- Page 1 PALM SANDER PALM SANDER MODEL NO: PS105 PART No: 6462055 OPERATION & MAINTENANCE INSTRUCTIONS 0705...
- Page 2 Thank you for purchasing this CLARKE Palm sander, which has been designed for DIY use only. Before attempting to use the sander, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the tool giving you long and satisfactory service.
- Page 3 Safety Precautions WARNING: As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result. ALWAYS Learn the machines applications, limitations and the specific potential hazards peculiar to it.
-
Page 4: Electrical Connections
Electrical Connections Connect the mains lead to a standard 230V (50Hz) electrical supply through an approved 13 Amp BS1363 plug, or a suitably fused isolator switch. WARNING: This appliance is DOUBLE INSULATED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue Neutral... - Page 5 Excessive sparking occurs This indicates worn brushes. This problem is quickly remedied but you should consult your CLARKE dealer for parts and advice. Sander does not operate when switched ON Check to ensure the fuse is sound and replace if necessary. If the fuse is sound or blows...
- Page 6 Parts Diagram PARTS & SERVICE TEL: 020 8988 7400 e-mail as follows: PARTS: Parts@clarkeinternational.com SERVICE: Service@clarkeinternational.com...
- Page 7 HTP510524 Bearing HTP510525 Extractor Duct HTP510526 Vibration Plate HTP510527 Base HTP510528 Screw HTP510529 Screw 6462060 Accessory/Replenishment Pack IMPORTANT: The use of parts other than CLARKE replacement parts may result in safety hazards, decreased tool performance and may invalidate your warranty.
- Page 8 HAND-ARM VIBRATION Refer to notes on page 10 MODEL No: Palm Sander DESCRIPTION: PS105 Declared vibration emmission value in accordance with EN12096 Measured vibration emmission value - a: 6.8 m/s Uncertainty value - K: 8.7 m/s Highest measured reading in a single plane...
