INSTRUCTIONS
Loop Block
3214, 3230, 3245, 3255
Part
Sheave
No.
Ø
3214
57 mm
3230
75 mm
3245 100 mm
adhesive
®
3255 125 mm
Loop and/or high-strength lashing line
When choosing a Harken Loup
6
working load in basket configuration exceeds the maximum working load
of the block.
When choosing a lashing line, use a breaking load that is double the block's
breaking load to account for strength loss from:
1. Knots slipping or breaking at a much lower load than line breaking load.
Spectra
or Dyneema
®
2. Splices slipping or failing due to incorrect type or execution.
3. UV damage increasing with each passing year.
4. Chafing seriously reducing strength.
7
Go to www.harken.com/knots for additional information. If you are not
comfortable choosing line, work with a qualified rigger.
Note: See chart for maximum line diameter that will fit through mouth.
WARNING! Knots weaken line considerably. Consult qualified rigger
or line manufacturer for advice on securing line. Use high-strength
loops or consult rigger for recommendations on lashing. Using the
wrong line, or securing the line improperly, can cause an accident.
Deadend
post
Sheave with side balls
Sheave w/side balls Deadend post Helicoil Sideplate alpha
HBB85
H-34389A
HBB86
H-34390A
HBB87
H-34391A
HBB88
H-34392B
= Incorrect. Avoid to prevent accidents.
Specifications
Max working load
Breaking load
(MWL)
lb
kg
lb
2500
1134
5000
5000
2268
10000
7500
3402
15000
11000
4990
22000
You Must Supply
soft-attach, be sure the Loup maximum
®
-type lines require specialized knots.
®
Roller cage
assembly
AL-3238
MS-210
AL-3700
AL-3336
MS-221
AL-3726
AL-3427
MS-251
AL-3751
AL-3515
MS-259
AL-3769
Max line Ø
(BL)
that fits
through mouth
kg
2268
5 mm
4536
8 mm
6804
11 mm
9977
14 mm
Sideplate beta
Isolator
Screw
Head securing line
HCP1438
HCP1419
HCP1419
HCP392
