Parameter Correspondence Table ................16 P3 Series 2 and G+ Mini Differences in Parameter Settings ........17 P3 Series 2 and G+ Mini Parameter Correspondence for Drive Replacement ..16 Appendix ........................20 P3 Series 2 and G+ Mini Differences in Watts Loss ..........20 P3 Series 2 and G+ Mini Specification Differences ..........21...
1.1 Overview This purpose of this document is to provide an easy transition from the P3 Series 2 (N060 = 00) to the G+ Mini (A01.01 = 1). For the advanced portion (A01.02 = 2), please refer to the G+ Mini Advanced instruction manual (P/N 144-25084).
Page 5
– Never attempt to apply P3 Series 2 option cards to the G+ Mini unit. – The option card on the G+ Mini may have another connector on the P3 Series 2. Make sure that the connectors fit into the new option card before using it.
Product Transition Guide G+ Mini Rev: 1.3 Ratings Summary The following table summarizes the output current ratings for the G+ Mini and P3 Series 2 with respect to the specific drive model. Heavy Duty Heavy Duty P3 Series 2 Rated...
1.4 Terminals Main Circuit Terminals • As the P3 Series 2 and G+ Mini may have different terminals sizes (depending on capacity), the terminals must be carefully checked before replacement. • The main terminal functionality has not been changed between the P3 Series 2 and the G+ Mini drive.
Product Transition Guide G+ Mini Rev: Control Signal Level Terminals Function Series P3 Series 2 G+ Mini Mini Analog input power supply +12 V (max. current 20 mA) +10.5 V (max. current 20 mA) Analog input 1 0~+10 VDC (20 kW),...
Product Transition Guide G+ Mini Rev: 1.5 Dimensions, Installation Space and Substitution Material IMPULSE® P3 Series 2 Dimensions & Drive Ratings Rated Total Voltage Max Full Model Wt. LB. Heat Class Load (in) (in) (in) (in) (in) (Approx) Loss 2001-P3S2 0.25...
24.0 7.09 11.42 5.63 6.30 11.18 11.5 283.8 4031-G+M 31.0 7.09 11.42 6.42 6.30 11.18 12.1 344.3 * Heat loss for carrier frequency of 2.0 KHz (Heavy Duty) G+ Mini Transition Guide September 2008 Page 14 of 24 Magnetek, Inc.
Page 15
Product Transition Guide G+ Mini Rev: IMPULSE® P3 Series 2 Wiring Diagram G+ Mini Transition Guide September 2008 Page 15 of 24 Magnetek, Inc.
Page 16
Product Transition Guide G+ Mini Rev: IMPULSE® G+ Mini Wiring Diagram G+ Mini Transition Guide September 2008 Page 16 of 24 Magnetek, Inc.
P3 Series 2 and G+ Mini Differences in Parameter Settings The list in Section 1.6 shows the parameter relations between the P3 Series 2 and the G+ Mini. It lists the parameters and setting values necessary for P3 Series 2 replacement by a G+ Mini, but does not show the complete G+ Mini parameters and extended parameter setting ranges.
Page 18
Product Transition Guide G+ Mini Rev: Drive P3 Series 2 G+ Mini Note Param. Initial Param. Initial Parameter Value Value Value Value Function P3 Series 2 G+ Mini B03.01 n013→xxx0 B03.01→0 n013→xxx1 B03.01→1 Run Signal Selection 1 n013 0101 n013→xx0x B03.02→0...
Page 19
Product Transition Guide G+ Mini Rev: Drive P3 Series 2 G+ Mini Note Param. Initial Param. Initial Parameter Value Value Value Value Function Swift Lift Delay Time at n023 C06.07 Threshold Speed Analog Frequency n024 1.00 H03.03 100.0 Reference Gain...
Page 20
Product Transition Guide G+ Mini Rev: Drive P3 Series 2 G+ Mini Note Param. Initial Param. Initial Parameter Value Value Value Value Function Max. Output Frequency n043 60.0 E01.04 60.0 Max. Output Voltage n044 230.0 E01.05 230.0 Max. Voltage Frequency n045 60.0...
Product Transition Guide G+ Mini Rev: Appendix P3 Series 2 and G+ Mini Differences in Watts Loss - Class D Operation P3 Series 2 @ 2.5 KHz G+ Mini @ 2.0 KHz Maximum Voltage Motor P3 Series 2 G+ Mini...
Product Transition Guide G+ Mini Rev: P3 Series 2 and G+ Mini Specification Differences Category Feature Item P3 Series 2 G+ Mini Control Method – Sinewave PWM: V/F & OLV Sinewave PWM: V/F & OLV Ratings 230v, 3ph. 0.125 to 10 HP 0.125 to 20 HP...
