Summit Shooter
Xtreme
© 2013 Summit Treestands, LLC
715A Summit Dr. Decatur, AL 35601
(256) 353-0634
info@summitstands.com
www.summitstands.com
•
READ AND UNDERSTAND ALL OF THE MANUFACTURER'S WARNINGS AND INSTRUCTIONS BEFORE USE. CONTACT SUMMIT TREESTANDS
FOR ANY QUESTIONS. FAILURE TO DO SO COULD RESULT IN INJURY OR DEATH!
•
KEEP HANDS AWAY FROM SCISSORING TUBING WHEN OPENING OR CLOSING THE SHOOTING BENCH.
•
NEVER USE YOUR SHOOTING BENCH ON UNEVEN OR SLOPING TERRAIN.
•
NEVER REST RIFLES AGAINST SHOOTING BENCH AS IT MAY ROTATE.
•
NEVER SIT ON THE TOP OF THE SHOOTING BENCH.
•
ALWAYS PRACTICE SAFE FIREARM HANDLING.
1
INDEX
2
BOX CONTENTS
DESCRIPTION
LEG ASSEMBLY WITH CENTER TUBE
SEAT ADJUSTMENT RING
LARGE NYLON BUSHING
SEAT ARM
MOLDED TOP WITH FRAME
PADDED SEAT
HAIR PIN CLIP

GENERAL WARNINGS AND PRECAUTIONS

SECTION 1 - INDEX
SECTION 2 - PARTS LIST
SECTION 3 - ASSEMBLY
SECTION 4 - SETUP AND USE
SECTION 5 - LIMITED WARRANTY
QTY
1
1
2
1
1
1
1
PN 85240
FORM# Shooter Extreme - 12/2013
PG 1
PG 1
PG 1
PG 2 - 3
PG 4
PG 4
