Summary of Contents for EuroLite LED PSI-1 DMX Controller

  • Page 1 BEDIENUNGSANLEITUNG USER MANUAL LED PSI-1 DMX Controller Für weiteren Gebrauch aufbewahren! © Copyright Keep this manual for future needs! Nachdruck verboten! Reproduction prohibited!
  • Page 2: Table Of Contents

    CLEANING AND MAINTENANCE ......................... 28 Replacing the fuse ............................28 TECHNICAL SPECIFICATIONS ........................28 Das neueste Update dieser Bedienungsanleitung finden Sie im Internet unter: You can find the latest update of this user manual in the Internet under: www.eurolite.de 2/28 00027825.DOC, Version 1.3...
  • Page 3: Einführung

    - sich die letzte Version der Anleitung im Internet herunter laden EINFÜHRUNG Wir freuen uns, dass Sie sich für einen EUROLITE LED PSI-1 DMX-Controller entschieden haben. Wenn Sie nachfolgende Hinweise beachten, sind wir sicher, dass Sie lange Zeit Freude an Ihrem Kauf haben werden.
  • Page 4: Sicherheitshinweise

    SICHERHEITSHINWEISE ACHTUNG! Seien Sie besonders vorsichtig beim Umgang mit gefährlicher Netzspannung. Bei die- ser Spannung können Sie einen lebensgefährlichen elektrischen Schlag erhalten! Dieses Gerät hat das Werk in sicherheitstechnisch einwandfreiem Zustand verlassen. Um diesen Zustand zu erhalten und einen gefahrlosen Betrieb sicherzustellen, muss der Anwender die Sicherheitshinweise und die Warnvermerke unbedingt beachten, die in dieser Bedienungsanleitung enthalten sind.
  • Page 5: Bestimmungsgemässe Verwendung

    In das Gerät dürfen keine fremden Gegenstände gelangen. Dies gilt insbesondere für Metallteile. Sollten auch nur kleinste Metallteile wie Heft- und Büroklammern oder gröbere Metallspäne in das Gerät gelangen, so ist das Gerät sofort außer Betrieb zu nehmen und allpolig vom Netz zu trennen. Durch Metallteile hervorgerufene Fehlfunktionen und Kurzschlüsse können tödliche Verletzungen zur Folge haben.
  • Page 6: Anschlüsse Und Bedienelemente

    ANSCHLÜSSE UND BEDIENELEMENTE Front LED PSI-1 DMX CONTROLLER MODE SET UP DOWN 1. MODE-TASTE 2. SET UP-TASTE 3. UP-TASTE 4. DOWN-TASTE 5. DISPLAY Anschlussfeld LIGHT 11 LIGHT 9 LIGHT 7 LIGHT 5 LIGHT 3 LIGHT 1 FUSE: F 4 A/230 V POWER IN AC 100-240 V 50/60 Hz DMX OUT...
  • Page 7: Installation

    INSTALLATION Das Gerät ist geeignet zur Wand- und Trussingmontage. Wandmontage Vergewissern Sie sich vor der Montage, dass die Montagefläche mindestens die 10-fache Punktbelastung des Eigengewichtes des Gerätes aushalten kann. Der Installationsort muss so gewählt werden, dass das Gerät absolut plan an einem festen, erschütterungs- freien, schwingungsfreien und feuerfesten Ort befestigt werden kann.
  • Page 8 Der Unternehmer hat dafür zu sorgen, dass sicherheitstechnische und maschinentechnische Einrichtungen mindestens einmal jährlich durch einen Sachkundigen geprüft werden. Vorgehensweise: Das Gerät sollte idealerweise außerhalb des Aufenthaltsbereiches von Personen installiert werden. WICHTIG! ÜBERKOPFMONTAGE ERFORDERT EIN HOHES MASS AN ERFAHRUNG. Dies beinhaltet (aber beschränkt sich nicht allein auf) Berechnungen zur Definition der Tragfähigkeit, verwendetes Installationsmaterial und regelmäßige Sicherheitsinspektionen des verwendeten Materials und des Gerätes.
  • Page 9: Led-Leuchten Anschließen

    Im Master/Slave-Betrieb lassen sich mehrere Geräte synchronisieren, die dann von einem Mastergerät gesteuert werden. An der Rückseite des EUROLITE LED PSI-1 DMX befinden sich eine XLR-Einbaubuchse und ein XLR- Einbaustecker, über die sich mehrere Geräte miteinander verbinden lassen. Wählen Sie das Gerät aus, das zur Steuerung der Effekte dienen soll. Dieses Gerät arbeitet dann als Master-Gerät und steuert die Slave-Geräte, die über ein zweipoliges geschirmtes Kabel mit dem Master-...
  • Page 10: Dmx512-Ansteuerung

    DMX512-Ansteuerung Achten Sie darauf, dass die Adern der Datenleitung an keiner Stelle miteinander in Kontakt treten. Die Geräte werden ansonsten nicht bzw. nicht korrekt funktionieren. Beachten Sie, dass die Startadresse abhängig vom verwendeten Controller ist. Unbedingt Bedienungsanleitung des verwendeten Controllers beachten. Die Verbindung zwischen Controller und Gerät sowie zwischen den einzelnen Geräten muss mit einem zweipoligen geschirmten Kabel erfolgen.
  • Page 11: Anschluss Ans Netz

    Anschluss ans Netz LEBENSGEFAHR! Lassen Sie den elektrischen Anschluss nur vom autorisierten Fachhandel ausführen! Die Belegung der Anschlussleitungen ist wie folgt: Leitung International Braun Außenleiter Blau Neutralleiter Gelb/Grün Schutzleiter Der Schutzleiter muss unbedingt angeschlossen werden! Wenn das Gerät direkt an das örtliche Stromnetz angeschlossen wird, muss eine Trennvorrichtung mit mindestens 3 mm Kontaktöffnung an jedem Pol in die festverlegte elektrische Installation eingebaut werden.
  • Page 12 4. DMX MODE - DMX-gesteuerter Modus In diesem Menüpunkt können Sie die DMX-Startadresse und den DMX-Modus definieren. Auswahl DMX-Startadresse Stellen Sie mit UP und DOWN einen Wert zwischen 001 und 512 ein. DMX MODE DMX address: 001 MODE SET UP DOWN Auswahl DMX-Modus Drücken Sie die Taste SET UP, um den DMX Modus zu definieren.
  • Page 13 Empfindlichkeit 231-255 Musikgesteuert Keine Funktion Keine Funktion 0-255 Ist für den ersten DMX-Kanal ein Wert zwischen 0 und 250 gewählt, trifft folgendes Protokoll auf das Gerät zu: bis max. CH49 0-10-keine 0-250-Dimmer Funktion 0-255-Rot 0-255-Grün 0-255-Blau (0-100%) 0-255-Strobe 5-Kanal-Modus: Dimmer und 4 Kanäle je Spot: Strobe, Rot, Grün, Blau 9-Kanal-Modus: Dimmer und 4 Kanäle für eine Gruppe von 6 Spots: Strobe, Rot, Grün, Blau 13-Kanal-Modus: Dimmer und 4 Kanäle für eine Gruppe von 4 Spots: Strobe, Rot, Grün, Blau 13/28...
  • Page 14 17-Kanal-Modus: Dimmer und 4 Kanäle für eine Gruppe von 3 Spots: Strobe, Rot, Grün, Blau 25-Kanal-Modus: Dimmer und 4 Kanäle für eine Gruppe von 2 Spots: Strobe, Rot, Grün, Blau 49-Kanal-Modus: Dimmer und 4 Kanäle für jeden Spot: Strobe, Rot, Grün, Blau 5.
  • Page 15: Reinigung Und Wartung

    REINIGUNG UND WARTUNG LEBENSGEFAHR! Vor Wartungsarbeiten unbedingt allpolig vom Netz trennen! Das Gerät sollte regelmäßig von Verunreinigungen wie Staub usw. gereinigt werden. Verwenden Sie zur Reinigung ein fusselfreies, angefeuchtetes Tuch. Auf keinen Fall Alkohol oder irgendwelche Lösungsmittel zur Reinigung verwenden! Im Geräteinneren befinden sich außer der Sicherung keine zu wartenden Teile.
  • Page 16: Introduction

    - download the latest version of the user manual from the Internet INTRODUCTION Thank you for having chosen a EUROLITE LED PSI-1 DMX Controller. If you follow the instructions given in this manual, we are sure that you will enjoy this device for a long period of time.
  • Page 17: Safety Instructions

    SAFETY INSTRUCTIONS CAUTION! Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual.
  • Page 18: Operating Determinations

    The total weight of the installation (=total weight of all individual parts) must never exceed the maximum load of the installation area. If the device will be installed on a trussing system or be suspended, it must always be secured with an appropriate safety-rope! Please consider that damages caused by manual modifications to the device are not subject to warranty.
  • Page 19: Control Elements And Connections

    CONTROL ELEMENTS AND CONNECTIONS Front LED PSI-1 DMX CONTROLLER MODE SET UP DOWN 1. MODE BUTTON 2. FUNC -BUTTON 3. RGB CONTROL EDs 4. DOWN BUTTON 5. UP BUTTON 6. DISPLAY Connections LIGHT 11 LIGHT 9 LIGHT 7 LIGHT 5 LIGHT 3 LIGHT 1 FUSE: F 4 A/230 V...
  • Page 20: Installation

    INSTALLATION Install the device on a plane surface or mount it on a wall or trussing system. Wall mounting Before attaching the device, make sure that the installation area can hold a minimum point load of 10 times the device's weight. The device must only be installed absolutely planar at a vibration-free, oscilation-free and fire-resistant location.
  • Page 21 The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled person once a year. The device should be installed outside areas where persons may walk by or be seated. IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to) calculating working load limits, installation material being used, and periodic safety inspection of all installation material and the device.
  • Page 22: Connection With Luminaries

    The master/slave operation enables that several devices can be synchronized and controlled by one master device. On the side panel of the EUROLITE LED PSI-1 DMX you can find an XLR jack (DMX Out) and an XLR plug (DMX In), which can be used for connecting several devices.
  • Page 23: Dmx512 Control

    DMX512 control The wires must not come into contact with each other, otherwise the devices will not work at all, or will not work properly. Please note, the starting address depends upon which controller is being used. Only use a stereo shielded cable and 3-pin XLR plugs and connectors in order to connect the controller with the device or one device with another.
  • Page 24: Connection With The Mains

    Connection with the mains DANGER TO LIFE! The electric connection must only be carried out by a qualified electrician! The occupation of the connection-cables is as follows: Cable International Brown Live Blue Neutral Yellow/Green Earth The earth has to be connected! If the device will be directly connected with the local power supply network, a disconnection switch with a minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
  • Page 25 4. DMX MODE - DMX-controlled mode Under this point of the menu, you can define the DMX starting address and the DMX mode. Setting DMX starting address Set a value between 001 and 512 via buttons UP/DOWN. DMX MODE DMX address: 001 MODE SET UP DOWN...
  • Page 26 Sensitivity 231-255 Sound-controlled No Function No Function 0-255 If a DMX value between 0 and 250 is selected for the first DMX channel, the following protocol applies to the device: up to CH49 0-250-Dimmer 0-10-No func 0-255-Red 0-255-Green 0-255-Blue (0-100%) 0-255-Strobe 5-channel mode: Dimmer and 4 channels per spot: Strobe, Red, Green, Blue 9-channel mode: Dimmer and 4 channels for a group of 6 spots: Strobe, Red, Green, Blue...
  • Page 27 17-channel mode: Dimmer and 4 channels for a group of 3 spots: Strobe, Red, Green, Blue 25-channel mode: Dimmer and 4 channels for a group of 2 spots: Strobe, Red, Green, Blue 49-channel mode: Dimmer and 4 channels for each spot: Strobe, Red, Green, Blue 5.
  • Page 28: Cleaning And Maintenance

    CLEANING AND MAINTENANCE DANGER TO LIFE! Disconnect from mains before starting maintenance operation! We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use alcohol or solvents! There are no servicable parts inside the device except for the fuse. Maintenance and service operations are only to be carried out by authorized dealers.
