket. Slide the bar into the bracket and line up the hole. 2. Secure using one 1 3/4”... -
Page 9: Setup And Use
SETUP AND USE PLATFORM RATCHET STRAP 1. Attach the Ratchet with Loop End to the yolk tube at location A as shown in figure 28. Put the sewn loop around the tube (figure 29) and then push the ratchet through the loop (figure 30) to create a cinch knot as shown in figure 2. Attach the Short Strap for the Ratchet to the opposite yolk tubing at location B shown in figure 28. - Page 10 SETUP WARNING It is required that at least three people initially set up the ladder stand. Always use two helpers! WARNING Check the ground under the ladder stand to make sure it is firm and level. WARNING Never use this ladder stand on dead, leaning, diseased or loose barked trees.
- Page 11 1. Climb up and before stepping onto the platform IMMEDIATELY attach your safety strap around the tree above your seating position. ALWAYS refer to your harness instructions included with this stand for proper use of your Summit Safety harness and Safety Strap 2. The length of the harness tether must be minimized at all times.
-
Page 12: Maintenance And Care
It is expressly understood that Summit’s liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product, as stated above, and Summit will not be liable for any other injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit, or damage to material, arising in connection with the sale, installation, use of, inability to use, or the repair or replacement of Summit’s products.
