  • Page 1 w i t h I n t e g r a t e d S c a n n e r...
  • Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.

  • Page 3: About This Guide

    • remove and charge batteries Caution: Before you start a PPT 4300-S0E terminal, make sure the Run/Ship switch has been set to the Run position. See “Parts of the PPT 4300-S0E Terminal” on page 4 for the...
  • Page 4 P P T 4 3 0 0 S e r i e s w i t h I n t e g r a t e d S c a n n e r Parts of the PPT 4300-S0E Terminal...
  • Page 5 Q u i c k R e f e r e n c e Parts of the PPT 4300-S0E 1. Pen Snap Holder 2. Pen 3. Antenna 4. Display Screen 5. Direct Access Panel 6. Scanning Icon 7. Keyboard 8. IrDA Port 9.

  • Page 6: Starting The Terminal

    P P T 4 3 0 0 S e r i e s w i t h I n t e g r a t e d S c a n n e r Using the Power Icon The Power icon is located at the top of the Direct Access Panel on the left side of the display.

  • Page 7: Starting Applications

    Q u i c k R e f e r e n c e Starting Applications After the terminal boots, one of the following appears: • a custom application, specific to your facility ® RAME ™ • a Citrix window •...

  • Page 8: Using The Terminal

    Using the Terminal Using the Touch Screen The PPT 4300-S0E terminal is designed to be used with an electromagnetic (EM) pen. This pen acts as a mouse. The table below describes how the pen works in a Windows session run on a DOS W client.

  • Page 9: Attaching An External Keyboard

    R e f e r e n c e Using the Keypad The PPT 4300-S0E terminal has an integral, 78-key keypad. The keypad also includes an Fn key that allows access to a set of alternate functions. These functions include:...

  • Page 10: Numeric Keypad

    P P T 4 3 0 0 S e r i e s w i t h I n t e g r a t e d S c a n n e r Numeric Keypad The keyboard incorporates a numeric keypad, using the symbols marked in small blue letters on the 7, 8, 9, 0, U, I, O, P, J, K, L, :, M and >...

  • Page 11: Using The Scanner

    Q u i c k R e f e r e n c e Scanning The PPT 4300-S0E provides an integrated scanning module with 1-D standard capability. Using the Scanner The terminal must have a scanning application and scanner driver loaded before you can use the scanner.

  • Page 12: Scanning Tips

    Note: Decoding of properly printed bar codes should be quick and effortless.Contact the Symbol Support Center if you have difficulty scanning. Scanning Tips Usually, scanning is a simple matter of aiming, scanning, and decoding.
  • Page 13 Q u i c k R e f e r e n c e Angle The scanning angle is important for quick bar code decoding and to avoid “blinding” the scanner. “Blinding” can occur when the scanner’s laser beam reflects directly back into the scanner from the bar code.
  • Page 14 P P T 4 3 0 0 S e r i e s w i t h I n t e g r a t e d S c a n n e r If the terminal is preparing to enter Doze mode while a scan is in progress, the scan will continue and Doze mode will not be activated.
  • Page 15 The Direct Access Panel The Direct Access Panel is located on the left side of the display window. It allows you to control settings on a PPT 4300-S0E terminal. Except for the Power icon, it is not active until after the terminal has finished booting.
  • Page 16 P P T 4 3 0 0 S e r i e s w i t h I n t e g r a t e d S c a n n e r Icon What it does Displays Remaining Battery Life as a percentage. Battery The Mouse icon is disabled.

  • Page 17: Providing Power To The Terminal

    Q u i c k R e f e r e n c e Providing Power to the Terminal You can run a PPT 4300-S0E terminal: • from a rechargeable NiMH (Nickel Metal Hydride) battery pack, or • by using the supplied DC Adapter plugged into a standard electrical outlet (see page 21).

  • Page 18: Changing The Battery

    You can change the battery on a PPT 4300-S0E terminal without logging out or losing your session. To do this: 1. Make sure you have a fully charged battery available and close at hand.
  • Page 19 Q u i c k R e f e r e n c e Note: You may find it easier to remove the battery if you hold the terminal with the display facing you, with your hands on both sides. Then, push up on the Battery Latch, with your finger-tips and allow the battery to slip out of the battery compartment.
  • Page 20 S c a n n e r Re-charging a Battery Pack As an option, Symbol supplies two types of Battery Chargers (a single-slot unit and a four-slot unit). For specific instructions on the use of the Battery Charger, see the user guide which came with your Battery Charger, or refer to the PPT 4300 Series Product Reference Guide.

  • Page 21: Using An External Power Source

    R e f e r e n c e Using an External Power Source You can connect a PPT 4300-S0E terminal to a DC adapter so that it can be powered from a standard electrical outlet. Note that the Power Management features are disabled when the terminal is running from the DC adapter.

  • Page 22: Service Information

    Customer will pay for the replacement product in case it does not return the replaced product to Symbol within 3 days of receipt of the replacement product. The process for return and customer’s charges will be in accordance with Symbol’s Exchange Policy in effect at the time of the exchange.

  • Page 23: Regulatory Information

    The stated express warranties are in lieu of all obligations or liabilities on part of Symbol for damages, including without limitation, special, indirect, or consequential damages arising out of or in connection with the use or performance of the product.

  • Page 24: Laser Devices

    • EN 60 825-1 (EN 60 825) - Safety of Devices Containing Lasers Laser Devices Symbol products using lasers comply with US 21CFR1040.10, Subchapter J and IEC825/EN 60 825 (or IEC825-1/EN 60 825-1, depending on the date of manufacture). The laser classification is marked on one of the labels on the product.
  • Page 25 Q u i c k R e f e r e n c e Class 2 laser scanners use a low power, visible light diode. As with any very bright light source, such as the sun, the user should avoid staring directly into the light beam. Momentary exposure to a Class 2 laser is not known to be harmful.
  • Page 26 P P T 4 3 0 0 S e r i e s w i t h I n t e g r a t e d S c a n n e r In accordance with Clause 5, IEC 0825 and EN60825, the following information is provided to the user: ENGLISH CLASS 1...
  • Page 27 Q u i c k R e f e r e n c e GERMAN KLASSE 1 LASERPRODUKT DER KLASSE 1 KLASSE 2 LASERSTRAHLEN NICHT DIREKT IN DEN LASERSTRAHL SCHAUEN LASERPRODUKT DER KLASSE 2 HEBREW ITALIAN CLASSE 1 PRODOTTO AL LASER DI CLASSE 1 CLASSE 2 LUCE LASER NON FISSARE IL RAGGIOPRODOTTO AL LASER DI CLASSE 2...
  • Page 28 The majority of Symbol’s RF devices are type approved and do not require the user to obtain license or authorization before using the equipment. Any changes or modifications to Symbol Technologies equipment not expressly approved by Symbol Technologies could void the user’s authority to operate the equipment.
