EAN-Startup Guide 1500-OEM
PN: EAN-Startup-Guide-1500-OEM
9/17/2019
© SightLine Applications, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1500-OEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SightLine 1500-OEM

  • Page 1 EAN-Startup Guide 1500-OEM PN: EAN-Startup-Guide-1500-OEM 9/17/2019 © SightLine Applications, Inc.
  • Page 2 User License Agreement. All data, specifications, and information contained in this publication are based on information that we believe is reliable at the time of printing. SightLine Applications, Inc. reserves the right to make changes without prior notice. Alerts The following notifications are used throughout the document to help identify important safety and setup information to the user: ...
  • Page 3: Table Of Contents

    Figure 2: 1500-AB Board Serial COM Connection ..................3 Figure 3: Typical Bench Hardware Setup ....................4 Figure 4: 1500-OEM Bench Setup with 1500-AB Board (Rev H and later) ..........5 Figure 5: 1500-AB Board Dual Power Switches (Rev E and earlier) ............5 Figure 6: Windows Security Alert Prompt ....................
  • Page 4 EAN-1500-OEM Startup Guide List of Tables Table 1: 1500-EVAL Kit ..........................3 Appendix Figures Figure A1: 1500-OEM Enclosure Bench Connection Diagram ..............12 Appendix Tables Table B1: 1500-ENC EVAL KIT ........................12 © SightLine Applications, Inc.
  • Page 5: Overview

    EAN-1500-OEM Startup Guide 1 Overview The 1500-OEM Startup Guide provides the steps for connecting, configuring, and testing the 1500-OEM board on the 1500-AB accessory board. The AB provides the standard connections for communication with the 1500-OEM board. Boards with SLE options enabled use the same startup procedure.
  • Page 6: Network Configuration

    EAN-1500-OEM Startup Guide 2 Network Configuration The 1500-OEM board can be connected directly to the host PC or through a network switch. During startup, the board sends three DHCP discover requests in three second intervals. It will self-assign the link-local address of 169.254.1.180 if it does not receive a response.
  • Page 7: 1500-Eval Kit

    Table 1: 1500-EVAL Kit Part Number Description 1500-OEM + 1500-SOM (Rev E) Video processing board 1500-AB (Rev H and later) Accessory board with standard connections for the 1500-OEM SLA-CAB-1514 Molex round wire cable SLA-MSD-32GB SD Card for recording clips and snapshots SLA-PWR-B05V...
  • Page 8: Hardware Bench Setup

    This section describes the connection for the 1500-OEM and the 1500-AB interface board to the supporting components. The 1500-AB board is used as the serial and network interface board.
  • Page 9: Power Connections

    To power-on the 1500-OEM board For Rev E and earlier AB boards, place both switches in the position shown in Figure A blue light on the 1500-AB board and a green light on the 1500-OEM indicate that all the boards are powered on. Network Connection LED...
  • Page 10: Panel Plus

    This section covers the Panel Plus setup and configuration process. Panel Plus provides a basic graphical interface to the features and functions of the 1500-OEM and 1500-AB board. Before connecting with the Panel Plus software, the 1500-OEM and 1500-AB boards should be powered up and connected through: a network switch or directly to the host PC (preferred) or, a direct serial connection (for troubleshooting or if a network connection cannot be established).
  • Page 11: Figure 7: Network Connection To Board

    Click to connect Connected tconnected Figure 7: Network Connection to Board 5. Verify the connection: a. When the Panel Plus has connected to the 1500-OEM board, the firmware version and the enabled features will be displayed. Appbit code with listed features Figure 8: Firmware Version and Enabled Features b.
  • Page 12: Camera Setup And Network Selection

     EAN-Camera Compatibility for all third-party cameras and lens assemblies that are currently supported by SightLine software. Includes configuration and setting support guidance. 5. From the Connection tab, click Stream Network Video to This PC. 6.2 Direct serial connection (optional): 1.
  • Page 13: Summary

    EAN-1500-OEM Startup Guide 7 Summary This completes the startup guide for the 1500-OEM board. See the Panel Plus User Guide (main menu » Help » User Guide) for additional user and setup information. If the board has been connected to a camera and encoding functions are part of the configuration, video will be displayed in the main window.
  • Page 14: Troubleshooting

    The Panel Plus software will automatically recognize serial ports and list them in the dropdown menu for available connections. 6. Connecting to the serial COM port on the 1500-OEM board from a host PC requires a null modem adapter or null modem serial cable.
  • Page 15: Questions And Additional Support

    8.1 Questions and Additional Support This concludes the Troubleshooting section. For questions and additional support, please contact Technical Support. Additional support documentation and Engineering Application Notes (EANs) can be found on the Support pages of the SightLine Applications website. © SightLine Applications, Inc.
  • Page 16: Appendix - 1500-Oem Enclosure

    EAN-1500-OEM Startup Guide Appendix - 1500-OEM Enclosure The 1500-OEM enclosure supports both laboratory and system integrations. It provides standard connectors for analog Video In and Out, ethernet, power and RS232 serial. An FFC interface allows digital interface connections to FLIR Tau, FLIR Quark, and Tamarisk LWIR cameras.
