CONTROL ELEMENTS AND CONNECTIONS

Front
LED PSI-1 DMX
MODE
1 2
Connections
DMX OUT DMX IN
6 7
6. DMX OUTPUT SOCKET
7. DMX INPUT SOCKET
8. LOAD OUTPUTS
9. FUSE
10. POWER SUPPLY
11. POWER ON/OFF
CONTROLLER
SET UP UP DOWN
LIGHT 11 LIGHT 9 LIGHT 7
LIGHT 12 LIGHT 10 LIGHT 8
5
1. MODE BUTTON
2. FUNC -BUTTON
3. RGB CONTROL EDs
3 4
4. DOWN BUTTON
5. UP BUTTON
6. DISPLAY
LIGHT 5 LIGHT 3 LIGHT 1
LIGHT 6 LIGHT 4 LIGHT 2
8
19/28
ON
FUSE: F 4 A/230 V POWER IN
AC 100-240 V 50/60 Hz
OFF
9 10 11
