Digital Audio; Physical - Ssl 2+ User Manual

Unbalanced Outputs
Frequency Response
Dynamic Range (A-Weighted)
THD+N (@ 1kHz)
Maximum Output Level
Output Impedance
Headphone Outputs
Frequency Response
Dynamic Range
THD+N (@ 1kHz)
Maximum Output Level
Output Impedance

Digital Audio

Supported Sample Rates
Clock Source
USB
Low-Latency Monitor Mix
Roundtrip Latency at 96 kHz

Physical

Analogue Inputs 1&2
Connectors
Input Gain Control
Microphone/Line/Instrument Switching
Phantom Power
Legacy 4K Analogue Enhancement
Analogue Outputs
Connectors
Stereo Headphone Outputs
Outputs 1L / 2R Level Control
Outputs 3 & 4 Level Control
Monitor Mix Input - USB Blend
Monitor Mix - Stereo Input
Headphones Level Control
Headphones B 3&4 Source Selection
SSL 2+ User Guide
± 0.05 dB
112 dB (1-2), 110 dB (3-4)
< 0.0015% @ -8 dBFS, < 0.0025% @ -1 dBFS
+6.5 dBu
< 1 Ω
± 0.05 dB
111 dB
< 0.0015% @ -8 dBFS, < 0.0020% @ -1 dBFS
+10 dBu
10 Ω
44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Internal
USB 2.0
Input to Output: < 1ms
Windows 10, Reaper: < 4ms (Safe Mode Off)
Mac OS, Reaper: < 5.2ms
XLR 'Combo' for Microphone/Line/Instrument on rear panel
Via front panel
Via front panel switches
Via front panel switches
Via front panel switches
1/4" (6.35 mm) TRS jacks, RCA sockets on rear panel
1/4" (6.35 mm) TRS jacks on rear panel
Via front panel
None
Via front panel
Via front panel
Via front panel
Via front panel
Specifications
25
