ASROCK IMB-152 Settings Manual

*15G06M015000AK*
P/ N: 15G06M015000AK V1.0
IMB-152
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
1 : Backlight Power Connector (BLT_PWR1)
PIN Signal Name
1 GND
2 GND
3 BL CTL
4 BL EN
5 LCD_BLT_VCC
6 LCD_BLT_VCC
2 : Backlight Volume Control (BLT_VOL1)
PIN Signal Name
1 GPIO_VOL_UP
2 GPIO_VOL_DW
3 PWRDN
4 LVDS1 BLUP
5 LVDS1 BLDW
6 GND
7 GND
3 : Panel Power Selection (LCD_VCC)
(PNL_PWR1)
1-2: LVDD: +3V
2-3: LVDD: +5V
4-5: LVDD: +12V
4 : LVDS Panel Connector
Jumpers and headers setting guide
1 2 3
36 1
BLT_PWR1
1
1
BLT_VOL1
1 PNL_PWR1
1 PWR_COM1
1 PWR_COM2
COM
COM
1 PWR_COM3
35
Port 1 Port 2
1
34
33
HDMI1
COM
32
VGA1
Port 3
BUZZ1
USB 3.0
Top:
31
T: USB3
RJ-45
B: USB2
30
USB 3.0
29
T: USB1
B: USB0
HD_AUDIO1 1
1
28
SPEAKER1
PCIE1
27 26 25
PIN Signal Name
1 LCD_VCC
3 +3.3V
1
5 LDDC_DATA
7 LVDS_A_DATA0
9 LVDS_A_DATA1#
11 GND
13 LVDS_A_DATA2
15 LVDS_A_DATA3#
17 GND
19 LVDS_A_CLK
21 LVDS_B_DATA0#
23 GND
25 LVDS_B_DATA1
27 LVDS_B_DATA2#
1
29 LVDD_EN
31 LVDS_B_DATA3
33 LVDS_B_CLK#
35 GND
37 CON_LBKLT_CTL
39 LCD_BLT_VCC
5 : Backlight Power Selection
(LCD_BLT_VCC) (BKT_PWR1)
1-2: LCD_BLT_VCC: +5V
2-3: LCD_BLT_VCC: +12V
6 : BLT_PWM1
1-2: +3V Level
2-3: +5V Level
7 : ATX Power Connector
(Input 12V)
1-2: GND
3-4: DC Input
8 : +12V_OUT1 Connector
Pin1: GND
Pin2: +12V
4 6
5
1 1
BKT_PWR1 BLT_PWM1
Industrial
IMB-152
1
COM4
1
USB2_0_1
1 1
COM5 USB2_2_3
CI2
1
1
1
USB2_4_5
CI1 JGPIO_SET1 1
1 COM6
1
PWR_JP1
1
JGPIO1
LPC1
1
JGPIO_PWR1 PWR_COM4 PWR_COM5
SPDIF1
1 1 1
1
24 23 22 21 20 19 18 17 16 15
PIN Signal Name
2 LCD_VCC
4 LDDC_CLK
6 LVDS_A_DATA0#
8 GND
10 LVDS_A_DATA1
12 LVDS_A_DATA2#
14 GND
16 LVDS_A_DATA3
18 LVDS_A_CLK#
20 GND
22 LVDS_B_DATA0
24 LVDS_B_DATA1#
26 GND
28 LVDS_B_DATA2
30 LVDS_B_DATA3#
32 GND
34 LVDS_B_CLK
36 CON_LBKLT_EN
38 LCD_BLT_VCC
40 LCD_BLT_VCC
3 1
4 2
2
1
7
ATX12V1
8
12V_OUT1
9
SATA_PWR1
10
11
LPT1
1
CLRCMOS1
12
1
PANEL1
1
13
1
FAN1
14
CMOS
BIOS
Battery
Chip
PWR_COM6
1
9 : SATA Power Output Connector
10 : SATA2 Connectors
(SATA2_1, SATA2_2)
11 : Printer Port Header
12 : Clear CMOS Header
1-2: Normal
2-3: Clear CMOS
13 : System Panel Header
GND
GND RESET#
PWRBTN# GND
PLED- HDLED-
PLED+ HDLED+
1
14 : 4-Pin FAN Connector
(+12V)
COM Port PWR Setting Jumpers
15: PWR_COM6 (For COM Port6)
17: PWR_COM5 (For COM Port5)
18: PWR_COM4 (For COM Port4)
34: PWR_COM1, 2, 3 (For COM Port1, 2, 3)
1-2: +5V
2-3: +12V
SATA2_2
SATA2_1
1 GND
+12V
2
FAN_SPEED
3
FAN_SPEED_CONTROL
4
